- Page 1 Operating your Machine with the Electric or Gasoline Motor EVEREST Models: a) TK1-PS GE b) TK2-PS GE c) TK2-2PS GE 315 E. Banks St. Glennville, GA 30427 Tel: 912-339-0173...
- Page 2 Using Your Machine With The Electric Motor: Your machine has dual power: Electric and Gasoline. In order to use the electric side, you will need to remove the belt that is located under the cover, between the electric and gasoline motor.
- Page 3 Removing the belt: Step1 – Make sure the machine is unplugged and the switch on the gasoline engine is turned to the off position. Step 2 – Remove the belt. Use a 1/2 in. wrench or socket to remove the screws on both sides of the cover.
- Page 4 3. Grab the cover and remove it to expose the belt. 4. Locate the bolt beneath the belt/gasoline motor.
- Page 5 5. Use a 3/4” wrench or socket to remove the bolt. 6. Grab the hinge and lift it up.
- Page 6 7. While lifting the hinge up, the belt will loosen. Grab the belt and remove it from the pulley (wheel). Be careful not to get your fingers caught between the belt and pulley. 8. Plug in machine. Turn the electric motor to position 1. Now you can start milking with the electric motor.
- Page 7 Using Your Machine With The Gasoline Motor If you are using the gasoline motor, always check that you unplug the electric motor. If you are using the electric motor, always check that the switch for the gasoline motor is turned off. 1.
- Page 8 2. Remove the cap to the air filter container. Fill it with the same motor oil to the ‘Oil Level” line on the container. 3. Remove the air filter and saturate it in the motor oil, then squeeze it to remove any excess oil. Reapply the cap to the container.
- Page 9 4. Put gasoline into the tank. 5. Install the belt on the pulley (wheel): Lift the hinge beneath the pulley (wheel)/gasoline engine.
- Page 10 6. While lifting the hinge, grab the belt and attach it onto the pulley (wheel).
- Page 11 7. Attach the nut back onto the screw that is on the hinge using a 3/4” wrench or socket.. 8. Grab the cover and place it back over belt/pulley.
- Page 12 9. Apply the nuts back onto the screws on both sides of the cover using a 1/2” wrench or socket. 10.Turn on the switch on the gasoline motor.
- Page 13 11.Move the choke and gas levers to the left. 12. Pull the Starter Cord several times until the motor starts running.
- Page 14 13.Once the motor is running, move the upper lever to the right where the CHOKE is on RUN. 14.Adjust the speed lever to the middle.
- Page 15 Once the motor is running, please refer to “Operation of the Milking Machine” brochure to start milking.
