Page 1: Table Of Contents
OASIS GLASS VERANDA INSTALLATION GUIDE ISSUE 1 CONTENTS BE SAFE WHEN WORKING AT HEIGHT Ensure you conform to the latest Work at Introduction Height Regulations. For more details, visit: Safety precautions and warnings www.hse.gov.uk/work-at-height Product description Parts overview Preparation for assembly...
Page 2: Introduction
Before you can start enjoying your patio roof it must be assembled properly. This manual provides clear instructions for all the steps you must complete for correct assembly of your Deeplas patio roof. We recommend that you take the time to read the entire manual before you begin assembly.
Page 3: Product Description
(Victorian style) decorative gutter and semicircular or square posts. The Deeplas Pigato patio roof is available as standard in widths of 4060, 5060 or 6060 as a single section; there is no limit to the number of sections that can be joined end to end.
Page 4: Parts Overview
4. PARTS OVERVIEW 4. Parts overview 4.1 EXPLODED VIEW 4.1 Exploded view 4.2 Delivery inspection The patio roof shown in this manual is a 5x3 metre Pigato with the posts on foundation blocks. This merely serves as an example. The type and number of components supplied depends on your order. Note: Always carefully check the delivered items against the accompanying delivery note to ensure DELIVERY INSPECTION that the quantity and quality are correct.
Page 5: Parts List
4.3 PARTS LIST 4.3 Parts list The following overview shows which parts are packed together. Carefully check the individual packaging units The following overview shows which parts are packed together. Carefully check the individual against the order form for quantity and quality. packaging units against the order form for quantity and quality.
Page 6 15. 44.2 laminated glass 1x bag of screws 21. Trim cover 21A. Trim cover 1x bag of screws short 4.2x16 + bit gutter profile gutter profile long 4.2x40 round traditional 09A. Rainwater 04. Leaf catcher 1x set frame fixing 9. 90° rainwater discharge sleeve 60mm screws...
Page 7: Preparation For Assembly
Dimensions & slope This caulk is available from retailers. A Deeplas roof should be installed with a slope of 120mm Rubber seals per metre. The height of the wall profile and the passage...
Page 8 5.2 INSPECTION OF TOOLS AND ACCESSORIES 5.2 Inspection of tools and accessories O A S I S G L A S S V E R A N D A I N S T A L L A T I O N G U I D E...
Page 9 W: Length of wall profile, gutter profile and decorative profile. The Deeplas patio roof is available in a large range of sizes. Moreover, the roof has a modular design and can be quickly and W: Length of wall profile, gutter profile and decorative profile.
Page 10 5.3.1 HEIGHT ADJUSTMENTS A Deeplas patio roof is designed for a slope of 120mm per metre. All the static strength calculations, as well as all sizes and dimensions in this manual, are based on this. The height of the wall profile and the passage height (distance from bottom of gutter to the ground) are completely dependent on each other and determined by this slope.
Page 11 5.4 JOINING PATIO ROOFS There is no limit to the width in which the Deeplas patio roofs can be delivered. This is because the patio roofs can be joined end to 5.4 Joining patio roofs end. In this case the gutter profile, wall profile and decorative profile are supplied in multiple lengths of 4060, 5060 or 6060mm. The centre-to-centre distance of the rafters, the number of sections and the glass width depend on the width of the Deeplas patio roof.
Page 12 After this shortening the further assembly is identical to that for a normal roof. After this shortening the further assembly is identical to that for a normal roof. 5.4 Joining patio roofs (continued) 5.4 JOINING PATIO ROOFS (CONTINUED) It is recommended that you join the gutter sections with the supplied gutter connector before installation.
Page 13: Assembly
6. Assembly 6. Assembly 6.1 Mounting the wall profile 6.1 Mounting the wall profile 6. ASSEMBLY If the wall profile does not need to be shortened, you can mount it straight away. Otherwise you If the wall profile does not need to be shortened, you can mount it straight away. Otherwise you must first cut the wall profile to the desired length.
Page 14 4. Fasten the wall profile with the supplied frame fixing screws (these should only be used if appropriate for the wall material). 5. Degrease the top edge of the wall profile along the wall. 6. Caulk the top edge of the wall profile (between the wall and the wall profile) to make a good seal. Strike off the caulk to make it smooth and waterproof.
Page 15 6.2 PRE-INSTALLING THE GUTTER If the standard gutter length is correct, you can pre-install it straight away. If not, you must first cut the gutter profile and decorative profile to the desired length. 6.2.1 Installing the leaf catcher in the gutter 1.
Page 16 6.2.2 Attaching the decorative profile to the gutter 1. Place the gutter flat and firm on a table or sawhorses. Place the decorative profile on the top of the gutter and click the bottom of the decorative profile under the gutter. 2.
Page 17 1. Place the gutter flat and firm on a table or sawhorses. 2. Slide the steel strip into the gutter. Use a lubricant. Tip: the steel strip can be ‘ratcheted’ in place with a lashing strap. 6.2.3 Installing the steel strip in the gutter The gutter is fitted with a 20x100mm steel strip to hold the glass.
Page 18 6.3 INSTALLING POSTS, GUTTER AND END RAFTERS 6.3.1 Installing posts on foundation blocks Determine the positions of the foundation blocks and the foundation block with the rainwater discharge. Place the foundation blocks in the ground as accurately as possible. Make sure that the top of the foundation block is placed at least 100mm below ground level, and place them level.
Page 19 1/2 B-55mm 1/2 B-55mm Min. 100mm s:: _ Note: If you shorten any of the posts, take into account the depth of the foundation blocks and the bottom end of the post. 1. Place the post with the PVC rainwater discharge pipe at the location of the rainwater discharge foundation block. 2.
Page 20 6.3.2 Installing the gutter 1. Now place the pre-assembled gutter profile on the posts. Make sure the leaf catcher is positioned properly in the PVC rainwater discharge pipe. 2. Screw the posts to the gutter with one short screw through the lower lip of the gutter profile and into the post. This way you can adjust the position of the gutter later, if necessary.
Page 21 6.3.3 Installing the end rafters 1. Carefully cut the pre-fitted rubber seals in the end rafters to size. 2. Place the left and right end rafters in both the gutter profile and the wall profile, one by one. Make sure that the outer edges of the end rafters are flush with the ends of the gutter profile and wall profile.
Page 22 Screw the end rafters to both the gutter profile and wall profile from the top with one short screw per end. Make sure the roof is completely square. Secure the end rafters with the second screw. Screw the end rafters to both the gutter profile and wall profile from the top with one short screw per end. Make sure the roof is completely square.
Page 23 714mm Note: if you install Deeplas LED lighting, we recommend performing the installation before placing the middle rafters. If you do not shorten the width of your patio roof, you can use the trim elements for the gutter as spacers between the rafters.
Page 24 654mm 654mm 654mm 654mm 654mm 654mm 4. Then place the remaining middle rafters in the wall profile and gutter profile at the desired distance. Note: see table on page 11 for the correct dimensions. 5. Screw the middle rafters to both the gutter profile and wall profile with two short screws. www.deponti.com Patio Roof Manual –...
Page 25 2. Place the inside trim covers on the gutter profile. Note: if Deeplas LED lighting is installed, make sure all the cabling is properly positioned and connected before the inside trim covers are fitted. We recommend placing the transformer behind a trim click strip so it will be easily accessible for future service.
Page 26 2. Carefully cut the pre-fitted rubber seals in the aluminium end cover strip to size. 3. Pre-drill the end cover strip with a 3 mm drill bit (1 top – 1 bottom – 1 middle). Fit the end cover strip. Position the cover strip flush with the rafter at the wall and gutter ends. At the wall end the cover strip fits just a bit under the wall profile for extra anchoring.
Page 27 1. Place the second glass panel between the rafters. 2. Carefully cut the pre-fitted rubber seals in the aluminium middle cover strip to size. 3. Pre-drill the middle cover strip with a 3 mm drill bit (1 top – 1 bottom – 1 middle). Fit the middle cover strip.
Page 28 5. Repeat steps 1 to 4 on pages 29 & 30 for installation of the other cover strips. 5. Repeat steps 1 to 4 on pages 29 & 30 for installation of the other cover strips. 5. Repeat steps 1 to 4 on pages 26 & 27 for installation of the other cover strips. 6.
Page 29 6.6 Finishing 6.6 FINISHING 6.6 Finishing Silicon spray Silicon spray 1. Position the rubber strip in the wall profile properly so it covers the sheets and cover strips. 2. Carefully cut the rubber strip to size at both ends. www.deponti.com Patio Roof Manual –...
Page 30 5. Carefully screw the decorative profile trim cover to the gutter profile and the decorative profile with the short screws in the guides provided for this purpose. 6. Caulk the inside of the gutter so it is waterproof. 4. Apply caulk to both ends of the gutter profile and decorative profile. 5.
Page 31 8. Remove the remaining protective film from the aluminium parts. 7. Now attach the sheet stoppers to the cover strips of the end rafters with the short screws. 8. Remove the remaining protective film from the aluminium parts. www.deponti.com Patio Roof Manual – Type Pigato...
Page 32 9. Secure your posts with the second short screw. 10. If there is a small gap between the top of the posts and the gutter you can seal it with caulk. 9. Secure your posts with the second short screw. 10.
Page 33: Maintenance
8. DISPOSAL OF WASTE Dispose of the product according to local laws and regulations. 9. GUARANTEE For a copy of the Deeplas product guarantee certificate please visit the following web page: shttps://www.eurocell.co.uk/technical-support/guarantee-certificates/conservatory-certificates please advise re web address and QR code 10.
Page 34 DESIGN GRID O A S I S G L A S S V E R A N D A I N S T A L L A T I O N G U I D E...
Page 35 DESIGN GRID...
Page 36 & CEILING PANELS SKIRTING CLADDING SLATESKIN GRP DEEPLAS WINDOW RAINWATER SHOWER PANELS GARDEN ROOMS SHEET TILE SYSTEM BOARDS Customer service If you need any assistance, please call the Customer Services team on 0800 988 7307 or visit deeplas.co.uk DE00055 Is1/Mar22...
