Summary of Contents for Nidec Embraco Sync
- Page 1 Electronic devices quick installation guide...
- Page 3 This material will explain how to explore some of the main features of Embraco electronic devices: Embraco Sync Embraco Air Electronic controller ECM Fan ● Controller Connections ● ECM Connections ● Controller Setup ● ECM Fan Setup Using ● Parameters - General list YouControl ●...
-
Page 5: Controller Setup
Controller Setup Using YouControl Using Controller display Configure the Easily visualization of parameters using the all the parameters in touch buttons on one single page. Embraco Sync display... -
Page 6: Initial Setup
Controller Setup Using YouControl Initial setup 1. Download and install ‘YouControl Interface’; 2. Connect the Programming Key to the computer using Cable 1; 3. Find the 'YouControl Input' on the Controller and connect it with the Programming Key via Cable 2. Access YouControl and instructions HERE... -
Page 7: Configuration Tab
Controller Setup Using YouControl Configuration Tab Use this tab to configure controller parameters. Expand all Expand parameter groups Group Parameter Buttons value input Import and export parameter in .csv file Reload Controller Parameters Reset default values Apply parameters to the controller... - Page 8 Controller Setup Using YouControl Chart Tab Use this tab to follow up testing with the controller. Controller Information Chart Controls Cursors Legend Data Explorer...
- Page 9 Controller Setup Using YouControl Chart Tab Use this tab to follow up testing with the controller. Real time data Events History Comments Backlog...
-
Page 10: Controller Display
Controller Setup Using Controller Display Display Buttons The display interface can be used to set up the parameters such as light, defrost, setpoint, turn on and turn off the application, through the 4 buttons there are on the main screen. BACK / Light UP / Defrost DOWN / On/Off... - Page 11 Controller Setup Using Controller Display Unlocking Parameter Editing 1. Press all the keys at the same time 2. Press the key “ENTER” until the 3. Confirm your password by using until the display shows “UnL”, then display show “PAS”, then release it. keys “UP”...
-
Page 12: Adjusting Setpoint
Using Controller Display Adjusting Setpoint 5. Use the keys “UP” and “DOWN” to 6. Touch the key “ENTER”, to show the 7. Use the keys “UP” and “DOWN” to select the thermostat parameter group parameter “t00”; and touch it again, to adjust the new value of the SetPoint “tHE”. -
Page 13: Initial Commissioning
Parameters General List Initial Commissioning Use parameters below to control logic configurations in the initial setup. Group Code Description Possible Values Default -99.9 to 99.9 [ºC] 4.0 [°C] Setpoint -147.8 to 211.8 [°F] 39.2 [°F] THERMOSTAT (tHE) -99.9 to 99.9 [ºC] 2.0 [°C] Hysteresis -147.8 to 211.8 [°F]... - Page 14 Parameters General List Initial Commissioning Use parameters below to control logic configurations in the initial setup. Group Code Description Possible Values Default 0: Disabled 2: Hot-gas Defrost type 1: Heater 3: Off-cycle 0 : disabled End defrost timeout 1 to 999 [min] -50 to 50 [ºC] 12 [°C] Defrost termination temperature...
- Page 15 Adaptive Door Heater Dynamic door temperature control providing energy saving. Control behavior Adaptive Door Heater Basic behavior Ambient probe Two probes are required for Ambient location adaptive door heater control: - Ambient - Door Door Logic Steps Note the dH1 temperature Door relay differential is the coldest external door temperature (heater cut-in).
- Page 16 Adaptive Defrost Adaptive Defrost logic providing energy saving and temperature stability. Evaporator Probe - Control behavior *no additional probe is needed *placement depends on defrost type Adaptive Defrost Defrost Ice-free Minimum AD Next defrost evaporator period (d16) by max period (d07) Defrost triggered...
- Page 17 Controller User Manual All you need to know about the controller Introduction Models & Features Accessories & Temperature Sensors Enclosure Details & Assembly Wiring Diagrams YouControl Embraco Development Interface Display Interface Commissioning Functions Alarms Modbus Parameter Table Technical Specifications Access User Manual HERE...
- Page 18 Embraco Air...
- Page 19 Wire Connections 5 Wires - Samples sent in the Integration Gift. - Below are the wire diagrams for each of the speed settings. 1st Speed (Phase + Neutral) 2nd Speed (Phase + Neutral + Black + Blue) White Neutral White Neutral Brown Phase...
- Page 20 Wire Connections 2 Wires & 3 Wires - Below are the wire diagrams for each of the speed settings. 1st Speed (Phase + Neutral) White Neutral Brown Phase 1st Speed (Phase + Neutral) 2nd Speed (Phase + Neutral + Black) White Neutral White...
- Page 21 ECM Fan Setup Using YouControl YouControl To properly connect the ECM Fan to the YouControl Tool Connect Fan signal wires to the Data Cable Adapter Connect the Data Cable to the Programming Key Connect the Programming Key to the PC Run YouControl Software Computer ECM Fan...
- Page 22 ECM Fan Setup Using YouControl Manual Control Tab Use this tab to live control the ECM Fan speed and direction. Direction (Shaft-End) Rotation Speed (RPM) Set ECM Fan Speed...
- Page 23 ECM Fan Setup Using YouControl Chart Tab Use this tab to follow up testing with the ECM Fan. ECM Fan Information Chart Controls Cursors Legend Data Explorer...
- Page 24 ECM Fan Setup Using YouControl Configuration Tab Use this tab to configure ECM Fan speed settings (5 wires version only). Reverse at Start (seconds) Signal Wires Import and export parameter in .txt file Reset default values Apply speed settings to the ECM Fan Direction Rotation (Shaft-End)
- Page 25 Embraco Air Preliminary Manual Embraco Air Features and Technical Information Table of Features and Certifications Nomenclature External View Speed Configuration and Selection Blade Matches Performance Curves Cable Connectors Configuration Accessories Access Preliminary User Manual HERE...
- Page 26 embraco.com embraco.com For an in-depth look about For an in-depth look about our solutions, follow our our solutions, follow our pages: pages:...
- Page 27 A brand portfolio of A brand portfolio of...
