- Page 1 Series Satellite Gateway U S E R G U I D E 06/2024 Remotely manage, monitor, and control your fence and energizer.
-
Page 2: Box Contents
Box contents You will need • Gallagher i Series Energizer and Energizer Controller Satellite Gateway • Mobile Phone with iPhone iOS 14 or later, or Android v6.0 or later Power Supply • WiFi or cellular coverage for set-up prior to installation Antenna •... -
Page 3: How It Works
• This data is stored in the cloud. • When your mobile device has WiFi or cellular coverage, it retrieves the data and loads it into your Gallagher Devices app. • Time interval between reads will vary depending on Satellites orbiting the earth and the location of your antenna. -
Page 4: Installation Site
Before you head to site, ensure you have: □ Created your account and purchased a subscription. □ Downloaded the Gallagher Devices app and are logged in. □ A Gallagher i Series Energizer and Energizer Controller. □ Screws and a drill bit to fasten the Satellite Gateway to a wall (not included). - Page 5 Physical Install Install your i Series Energizer and Controller • Install your i Series Energizer and Energizer Controller according to the supplied instructions. • Power off the energizer. Install the Satellite Gateway • Choose an indoor location that is sheltered from wind and rain and within one meter of the energizer.
- Page 6 Power and satellite connection Power the i Series Energizer and Satellite Gateway • The i Series Energizer and the Satellite Gateway can be powered by mains, solar, or battery. Note: The controller is powered by the energizer. • A 15V power supply is provided with the Satellite Gateway for mains connection.
- Page 7 Gallagher Devices app using Bluetooth®. Gallagher Devices App and status Button The Gallagher Devices app shows the status for: • Energizer connection • Power connection • Satellite signal strength • Satellite data transfer Open the Gallagher Devices app: •...
-
Page 8: Optional Accessories
Solar Panels Alarm System Ideal security alarm where Convert multi powered valuable livestock or energizers into equipment is kept. solar-powered energizers Gallagher Private Bag 3026 Hamilton, New Zealand pg. 8...
