- Page 1 Nişantepe Mh. Gelin Çiçeği Sk. No:36 Çekmeköy 34794 İstanbul (0216) 585 18 18 (0216) 585 18 19 esit.com.tr Wifi Plus User Manual - R00...
- Page 2 Wifi Plus User Manual...
- Page 4 Wifi Plus User Manual...
- Page 5 Wifi Plus – Instruction Manual _______________________________________ CONTENTS 1. INTRODUCTION ... Hata! Yer işareti tanımlanmamış. 2. TECHNICAL DRAWING AND MEASUREMENTS Figure 1 Front View of the Access Point ..Hata! Yer işareti tanımlanmamış. 3. INSTALLATION ..... Hata! Yer işareti tanımlanmamış. Deleting the Access Point Record List and Performing a New Device Scan .....
- Page 6 Esit products enabled by the RF modules built in them. This instruction manual contains all the information you'll need for the installation and use of ESİT Wifi Plus and every case scenario that may take place. All the written and visual material contained in this instruction manual belongs to ESİT Elektronik Sistemler İmalat ve...
- Page 7 Wifi Plus – Instruction Manual _______________________________________ 2. TECHNICAL DRAWING AND MEASUREMENTS Figure 1 Front View of the Access Point ________________________________________ Page 3...
- Page 8 Wifi Plus – Instruction Manual _______________________________________ Figure 2 Side View of Access Point ________________________________________ Page 4...
-
Page 9: Installation
Wifi Plus – Instruction Manual _______________________________________ 3. INSTALLATION Esit Wifi Plus consists of a central device (Access Point) and end points (End Device) that are connected to Esit products. Each communication group is made up of a transmitter (End Device connected to the indicator) and one or more receivers (End Device connected to the external indicator). - Page 10 Wifi Plus – Instruction Manual _______________________________________ NOTE: If more than one device is gathered (collective device) in a single display then no additional new device group can be introduced. Communication group of 1 – 1AP2ED ________________________________________ Page 6...
- Page 11 Wifi Plus – Instruction Manual _______________________________________ Communication group of 2 – 1AP4ED ________________________________________ Page 7...
- Page 12 Wifi Plus – Instruction Manual _______________________________________ Access Point Status Table (If Pressed on the Button While Being Powered) Green Led Red Led Result Lighting Lighting Constantly Constantly Continue to press the button for scanning. The button has been pressed consistently for 3 seconds after it was powered.
- Page 13 Wifi Plus – Instruction Manual _______________________________________ Access Point Status Table (While Powered) Green Led Red Led Result Lighting Constantly Dimmed Access Point record list is empty. All the devices included in the Access Point record list Flashing Dimmed communicate soundly with the Access Point.
- Page 14 Wifi Plus – Instruction Manual _______________________________________ 9. The green and red leds will blink during the scan mode. When the scan is completed, the device will go into the result status. If the green led is alight while the red led is dimmed, all the devices within the field are successfully introduced.
- Page 15 Wifi Plus – Instruction Manual _______________________________________ Connecting Power to the Access Point Access Point Devices are powered with either 12V or 24V DC voltage. Access Point Devices are fitted with a 1.5 meter long cable. Access Point connection cable colors are as follows;...
- Page 16 Wifi Plus – Instruction Manual _______________________________________ Making Electrical and Communication Connection of an End Device End Devices are powered with either 12V or 24V DC voltage. End Devices are fitted with a 1.5 meter long cable. End Device connection cable colors are as follows;...
- Page 17 Wifi Plus – Instruction Manual _______________________________________ Connecting an End Device to an Indicator; Connect the green end of the Device with either 12VDC or 24VDC supply and the black end with the GND supply. For an ART Indicator; Connect the End Device’s Communication connector of 9 to the serial communication port of an ART indicator.
- Page 18 Wifi Plus – Instruction Manual _______________________________________ Set the Communication Format (Rate) parameter of the Art Indicator as 9600 Communication Format (Number of Bits) parameter as Communication Format (Parity Bit) parameter as See the Art Serial Indicators Instruction Manual on page And switch the Art Indicator Communication Type to Mode 1, the constant data transmission mode.
- Page 19 Wifi Plus – Instruction Manual _______________________________________ PWI Indicator; Connect the End Device’s Communication connector of 9 to the serial communication port of a PWI indicator. Back View of a PWI Indicator 1- Analog Output (15’D Female) 2- Digital Output (25’D Male) 3- Analog Input Connector (9’D female)
- Page 20 Wifi Plus – Instruction Manual _______________________________________ Connecting an End Device to an External Indicator; End Devices use the communication rate of 9600 Baud rate. External indicator is first set to the communication rate of 9600 Baud rate. And then the D_Sub 9 connector fitted on the End Device’s cable end is disconnected.
