- Page 1 User Manual Video RoyalBaby Customer Support service@royal-bike.com Tutorial +1 (888)881-BIKE (2453) Model: RB24-37 Recommend Height: 130-170 CM RoyalBaby Cycle Beijing Co., Ltd. Manufacturer ONCE A ROYAL RIDER ALWAYS A BIKING LOVER...
-
Page 2: Front Wheel Assembly
Fig.1 Stem Brake Lever Saddle Fork Disc Brake Rotor Pedal Kickstand Preparation 1.Prop up the kickstand 2.Remove all tie wraps 3.Make sure all parts are included Front Wheel Assembly Quick-release Skewer Installation 2. Securing the Front Wheel 3. Secure the Quick-release Remove the front wheel skewer by loosening the Insert the disc brake into the caliper. -
Page 3: Handlebar Assembly
Handlebar assembly Important： Make sure the fork arch faces the front before adjusting the handlebar. 1.Rotate the handlebar 2.Remove the face plate Use a hex driver to loosen the ① pinch bolt on the stem by turning Use a hex driver to loosen the four bolts securing counterclockwise. -
Page 4: Saddle Assembly
Pedal Assembly 1.Identify sides 2.Pedal assembly Identify the pedal's left (L) and right (R) sides. Thread in the left pedal on the left-hand side crank by turning counterclockwise. Thread in the right pedal on the right-hand side crank by turning clockwise Saddle Assembly 2.Secure the saddle Tighten a)nut until the lever becomes... - Page 5 Maintenance and Service Guide cable-tightening screw (h), tighten and adjust the brake cable (i), to make RIDING SAFETY the distance between the brake shoe (r2) and disc brake< 1mm. 1.Always wear a helmet when riding a bike. B.Adjustments for grinding noise during riding: 2.Check brakes before riding.
