RoyalBaby FREESTYLE PREMIUM Assembly Instruction

ASSEMBLY INSTRUCTION
Please get in touch with our customer service if you encounter any difficulties during
HANDLEBAR INSTALLATION
Remove wedge cover
Use a wrench and turn the cover counterclockwise if
the cover is too tight to be removed.
Stem bolt
1
Minimum insertion marks
Be sure the
2
minimum insertion marks
are not visible.
Install the Stem ① into the Head tube ②, and tighten
the stem bolt clockwise.
Avoid overtightening the bolt
and cracking the screw
Tilt the brake lever 30 degrees
downward and tighten the
30°
adjustment screw clockwise
with a hex wrench.
the assembly at +1(888)-881-BIKE(2453) or service@royal-bike.com
SADDLE INSTALLATION
Minimum insertion marks
Wedge
Be sure the
minimum insertion marks
are not visible.
Unlock the quick-release lever and insert the seat post
into the seat tube.
1
Start to hand tighten the Adjustment nut ① and close
the quick-release lever ②.
If the seat is not securely locked, open quick-release
lever and tighten the adjustment nut further.
PEDAL INSTALLATION
L
Match the pedal marked R with the right-hand crank
arm,and match the pedal marked L with the left-hand
crank arm.
Left-hand crank arm example
2
The left pedal (L) turns counter-clockwise and the
right pedal (R) turns clockwise.
R
