- Page 1 ASPECT 4 DOUBLE SIDED WOOD BURNING STOVE JINASDS RevB 20/08/2024 HUNTERSTOVES.CO.UK...
-
Page 2: Table Of Contents
Welcome to the Hunter Stoves family, thank you for purchasing an Aspect Double Sided stove. This stove was designed and built to be a high-performance heating appliance, and we hope it will bring you great enjoyment. The natural environment is important to us and our stoves are manufactured to provide you with a clean and efficient burn that will keep you warm through cold winter nights. -
Page 3: Stove Dimensions
STOVE DIMENSIONS DIMENSIONS Aspect 4 580mm 620mm 415mm 127mm 420mm 516mm Double Sided GENERAL INFORMATION Legal Requirements These instructions cover the basic principles to ensure satisfactory installation of the stove, although details This appliance will become very hot when used in may need slight modification to suit particular local site accordance with the instructions. - Page 4 GENERAL INFORMATION Carbon Monoxide (CO) Alarms Hearth In compliance with Building Regulations, a carbon Hearth constructions must comply with the current monoxide (CO) alarm must be installed in the room building regulations. where the stove is located. (See page 13 for additional Your stove must be installed on a floor with adequate details.) load-bearing capacity.
-
Page 5: Material Clearances
GENERAL INFORMATION Nominal Mean Flue Flue Gas Min. Stove Model Efficiency CO (@13% O ) Weight Heat Output Temp. Mass FLow Draft Aspect 4 5.0kW 0.088% 88kg 292°C 5.0 g/sec 12Pa Double Sided MATERIAL CLEARANCES Combustible Distances Model (Twin-Walled Flue) Constructional Front to Hearth... -
Page 6: General Guidance
GENERAL GUIDANCE Unpacking and Removing Internal Components After unpacking all internal components must be removed prior to fitting the stove. This will make handling the stove easier; allow access to fixings and the flue outlet; as well as protect the internal components from damage during the Installation process. - Page 7 GENERAL GUIDANCE Flue Collar Secondary Steel Baffle The Secondary Steel Baffle fits between the 2 Top Air Deflectors. ensure it is fitted correctly prior to fitting the Vermiculite Fire Bricks The Flue Collar and Flue Gasket are supplied seperately and will need fitting during installation Direct Air Side Bricks &...
- Page 8 Vermiculite Fire Brick Assembly Appliance body made transparent for clarity Fit front right hand side brick Fit rear left hand side brick. Fit front baffle brick and hold the left hand side high to aid the fitting of the left hand side brick Fit rear right hand side brick.
-
Page 9: Fuel Overloading
SMOKE CONTROL AREA EXEMPT The Clean Air Act 1993 and Smoke Control Areas Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed boiler if located in a designated smoke control area. -
Page 10: Important Warning
Health and Safety Guidance Special care must be taken when installing the stove such that the requirements of the Health and Safety at Work Act are met. Handling This appliance is very heavy. Adequate facilities must be available for loading, unloading and side handling. Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS Stove Body Safety Advice The stove paint curing process takes place at room temperature and the surface coating is virtually free from fumes and odours. When being put into operation for the first time we would recommend that windows and doors are opened for a short time to provide ventilation. -
Page 12: Adding Wood
Adding Wood Only refuel when the fire has died down to embers. Ensure that the wood you are using has a moisture content of less than 20% (we recommend 12-15% to ensure an efficient burn). When refuelling open all the air controls fully and the damper (if fitted). Open the door slowly by releasing the handle and remaning in this position for 5 to 10 seconds. -
Page 13: Maintenance And Servicing
MAINTENANCE AND SERVICING Periods Of Prolonged Non-Use If the stove is to be left unused for a prolonged period, then it should be given a thorough clean to remove ash and unburned fuel residues. To enable a good flow of air through the appliance to reduce condensation and subsequent damage, leave the air controls fully open. -
Page 14: Annual Service
Stove Body Annual Service Hunter Stoves Group recommend that this appliance The stove is finished with a heat resistant paint and this be serviced annually, preferably prior to the start of the can be cleaned with a dry microfibre heating season, thus avoiding any delay in receiving cloth or dry soft brush. -
Page 15: Warning Note
Carbon Monoxide (CO) Alarms Hunter Stoves recommend a carbon monoxide (CO) alarm that conforms to BS EN 50291 be installed in the same room as the appliance. See BS EN 50292 and the alarm manufacturer’s instructions for installation guidance. The use of such an alarm is not considered a substitute for regular maintenance or servicing of the appliance and flue system. -
Page 16: Troubleshooting
TROUBLESHOOTING Smoke This can happen for a variety of reasons e.g cold air trapped in chimney/flue. As cold air is denser, this causes smoke to be forced back down the chimney. We recommend trying to heat the chimney before lighting, for example, placing a firelighter on top of the kindling. -
Page 17: Product Fiche & Technical Information- Uk
PRODUCT FICHE - UK In accordance with Regulation (EU) 2015/1186 The information below is valid in the UK in conjunction with the UKCA mark only. Energy Direct Heat Energy Useful Energy Efficiency Indirect Heat Model Efficiency Output, [x.x] Efficiency at Nominal Heat Output, Output, [x.x] kW Class Index, [x]... -
Page 18: Product Fiche & Technical Information- Eu
PRODUCT FICHE - EU In accordance with Regulation (EU) 2015/1186 The information below is valid in the EU in conjunction with the CE mark only. Energy Direct Heat Energy Useful Energy Efficiency Indirect Heat Model Efficiency Output, [x,x] Efficiency at Nominal Heat Output, Output, [x.x] kW Class Index, [x]... -
Page 19: Warranty
WARRANTY Hunter Stoves Group Ltd Extended 5 and 10 year Warranty 2 Year Standard Warranty Any appliance bought through the showroom of an authorised Hunter Stoves Group retailer will automatically be covered by our standard 2-year conditional warranty. However, this standard 2-year warranty can be extended to a 5-year or 10-year conditional warranty dependent on the model type (5 years - Boiler model and Gas models, 10 year - Room heater). - Page 20 Paint and Surface Coverings The paint or surface covering of the appliance will be covered (for 1 years after installation) provided the warranty conditions are met. However, damage due to the following events will not be covered: Damage to the paint surface caused by the appliance being stored in a damp and cold environment is not covered under warranty.
-
Page 21: Servicing Records
Service Records 1st SERVICE 2nd SERVICE Date of service.......... Date of service.......... Date of next service........Date of next service........HETAS Number.......... HETAS Number.......... Signature........... Signature........... 3rd SERVICE 4th SERVICE Date of service.......... Date of service.......... Date of next service........Date of next service........ - Page 22 BRITISH EXCELLENCE 8 EMPEROR WAY EXETER DEVON EX1 3QS INFO@HUNTERSTOVES.CO.UK WWW.HUNTERSTOVES.CO.UK Hunter Stoves reserve the right to change dimensions and procedures described in these instructions at anytime without special notice. Registered address: Hunter Stoves Ltd., Trevilla Park, Slaughterbridge, Camelford, Cornwall, UK, PL32 9TT...
