HyVibe H2 Installation Manual
Hide thumbs
Also See for H2:
- Installation manual (13 pages) ,
- Quick start manual (7 pages) ,
- Upgrade installation manual (6 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for HyVibe H2
Summary of Contents for HyVibe H2
- Page 1 HyVibe H2 Installation Guide...
- Page 2 ● Connecting cables ● Output jack panel ● Actuators ● Piezo sensor ● Eight 2x6mm screws ● 3 fastening clips ● USB C - USB A cable ● HyVibe cut blueprint (link) ● Protection label ● Super Glue (Cyanoacrylate) Confidential...
- Page 3 ~10 seconds to confirm they are attached strongly. Also, make sure that actuators are arranged so the connector cable is on the same side of the guitar where the HyVibe System will be inserted. Confidential...
- Page 4 3. Install piezo sensor If the guitar does not already have an under saddle piezo sensor: Using a 3 mm drill, make a hole for the piezo sensor at the edge of the saddle slot. Insert the sensor from inside the guitar and lay flat in the saddle slot.
- Page 5 4. Choose position for HyVibe System Mark 4 drill spots: place the HyVibe blueprint* in the chosen location, and then indent tiny holes into the wood at each of the four corners of the inner rectangle on the HyVibe blueprint.
- Page 6 5. Cut preamp hole Drill holes in the 4 corners using a 10mm drill. Then use a straightedge and a blade to draw the guidelines for sawing the outside border. Confidential...
- Page 7 6. Cut preamp hole (cont’d) Cut along the 4 traced sides with a saw and then file/sand the inside edges to smooth them out. Confidential...
- Page 8 7. Install output/input/USB panel Locate the position on the bottom of the guitar where you want to install the output jack panel. Tape the stencil/cut outline in this position or use an adhesive label and draw a 18x44mm rectangle. Then, using a 6mm drill, drill the 4 corners.
- Page 9 8. Install output jack panel (cont’d) After drilling the 4 holes cut along the outside border. Remove the stencil, connect cables to the jack panel, insert the panel into the guitar, and screw the housing into the guitar using the screws.
- Page 10 9. Install clips Fasten 2 clips to the inside of the guitar. They will be used to hold the wires in place against the side of the guitar. The piezo sensor cable only needs to be in the last clip since the cable is short.
- Page 11 Bring the cables from the output jack panel, actuators, and piezo through the hole on the side of the guitar. Then connect them to H2 interface. Insert the H2 into the slot as shown in the picture and use the the screws to fasten. Confidential...
- Page 12 11. Fasten wires to clips Put your hand inside the sound hole and affix the wires inside the clips, as shown in this picture. Make sure the wood is clean before you affix the clips to the guitar. Confidential...
