Wall Mount Kit (Optional)

1.Before using wall mount, please read manual of wall mount and following assembly guide.
2.For safety purpose, please purchase wall mount which can bear the LCD TV weight.
3.Following installation instruction is only for your reference.
4.Please consult authorized service personnel for the installation of wall mount.
X4
*Place LCD with facing
downward on flat surface.
Place mounting unit on
the LCD back as figure
and level at holes.
Secure them together
with four screws .And then
tighten them up with
screwdriver(not supplied).
Note:
Please follow the instruction of
removing the
attaching the
on to your LCD TV.
2
6
X
*Secure component base firmly to
the solid cement wall with six
expansive bolt.
08
STAND before
WALLMOUNT
