5" x 8" direct vent termination kit

Advertisement

Quick Links

Installation Instructions
5" x 8" DVP Direct Vent Termination Kit
The information in this instruction manual supersedes the
venting information located in the owners manual shipped
The following termination kits can only be used with
DVP-RVTK Horizontal Kit
1, Termination Cap
1, Firestop, 1" (square)
1, Adjustable Pipe
4, #8 x 1" Screw
4, #8 x 3" Screw
DVP-RVTM Horizontal Termination Cap
4, Termination Caps
4, Firestop, 1" (square)
16, #8 x 1" Screw
16, #8 x 3" Screw
DVP-HVTK Termination Kit
1, Termination Cap
1, Firestop, 1" (square)
1, Firestop, 3" (rectangular)
1, Adjustable Pipe
1, 90° Elbow
8, #8 x 1" Screw
8, #8 x 3" Screw
DVP-HSFTK Flex Horizontal Termination Kit
1, Termination Cap
1, Firestop, 1" (square)
1, Flex Adapter Starter (5" inner /8" outer)
1, Flex Adapter, 5"
1, Flex Adapter, 8"
1, Flex 5" x 48"
1, Flex 8" x 48"
2, Clamp, 5"
2, Clamp, 8"
4, #8 x 1" Screw
24, #10 x 1/2" Self-drilling Screw
4, #8 x 3" Screw
3, Spacer Springs
DVP-TRFK Through the Roof Termination Kit
1, Vertical Termination Cap
1, Storm Collar
1, Rigid Pipe, 2'
1, Flex Adapter Starter (5" inner/8" outer)
1, Flex Adapter, 5"
1, Flex Adapter, 8"
1, Roof Support
2, Clamps, 5"
2, Clamps, 8"
6, Wood Screws, 2"
24, #10 x 1/2" Self-tapping Screws
3, Springs, 8"
1, Spacer
All Vermont Castings Group Direct Vent Fireplaces have
been tested and approved to ANSI / CSA Standards and
will operate safely when installed in accordance with this
installation, then follow these instructions carefully to
Always maintain minimum clearances around vent
sections of this vent system require a minimum of 3"
(76 mm) clearances to combustibles at the top of the
when top venting, the clearance to combustibles is 1" on
horizontal run must have a 1/4" rise for every one (1)
• Any common venting of this gas appliance with other
• Do not connect this appliance to a chimney flue
Failure to follow these instructions may create a possible
CozyCabin.com 518-623-4349
Addendum
CAUTION
WARNING
1
WARNING
WARNING
2
20307393 Rev 1 0315

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP-RVTK and is the answer not in the manual?

Questions and answers

Summary of Contents for Vermont Castings DVP-RVTK

  • Page 1 The information in this instruction manual supersedes the venting information located in the owners manual shipped All Vermont Castings Group Direct Vent Fireplaces have been tested and approved to ANSI / CSA Standards and The following termination kits can only be used with...
  • Page 2: Important Safety Information

    5" x 8" DVP Termination Kit IMPORTANT SAFETY INFORMATION PRE-INSTALLATION INFORMATION • Before You Start • Figure 1 • Tools: • The installation must conform with local codes or in the absence of local codes, with the National Fuel Gas Measuring Tape Electric drill and bits Pliers...
  • Page 3 5" x 8" DVP Termination Kit Assemble Pipe Sections ATTENTION ATTENTION The vent kits described in this manual are tested as part ASSEMBLE DVP VENT SECTIONS WARNING Figure 2 Inner/Outer Risk of Fire/Explosion/Asphyxiation! Improper support supports and connect vent sections per installation DO NOT allow vent to sag below connection together (see Figure 3) and the seams are not aligned Attach the First Vent Component to Starter Collar...
  • Page 4 5" x 8" DVP Termination Kit Assemble Slip Sections Make sure the seams are not aligned to prevent unintention- al disconnection. Slide together to the desired length, making sure that a The pipe and slip section need to be secured by driving two screws through the overlapping portions of the outer CORRECT INCORRECT...
  • Page 5: Install Horizontal Termination Cap

    5" x 8" DVP Termination Kit Secure the Vent Sections WARNING Risk of Fire/Explosion/Asphyxiation! Improper support supports and connect vent sections per installation Figure 9 Rotate Seams for Disassembly Figure 7 Securing Vertical Pipe Sections Figure 10 Align and Disassemble Vent Sections INSTALL HORIZONTAL TERMINATION CAP WARNING Risk of Fire! The telescoping flue section of the...
  • Page 6 5" x 8" DVP Termination Kit Secure termination cap to exterior wall using provided Flash and seal as appropriate for siding material at outside Install gutter When installing a horizontal termination cap, follow the cap Divert Roof Run-off is possible, use of one of the two options shown below to prevent water running off the roof and onto/into the Install L-shaped diverter...
  • Page 7 DVP6A is slid over the DVP6 to make an adjustable only the DVP6 (for instances in which the adjust- NOTE: You may use the DVP-RVTK OR DVP-RVTM for corner installations. You may also use the DVP45M off the rear of the unit witha 45° elbow (p/n 1245) and proper length of pipe(s).
  • Page 8: Horizontal Termination Kit

    5" x 8" DVP Termination Kit WARNING minimum and maximum venting requirements of your WARNING Any horizontal run must have a 1/4" rise for every one Vinyl Siding Wall Termination Cap WARNING Figure 13 Horizontal Termination Cap on a Vinyl Siding Wall Termination cap must be positioned so the embossed DVP-HSFTK - HORIZONTAL TERMINATION KIT...
  • Page 9 5" x 8" DVP Termination Kit (1) large band clamp and three (3) self tapping #10 the slip section for the termination cap using three (3) the slip section for the termination cap using three (3) adapter on the slip section of the termination cap pipe from touching each other and should be placed Figure 15 - DVP-HSFTK Side View...
  • Page 10 5" x 8" DVP Termination Kit VERTICAL THROUGH-ROOF FLEX Secure Screws Flex Vent VENTING (3 Places Equidistant Just Above Gear Clamp) venting application where rigid direct vent components All restrictions, clearances and 2" Flexible Pipe allowances that pertain to the rigid piping apply to Flex kits may be added to the end of a vent run made Flex Adapter Gear Clamps...
  • Page 11: Install The Ceiling Firestop

    5" x 8" DVP Termination Kit N O TE : Fl ex ve n t p ip e sp a ce r s : R e fe r to manufacturer ’s specifications for cor rect positioning of the spacer springs to maintain proper distance between inside and outside pipe.
  • Page 12: Flat Ceiling Installation

    5" x 8" DVP Termination Kit Roof Support Flat Ceiling Installation Figure 21. Note: Cut previously installed batt insulation to make Ensure that the termination pipe is centered and has a minimum of 1" clearance on all sides from • Wrap shield around pipe if pipe is already installed in Figure 22 •...
  • Page 13: Assemble And Install Storm Collar

    5" x 8" DVP Termination Kit Install Roof Flashing For installation of vertical termination cap see minimum Horizontal overhang Pipe 20 in. Caulk 24 in. min. (508 mm) (610 mm) Vertical Lowest wall Discharge Opening Termination Storm Collar Roof Flashing Roof Pitch is X / 12 H (min.) - Minimum height...
  • Page 14: Install Vertical Termination Cap

    5" x 8" DVP Termination Kit Install Vertical Termination Cap Attaching Flexible Venting to Vertical To attach the vertical termination cap, slide the inner col- Termination Kit Secure the cap by driving the three self-tapping screws (supplied) through the pilot holes or dimples in the outer Termination Cap (1 of 3) Storm...
  • Page 15 5" x 8" DVP Termination Kit Termination Storm Collar Roof Support Rigid Pipe Flashing Refer to Figures 5 & 6 Rigid Pipe Secure Screws (3 Places Equidistant Flex Adapter Just Above Gear Clamp) Flex Adapter Inner Gear Flex Adapter 2" Flexible Pipe Clamp Flex Adapter Inner...
  • Page 16 149 Cleveland Drive • Paris, Kentucky 40361 CozyCabin.com 518-623-4349...
