Table of Contents

Ranger 305G
Troubleshooting Guide
Prior to attempting any troubleshooting procedures, please see important safety
Refer to this unit's operators manual for proper Installation and Input power
requirements.
If for any reason you do not understand the test procedures or are unable to perform the
test/repairs safely please contact Lincoln electric call center at 1-888-935-3877
SYSTEM CONFIGURATION
Place the machine into the following configuration prior to performing any
troubleshooting procedures
1. Check all circuit breakers are
not tripped before proceeding
to tests.
2. Refer to Operator's Manual for
guidances on machine
operation.
3. Set Run/ Stop to Run then, Idle
switch to High Idle, pull out
choke.
4. Then press the start button.
5. Set mode to CC Stick, and Weld
Terminals ON.
Publication | Issue D ate 04/23
Lincoln Global, Inc. All Rights Reserved.
information starting on page 19.
THE LINCOLN ELECTRIC COMPANY
22801 St. Clair Avenue • Cleveland, OH 44117-1199 • U.S.A.
PH: +1.888-935-3877 • www.lincolnelectric.com
