Lincoln Electric Ranger 305G Technical Specifications

Ranger
®
300 Amp DC Gasoline Engine
Driven Welder
The Ranger ® 305G is a powerful stick, TIG, wire and pipe welding
engine driven welder that is ready for all day, everyday performance.
Rugged and dependable, the Ranger
enclosed case for maximum protection; Lincoln's
Technology™ for an arc operators appreciate; and a 12 gallon fuel tank
that will last you through the entire day. Lincoln's Ranger
it's ready for a workout.
Processes
Stick, TIG, MIG, Flux-Cored, Gouging
Advantage Lincoln
• Gasoline Engine-Driven Welder
- A powerful 300 amp DC CC/CV gasoline engine-driven welder. All
rated outputs at 100% duty cycle 104°F (40°C).
- Only compact gasoline welder in N. America rated at 29V for 300
amps of stick welding.
• 23 HP Kohler ® Gasoline Engine
- Increase from 22 HP to 23 HP for plenty of engine horsepower.
- 2-cylinder, 4-cycle OHV (overhead valve) air-cooled.
• Multi-Process Welding
- Excellent DC multi-process welding for general purpose stick,
downhill pipe (stick), TIG, cored-wire, MIG (CO 2 and blended gas)
and arc gouging.
• Digital Weld Meters
- Digital weld meters for amps and volts makes it easy to precisely
pre-set your procedures and monitor actual welding output.
• Superior Arc Performance
- Lincoln's Chopper Technology provides easy starts, a smooth
arc, low spatter and excellent bead appearance.
Product Rated Output
Name Current/Voltage/Duty Cycle
Ranger 305G 305A DC CC/29V/100%
300A DC CV/29V/100%
305G
® 305G is built with a totally
Chopper
® 305G ...
TECHNICAL SPECIFICATIONS
Output
Range
20-305A DC
40-300A Pipe
20-250A DC TIG
14-29V CV
10,500 watts peak
9,500 watts continuous
• 10,500 Watts Peak Single-Phase AC Generator Power
- 10,500 watts peak for motor starting. 500 watts more!
- 9,500 watts contiuous for high capacity needs such as a back-up
generator, powering a Pro-Cut
inverter welder. Also for lights, a grinder or other power tools.
• Skewed Rotor Design
- Skewed rotor design provides AC power suitable for operating
Lincoln Pro-Cut ® plasma cutters and inverter power sources.
Lincoln was first in the welding industry with this feature.
• Choice of Mechanical or Electric Fuel Pump
- Mechanical for most environments.
- Electric for high altitude operation.
• One-Pak ® Package
- Convenient way to order a welding system. See inside.
• Three-Year Warranty
- Three-year Lincoln warranty (parts and labor) on welder.
(Engine is warranted separately by the engine manufacturer).
No. HP &
Engine of Speed
Model Cyl. (rpm)
Kohler OHV Command 2 23 @ 3600
CH23S Gasoline
Choice of Mechanical
or Electric Fuel Pump
ENGINE DRIVEN WELDERS
® plasma cutter or an Invertec
Dimensions Net
H x W x D Weight
inches (mm) lbs. (kg)
36.2 x 21.5 x 42.3 510
(920 x 546 x 1073) (231)
