QUICK START
GUIDE
G SERIES
ACTIVE & HITECH
EN - GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Valtra G Series

Summary of Contents for Valtra G Series

  • Page 1 QUICK START GUIDE G SERIES ACTIVE & HITECH EN - GB...
  • Page 2 ACTIVE & HITECH This quick start guide offers simple tips for getting the most out of your Valtra G Series tractor. Please note that this is NOT an operator’s manual. Before operating the tractor, it is important that you read the operator’s manual with all safety points.

  • Page 3: Table Of Contents

    YOUR Valtra ARM explanation ........4 Side panel & Side panel connectors ....5 A-B-C-D four speed ranges ......6 How to select speed range ......7 How to select Powershift gear .......8 Driving with gear lever........9 Auto shift ............10 Features ............12 AutoTraction .............13 HillHold ..............14...

  • Page 4: Valtra Arm Explanation

    G Series Quick Start Guide / Active & HiTech VALTRA ARM & SIDE PANEL DRIVER’S ARMREST Front hydraulics on/off button Button for hydraulic implement locking Button for SoftDrive Changeover button for front lift / front loader Joystick Hand throttle Gear lever...

  • Page 5: Side Panel & Side Panel Connectors

    G Series Quick Start Guide / Active & HiTech SIDE PANEL SIDE PANEL CONNECTORS Three –pin current socket (25A) – standard equipment Control lever for auxiliary hydraulic valve 1 and 2 (STD) Control lever for auxiliary hydraulic valve 3 (option)

  • Page 6: A-B-C-D Four Speed Ranges

    G Series Quick Start Guide / Active & HiTech A-B-C-D FOUR SPEED RANGES Four speed ranges – less strain = increased efficiency. With a choice of speed ranges YOU can set the transmission to work as effectively as possible, cutting fuel usage and increasing component life.

  • Page 7: How To Select Speed Range

    G Series Quick Start Guide / Active & HiTech HOW TO SELECT SPEED RANGE Selecting the correct speed range for the task means that the tractor will perform best of its ability. TO CHANGE RANGE Simply push + or - button located on gear lever or use the lower rocker switch on the basic handle.

  • Page 8: How To Select Powershift Gear

    G Series Quick Start Guide / Active & HiTech HOW TO SELECT POWERSHIFT GEAR To change the Powershift gear in manual mode (move gear lever to the left position) simply push the gear lever forward to increase the Powershift gear or backward to decrease the Powershift gear.

  • Page 9: Driving With Gear Lever

    G Series Quick Start Guide / Active & HiTech DRIVING WITH GEAR LEVER DRIVING VALTRA HITECH AND ACTIVE IS EXTREMELY EASY Start the engine with the clutch pedal depressed and release the clutch pedal. Select the desired range (C-range is default).

  • Page 10: Auto Shift

    G Series Quick Start Guide / Active & HiTech AUTO-SHIFT (AUTO-1) This feature let the tractor manage the gear changes within a range, or if B C and/or C D automatics activated, between A1 or C1 and D6, including changing the range automatically when required. From C to B the change is always manual.
  • Page 11 G Series Quick Start Guide / Active & HiTech AUTO-SHIFT (AUTO-2) SETTING AUTO-2 Push on dash control panel once Push to get to AUTO 2 screen Press to get on right line to adjust, press OK Set with to adjust the engine RPM for gear change...

  • Page 12: Features

    G Series Quick Start Guide / Active & HiTech FEATURES POWERSHIFT REVOLUTION Your Valtra tractor is packed with features to make your working day easier… LIMITING MAX. POWERSHIFT GEAR Limit max desired powershift gear with the push button next to the gear lever.

  • Page 13: Autotraction

    G Series Quick Start Guide / Active & HiTech POWERSHIFT REVOLUTION AUTOTRACTION STANDARD FEATURE Standard AutoTraction - a feature that revolutionizes the driving of a powershift tractor. With a Active or HiTech tractor you need the clutch pedal only when starting the engine. Otherwise you need only brakes and drive pedal for controlling the tractor.

  • Page 14: Hillhold

    G Series Quick Start Guide / Active & HiTech POWERSHIFT REVOLUTION HILLHOLD STANDARD FEATURE The new HillHold function is a standard feature in Active and HiTech tractors. With this function you don’t have to keep the brakes pressed down when the tractor is standing still in up- or downhill, for example when waiting for turn in a junction.

  • Page 15: Ecopower Mode

    G Series Quick Start Guide / Active & HiTech ECOPOWER-MODE Only on G125 models ECO mode is designed especially for work that requires high torque, but not constant engine revs e.g. pulling work on the field. With EcoPower the tractor will give highest torque already at very low engine revs.

  • Page 16: Cruise Control

    G Series Quick Start Guide / Active & HiTech CRUISE CONTROL Traditionally most drivers have used the hand throttle to hold a steady speed, especially on the road. Cruise disengages automatically when clutch or brakes are depressed. NOTE There are two independent memory slots, e.g.

  • Page 17: Engine Rpm Cruise

    G Series Quick Start Guide / Active & HiTech ENGINE RPM CRUISE Valtra Active and HiTech have cruise control also for engine RPM that will keep engine RPM constant regardless of speed. Engine RPM cruise can be stored whilst stationary or moving.

  • Page 18: Hydraulics - Rear Valves

    G Series Quick Start Guide / Active & HiTech HYDRAULICS REAR VALVES In HiTech you have Open Centre and in Active In tractors with three rear valves, there is a flow Load Sensing hydraulics, both with mechanically control knob in the rear controlled rear valves.

  • Page 19: Optional Front Hydraulic

    G Series Quick Start Guide / Active & HiTech OPTIONAL FRONT HYDRAULICS You can use Joystick to control front loader or front lift operations Every time tractor is turned on, the spools must also be turned on using the ON/OFF button located on the left side of the joystick.

  • Page 20: Hydraulics - Front Valve Operations

    G Series Quick Start Guide / Active & HiTech HYDRAULICS FRONT VALVE OPERATIONS FRONT LOADER With Joystick you can use front loader beam (A) and loader implement tilt (B) functions If live 3 is selected, use the “trigger” (C) to control live 3 function...

  • Page 21: Front Loader Work

    Select the desired range (B or C recommended). Move the shuttle to the forward/reverse position to initiate drive. Activate hydraulics (with Valtra ARM). Activate hydraulic assistant from dahsboard hydraulic setting menu Adjust/limit hydraulic flow from dashboard setting menu if needed...

  • Page 22: Hydraulic Assistant

    G Series Quick Start Guide / Active & HiTech HYDRAULIC ASSISTANT BOOSTING YOUR FRONT LOADER USE Valtra is the first Powershift tractor in the world with patented hydraulic assistant! Engine revs are rising when hydraulic flow is required from front valves (electric valves), even when driving - without affecting the ground speed.

  • Page 23: Pto

    G Series Quick Start Guide / Active & HiTech The rear PTO can have 2 or 3 speeds and in addition optional Ground Speed PTO. Before using PTO: it is important that you study first the safety guidelines from Users Manual!

  • Page 24: Pto Tips

    G Series Quick Start Guide / Active & HiTech PTO TIPS STATIONARY MODE OF THE PTO You can engage the stationary mode of the PTO and it then operates even when you are not on the operator’s seat. Park the tractor and apply the parking brake.

  • Page 25: Rear Controls And Connections

    G Series Quick Start Guide / Active & HiTech REAR CONTROLS AND CONNECTIONS 2-line trailer air brake couplings (option)* Valve to isolate the front hydraulics from valve 2 (option) Power Beyond couplings (Active only, option) ISOBUS connector (option) Compressed air outlet (option)

  • Page 26: Pick-Up Hitch

    G Series Quick Start Guide / Active & HiTech PICK-UP HITCH UNLATCH THE PICK-UP HITCH PROCEDURE Push the top side of the lifting/lowering switch to fully lift the linkage. To unlatch the hitch, pull the hitch release lever and at the same time push the bottom side of the lifting/lowering switch.

  • Page 27: Pulling Work On The Field

    G Series Quick Start Guide / Active & HiTech PULLING WORK ON THE FIELD HIGH NEED FOR POWER, LOWER SPEED Start the engine. Select the B range using the + and – buttons. Switch 4WD ON (symbol side position) and set differential lock to AUTO.

  • Page 28: Transport On The Road

    Switch 4WD to OFF when driving on the road (slippery conditions: keep 4WD on all time) Optional: Set speed cruise when moving (with Valtra ARM). Optional: Set Auto-1 by moving to right position if you want tractor to manage Powershift changes automatically between C1-D6.

  • Page 29: Pto Work Auto 1

    PTO WORK AUTO 1 PTO USE – HIGH POWER NEEDED – MEDIUM/HIGH SPEEDS Start the engine. Select range B or C. Select PTO speed and start PTO. Set the right PTO speed and put it into the Engine RPM memory with a push longer than 2 seconds. Select driving direction using the shuttle lever.

  • Page 30: Grease Points

    G Series Quick Start Guide / Active & HiTech GREASE POINTS 50h /weekly Every 500h Support points...

  • Page 31: Daily Checks

    G Series Quick Start Guide / Active & HiTech DAILY CHECKS Before starting the daily work, make sure that the following daily maintenance checks are done. Check the engine oil level. Check the coolant level (under hood). Check the radiators and if necessary, clean them throw openings (via latches under hood, both sides).

  • Page 32: Tips

    HillHold This feature is for operation in varying conditions, Valtra offers a standard HillHold feature. The hill-hold assist helps to prevent the tractor from going backwards unintentionally when starting on steep slopes.
  • Page 33 Load-sensing hydraulics in Active models increase effectivity of working with implements + By offering just the needed amount of oil and pressure through the valve, fuel consumption decreases and the need for cooling the oil is smaller. + Load-sensing hydraulic system enables several functions to be used simultaneously while maintaining stable hydraulic oil output regardless of the engine revs.

  • Page 34: Instrument Cluster & Setting Menus

    G Series Quick Start Guide / Active & HiTech INSTRUMENT SETTING MENUS CLUSTER Here an overview of different settings (HiTech, Active). Left dash is a real information and setting centre in HiTech and Active models. Drive Display shows all transmission functions...

  • Page 35: Settings And Operations

    G Series Quick Start Guide / Active & HiTech SETTINGS AND OPERATIONS Active regeneration - used usually Terminal settings like brightness Information about: Service codes: Use Valtra Connect only before engine oil change. Will • Voltage for further info! signal light be lit - see user manual •...
  • Page 36 Valtra Inc. brand of AGCO Valmetinkatu 2 Tel. +358 (0)2045 501 FI-44200 Suolahti www.valtra.com...
