SUMMARY FOR USERS ……………………………………………………………………....P.3-P.10 GENERAL INFORMATION 1.1. Name of Parts 1.2. Accessory list 1.3. Dimension OPERATION 2.1. Instruction for Controller TECHNICAL SPECIFICATION FOR INSTALLERS AND PROFESSIONALS …………………………………….. P.11-P.27 Installation and Maintenance 1.1. Notice before installation 1.2. Instruction 1.3. Trail after Installation 1.4.
Warning: a. Please read the following tips before installation, use and maintenance. b. Installation, removal and maintenance must be carried out by Professionals in accordance with the instructions. c. Gas leakage test must be done before and after installation. 1. Use a.
d. Installation must be stopped if any R32 gas leakage, and the unit must be returned to professional maintenance center. 3. Transportation and Storage a. Sealing is not allowed during transportation b. Transporting goods at a constant speed is needed to avoid sudden acceleration or sudden braking, so as to reduce the collision of goods.
FOR USER 1. GENERAL INFORMATION 1.1. Name of Parts Name Controller Feet Air Outlet Air Inlet (on the bottom) Hanging Strip on Wall Filter and filter bracket...
FOR USER 1.2. Accessory list Padx3,Feetx4,Drain-pipe x1(2m),Hanging Stripx1,Manual 1.3. Dimension Size(mm) Name Model IDHR60 IDHR96 1120 1054 IDHR120 1220 1154...
FOR USER 2. OPERATION 2.1. Instruction for Controller SYMBOL DESIGNATION FUNCTION ON/OFF Press to power on or off the dehumidifier For dehumidifier with dehumidifying function only, press Mode “ ” to select Smart /Silence mode. Timer Press to set the time to switch on and off Up and Down Adjust the value of the required parameters Dehumidifying mode...
Page 9
FOR USER Wi-Fi connection Air temperature Humidity Mode Timer 1. When the dehumidifier it’s on, press any button to light the keyboard and operate it. When it’s off, press to light the keyboard and operate it. Mode Button Dehumidifying Function only: Press one time,it can transfer mode.
Page 10
FOR USER (2) Timer OFF setting: When the dehumidifier is on or off, press the to enter the timer setting; Meanwhile, the symbol light and the are flashing. Press two times to enter the Timer OFF setting, the is flashing, you can adjust the hour setting by pressing the , then press again the , then you can adjust the...
Page 11
FOR USER 6. Advanced application (for professional technician’s operating only) 6.1. Running status checking (1) Press for 5 seconds to enter into “Running status checking”, the screen alternately shows status point “C0” and its corresponding value. (2) Check all status points and their corresponding value through , Press to quit “running status checking”...
FOR USER 6.4. Parameter list Content Adjust range Step length Heating function 0 — no / 1 — yes 0: Reach temp/humidity to low speed Fan running mode 1: Reach temp/humidity stop Compressor continuously running time 20 ~ 90min 1min before defrosting mode Defrosting start temp -10 ~ 10°C...
FOR INSTALLERS AND PROFESSIONALS Installation and Maintenance This product must be installed by a professional team. The users are not qualified to install by themselves, otherwise the dehumidifier might be damaged and risky for users’ safety. 1.1. Notice before installation The product is only used for dehumidification of the swimming pool and must ensure sufficient air circulation, otherwise the dehumidification function will be ineffective or have little effect.
Page 15
FOR INSTALLERS AND PROFESSIONALS 1.1.6. It is strictly forbidden to use or store flammable gases or liquids such as hair spray, paint, gasoline, etc. near the dehumidifier, otherwise a fire may occur. 1.1.7. If any abnormal conditions such as abnormal noise, odour, smoke, leakage, etc., are found, the power should be cut off immediately and contact the local dealer, and do not repair the equipment yourself.
FOR INSTALLERS AND PROFESSIONALS 1.1.10. Do not wash the equipment directly with water. 1.2. Instruction This product should be installed in a well-ventilated place 1.2.1. Installation (1) The dehumidifier may be placed on the ground or installed on the wall; (2) When installing on the wall, be sure to use M6 pull-out screws to fix the bracket, the concrete foundation of the selected wall should be firm and strong, and the bracket should be strong enough and rust-proof;...
Page 17
FOR INSTALLERS AND PROFESSIONALS the bottom board, please pay attention; put the drainage kit firmly into the drain hole of the bottom board, and then connect the drain pipe to drain away the condensed water smoothly. Steps to install the foot and place it on the ground: 1.
Page 18
FOR INSTALLERS AND PROFESSIONALS Steps of installation on the wall: 1. On the appropriate wall, mount the bracket to the wall by attaching five φ6mm pull- out screws to the holes in the wall bracket. 2. Place the pad on the wall-mounting platform behind the equipment 3.
Page 19
FOR INSTALLERS AND PROFESSIONALS After hanging the bracket, gently put the equipment until the pad of the bottom rests against the wall.
Page 20
FOR INSTALLERS AND PROFESSIONALS 4. Connect the drain pipe, and connect the power cord according to the wiring diagram A: Power cord; B: Drain outlet (connect the drain pipes) 1.2.2. Electrical installation wiring (1) Connect to appropriate power supply, the voltage should comply with the rated voltage of the products.
FOR INSTALLERS AND PROFESSIONALS Electric wiring diagram Power Supply 230V/50Hz Model IDHR60 IDHR96 IDHR120 Rated current (A) 10.0 12.0 Breaker Rated residual Action Current (mA) Max input current (A) Fuse (A) 10.0 12.0 Power cord (mm 3x1.5 3x2.5 3x2.5 Note: Above date is adapted to power cord ≤10m.If power cord ≥10m, wire diameter must be increased.
FOR INSTALLERS AND PROFESSIONALS 1.4. Daily Maintenance Notice The maintenance should be carried out per year by qualified professional technician. Cut off power supply of the dehumidifier before inspection; Please cut off the power supply when not be used, and cover the plastic sheet use the cloth to prevent dust from entering.
FOR INSTALLERS AND PROFESSIONALS 3. FAILURE CODE Failure Code High pressure protection Low pressure protection Abnormal power supply voltage protection Electric heating overheating protection (manual reset thermostat) Exhaust high temp protection Air out high temp protection Environmental low temp protection Controller failure Air inlet temperature sensor failure Air outlet temperature sensor failure...
FOR INSTALLERS AND PROFESSIONALS 4. Wi-Fi Setting 4.1. APP Download Android Mobile please download from iPhone please download from 4.2. Account registration a) Registration by Cell phone number/Email...
Page 25
FOR INSTALLERS AND PROFESSIONALS b) Cell phone number registration 4.3. Create family Please set a name for the family and choose the room of the device.
Page 26
FOR INSTALLERS AND PROFESSIONALS 4.4. Three methods of device binding Please connect your phone to the Wi-Fi network first. 4.4.1. Auto Discovery (Bluetooth) a) Please make sure the Bluetooth function is enabled on your phone. b) When switched on, tap any key to wake up the controller, then press for 3 seconds, and will be flashing rapidly to enter Wi-Fi binding status.
Page 27
FOR INSTALLERS AND PROFESSIONALS 4.4.2. EZ Mode (Easy-connect) a) Activate the Wi-Fi module b) When switched on, tap any key to wake up the controller, then press for 3 seconds, and will be flashing rapidly to enter Wi-Fi binding status. c) Click "Add device", and follow the instructions below to finish binding.
Page 28
FOR INSTALLERS AND PROFESSIONALS 4.4.3. AP Mode Activate Wi-Fi module a) When switched on, tap any key to wake up the controller, then press for 10 seconds, and will be flashing slowly to enter Wi-Fi binding status. b) Click "Add device", and follow the instructions below to finish binding. display on the screen once the Wi-Fi connection success.
Page 29
FOR INSTALLERS AND PROFESSIONALS 4.5. Operation instructions The following instructions are for dehumidifiers without an electrical heater. Device name More Share device Temp Unit Indoor Current Temp Indoor Current Humidity Set Humidity Value Humidity Adjustment Slider ON/OFF Select Smart/Silence Mode Dehumidify...
Page 30
FOR INSTALLERS AND PROFESSIONALS 4.6. Share devices with your family members After binding, if your family members also want to control the device. Please let your family members register the APP first, and then the administrator can operate as below (The following pictures are for reference only): Then your family members will see this heat pump once they log in to the APP.
Page 32
The factory reserves the final interpretation right. And keep the right to stop or change product specification and design without prior notice at any time, no need to bear the resulting obligations. Version:Gk10Ir32-1...
