OzSpy DSIENHANCELNW User Manual

5. Never use the antenna of this device to touch a metal surface or the antenna of
signal emission source. The quality warranty does not include the damage caused
by static electricity or feedback.
DISTINGUISH THE SIGNAL TYPE
This device can help user to distinguish the signal type: analog signal LED light up,
digital signal LED blinking.
1. Analog signal: Wireless bug, Video wireless camera, 2-way radio, 3G / 4G phone
2. Digital signal: WiFi, IP camera, Digital wireless camera, 2G phone, etc.
SPECIFICATION
* Specification may change without notice.
Detecting range 50 MHz - 6.0 GHz
Dimension L 14 x W 7 x T 2.5 cm
Weight About 200g
1. 12V DC 1A switching power adaptor
Power
2. Rechargeable battery AAA/UM-4 x 4
1. Beep alarm sound
2. LED indication
Warning mode
3. Vibration
4. Earphone silent detection
1. Adjust detecting distance to find signal source
Sensitivity Tuner
2. Eliminate the environment interference
1. 100mW
2. GSM phone: up to 4 meters
3. Smartphone (4G, 5G: 3300~3700MHz) : up to 4 meters
Detecting Distance
4. 3G 2100: up to 1.2 meters
5. Camera lens: up to 5 meters
6. 2.4G WiFi IP hidden
* The detecting distance will be varied depending on the type and strength of signal sources.
WARNING
Use this device as an auxiliary, supplemental help or aid to prevent the risks caused by hidden
camera, cellular phone or other wireless devices. This device does not take the place of all the
supervisions. Performance of this Radio frequency (RF) product will be affected by the circumstance
of use. The producer and marketing group accepts no liability for any loss or damage by malfunction
or misuse.
COPYRIGHT
All rights are reserved. The manufacturer may further revise this manual from time to time without
prior notice.
©Copyright 2023, All rights reserved.
4
2.4GHz Wireless camera: up to 6 meters
camera: up to 2.2 meters
Made in Taiwan
08.2019
RF Signal Detector with Auto Benchmark
Digital Sensitivity Tuner + Digit Sensitive Level Indication
Efficient Detect 2.4G WiFi IP hidden Camera
Thank you for purchasing this device. Please first read over this manual for proper
use, save this manual and keep it handy.
GENERAL
This device applies with fuzzy scanning
technology to detect spy cameras, bugs,
cellular phones and other radio frequency
devices. This device surely avoids being
peeping or tapping to protect privacy or
protect information being disclosed
secretly.
This device applies digit (numeric) display
to show the sensitivity level. With up (▲)
and down (▼) buttons, user knows the
sensitivity setting directly.
Every time this device is switched on, it
will stay at factory default benchmark of
Level 6. User will not have problem in
sensitivity setting of too high or too low.
Press the UP or DOWN button in right side of this device, leave only the very left
LED going Green and no alarm go off, this is the suitable benchmark.
HOW TO OPERATE
1. Pull out the antenna and turn on the power. The very left Green LED will light up
and the 7-segment LED at central of front side will display from digit 8 to 0 and
then stay at 6 (Level 6) as power on self-test.
2. If the environment has higher background noise, some of the LEDs will light up
and the alarm of this device will beep.
3. Press once the DOWN button in the side of this device, the digit display will show
5. If the LEDs put out and leave only the very left LED going Green and no beep
or vibration, this is the suitable benchmark.
DSIENHANCELNW
User's Manual
1
