tacwise C9725V Operator's Manual page 6

One-year standard tool warranty
Should your Tacwise air tool become defective due to faulty materials or workmanship within 12 months from the date of purchase, we guarantee to replace all
defective parts free of charge or at our discretion, replace the tool entirely. However, this one-year warranty does not cover any consumable parts such as
drivers, O-rings, springs etc.
6-month standard consumable parts warranty
Tacwise air tools are warranted to be free from defects with all its original consumable parts for 6-months from the date of purchase.
Neither of these warranties cover:
• Tools that have received unauthorised changes or additions.
• Defects caused by using accessories, components or spare parts other than approved/genuine Tacwise accessories or parts.
• Component parts that are subject to natural wear and tear caused by use in accordance with our operating instructions.
• Defects to the tool caused by improper use, abnormal environmental conditions or inappropriate operating conditions, non-compliance with our operating
instructions or insufficient servicing or maintenance.
• Proof of purchase must be produced with an original receipt.
Operating Instructions
Technical data
Characteristics
Model
Staple type
Staple length range
Magazine capacity
Minimum operating air pressure
Maximum operating air pressure
Air inlet
Air consumption
Weight
Vibration emission level*
* The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission may differ. This may significantly increase exposure level over the total working period.
CE – Declaration of Conformity
C9725V
Tacwise declares that this power tool has been designed in compliance with the Regulations and Standards of the European Directives.
Quality Department, Tacwise Group Plc – UK
Features (Fig. A)
1. Trigger
2. Quick-release plug (Euro fitting)
3. Magazine release lever
4. Magazine
5. Quick-release nose gate
6. Safety contact nose
7. Air deflector
Set up
Your air tool is fully assembled when you receive it. Before using it, attach the air line and desired air system accessories. See Fig. B for the recommended
accessories and connection order. Be sure the air hose is de-pressurised when installing or removing adaptors to the air line.
Connecting the tool to an air supply (Fig. B)
• Determine if the tool needs oil and, if necessary, place two drops of oil in the air plug as shown in Fig. B. If you are using an automatic in-line oiler, check and
add oil if necessary.
• Turn the compressor on and set the regulator to the proper pressure for the size and type of fastener being used.
• Connect the tool to the air supply.
Loading the fasteners (Fig. C)
• Depress the magazine release lever situated at the back of the magazine.
• Pull the moveable magazine out.
• Place a strip of staples over the rail of the magazine channel.
• Slide the magazine shut until the magazine release lever clicks.
NOTE: We strongly recommend that you only use approved/genuine Tacwise fasteners.
Operating the tool
• Connect the tool to the air supply. Make sure the air pressure is in correct range denoted in section of Technical data.
• Load fasteners as directed in the section called Loading the fasteners.
• Hold the body of the tool and press the nose to the work surface, be sure the tool is straight and then gently depress the trigger to drive the fastener.
• Lift the tool off the work surface.
Firing mode
Contact trip (Bump fire):
• Depress the trigger and whilst holding the trigger squeezed, repeatedly impact the nose piece on the work surface.
• The tool will drive one fastener each time the nose is impacted.
FASTENING TOOLS FOR THE PROFESSIONAL
Value
C9725V
Tacwise 97 series staples
10mm (3/8") – 25mm (1")
125
60psi / 4.14 bar
100psi / 6.89 bar
1/4" NPT
1.7 CFM @ 90psi / 6.20 bar
1.2kg (2.6lbs)
1.9m/s 2
6
