Summary of Contents for Beko WMY 1214441
- Page 1 Washing Machine User Manual WMY 1214441 Document Number= 2820524460/ 26-01-17.(13:10)
- Page 2 This product was manufactured using the latest technology in environmentally friendly conditions.
-
Page 3: General Safety Instructions
General safety instructions This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 Life and property safety Never place the product on a carpet-covered floor. Electrical parts will get overheated since air cannot circulate from under the device. -
Page 4: Electrical Safety
Do not forget to close the loading door when leaving the room where the product is located. store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package. -
Page 5: Important Instructions For Environment
Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 6: Technical Specifications
Technical specifications Supplier name or trademark Beko Model name WMY 1214441 Rated capacity (kg) Maximum spin speed (rpm) 1400 Height (cm) Width (cm) Depth (cm) 62.5 Net weight (±4 kg.) Single Water inlet / Double Water inlet • / - •... -
Page 7: Appropriate Installation Location
4.1 Installation • Apply to the nearest authorized service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures. • Make sure that the installation and electrical connections of the product are performed by authorized service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorized persons. -
Page 8: Connecting Water Supply
4.1.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher. If you are going to use the double water-inlet product as a single (cold) water-inlet unit, you must install the supplied stopper to the hot water valve before operating the product. (Applies for the products supplied with a blind stopper group.) CAUTION: Models with a single water inlet should not be connected to the hot water tap. -
Page 9: Adjusting The Feet
4.1.6 Adjusting the feet CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems. -
Page 10: Preparing Laundry For Washing
4.2 Preparation 4.2.1 Sorting the laundry * Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always obey the instructions given on the garment tags. 4.2.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine. -
Page 11: Using Detergent And Softener
4.2.6 Using detergent and softener When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's instructions written on the package and follow the dosages specified. Use measuring cup if available. The detergent drawer is composed of three compartments: – (1) for prewash – (2) for main wash – (3) for softener... - Page 12 Using softeners Pour the softener into the softener compartment of the detergent drawer. • Do not exceed the (>max<) level sign on the softener compartment. • If the softener has lost its fluidity, dilute it with water before putting it in the detergent drawer. Using liquid detergents If the product contains a liquid detergent cup: • Put the liquid detergent container into the compartment no “2”. • If the liquid detergent lost its fluidity, dilute it with water before putting it into the detergent container.
-
Page 13: Tips For Efficient Washing
4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature range temperature range based temperature range range based on soiling level: based on soiling level: cold -40 on soiling level: cold based on soiling 40-90 level: cold -30... -
Page 14: Operating The Product
4.3 Operating the product 4.3.1 Control panel 1 - Programme Selection knob 6 - On / Off button 2 - Spin speed adjustment button 7 - Start / Pause button 3 - Temperature Adjustment button 8 - End Time Setting button 4 - Display 9 - Auxiliary Function buttons 5 - Program Follow-up indicator... -
Page 15: Programme And Consumption Table
4.3.3 Programme and consumption table Selectable temperature Programme range °C 2.70 1600 • • • 90-Cold Cottons 1.75 1600 • • • 90-Cold 1.00 1600 • • • 90-Cold Cottons Eco 60** 1.30 1600 60-Cold Babyprotect Mini 0.50 1400 90-60 1.04 1200 •... -
Page 16: Programme Selection
4.3.4 Programme selection 1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with the "Programme and consumption table". Programmes are limited with the highest spin speed appropriate for that particular type of fabric. When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature. - Page 17 • Woollens You can wash your woolen laundry that can be washed in machine in this programme. Wash your clothes by selecting the appropriate temperature complying with the tags of your clothes. It is recommended to use suitable detergent for woolens. “The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool garments labelled as „hand wash“...
-
Page 18: Temperature Selection
4.3.6 Temperature selection Whenever a new programme is selected, the recommended temperature for the programme appears on the temperature indicator. It is possible that the recommended temperature value is not the maximum temperature that can be selected for the current programme. 88:88 1888 Press the Temperature Adjustment button to change the temperature. -
Page 19: Auxiliary Function Selection
Rinse Hold If you are not going to unload your clothes immediately after the programme completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine. Press Start / Pause button after this process if you want to drain the water without spinning your laundry. -
Page 20: Starting The Programme
4.3.9 End Time With the End Time function, the startup of the programme may be delayed up to 24 hours. After pressing End Time button, the programme's estimated ending time is displayed. If the End Time is adjusted, End Time indicator is illuminated. -
Page 21: Child Lock
4.3.12 Changing the selections after programme has started Adding laundry after the programme has started: If the water level in the machine is suitable when you press Start / Pause button, loading door symbol will flash on the display until the loading door is opened and will disappear when the loading door is opened. 88:88 1888 If the water level in the machine is not suitable when you press Start / Pause button, the loading door symbol... -
Page 22: Cancelling The Programme
4.3.14 Cancelling the programme The programme is cancelled when the machine is turned off and on again. Press and hold On / Off button for 3 seconds. After the countdown as "3-2-1" on the display is over, the machine turns off. If you press On / Off button when the Child Lock is enabled, the programme will not be cancelled. You should cancel the Child Lock first. -
Page 23: Maintenance And Cleaning
4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 24: Cleaning The Water Intake Filters
4.4.4 Cleaning the water intake filters There is a filter at the end of each water intake valve at the rear of the machine and also at the end of each water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in the water to enter the washing machine. - Page 25 In order to clean the dirty filter and discharge the water: 1 Unplug the machine to cut off the supply power. CAUTION: Temperature of the water inside the machine may rise up to 90 ºC. To avoid the burning risk, clean the filter after the water inside the machine is cooled down. 2. Open the filter cover. 3 Follow the below procedures in order to drain water. If the product does not have an emergency water drain hose, in order to drain the water: In order to collect the water to flow out of the filter, place a large vessel in front of the filter.
-
Page 26: Troubleshooting
Troubleshooting Problem Reason Solution Program does not start after Start / Pause / Cancel button was not pressed. • *Press the Start / Pause / Cancel button. closing the door. It may be difficult to close the loading door in case of • Reduce the amount of laundry and make sure that excessive loading. - Page 27 Problem Reason Solution Programme time does not Timer may stop during water intake. • Timer indicator will not countdown until the countdown. (On models with machine takes in adequate amount of water. The display) (*) machine will wait until there is sufficient amount of water to avoid poor washing results due to lack of water.
- Page 28 Problem Reason Solution It does not rinse well. The amount, brand and storage conditions of the • Use a detergent appropriate for the washing detergent used are inappropriate. machine and your laundry. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 29 Problem Reason Solution Foam is overflowing from the Too much detergent is used. • Mix 1 tablespoonful softener and ½ l water and detergent drawer. pour into the main wash compartment of the detergent drawer. • Put detergent into the machine suitable for the programmes and maximum loads indicated in the “Programme and consumption table”.
- Page 30 30 / EN Washing Machine / User’s Manual...
- Page 31 31 / EN Washing Machine / User’s Manual...
- Page 32 www.beko.com...
