Front-Loading
Automatic Washer
Owner's Guide & Installation
Instructions
To prevent accidents and machine damage, read these
instructions before installation or use. Use the washer only as
instructed in this owner's guide and installation instructions
included with your washer. Keep this guide for future reference
WMY 10148 C0
WMY 10148 W0
EN
Document Number=
As an ENERGY STAR® partner,
BEKO has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.
2820524379_EN / 04-07-18.(11:00)
Advertisement
Table of Contents
Related Manuals for Beko WMY 10148 C0
Summary of Contents for Beko WMY 10148 C0
- Page 1 Keep this guide for future reference As an ENERGY STAR® partner, BEKO has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. WMY 10148 C0 WMY 10148 W0 2820524379_EN / 04-07-18.(11:00)
- Page 2 Please read this guide first! Dear Customer, We hope that your product which has been manufactured in modern facilities and passed through a strict quality control procedure will give you the best results. Therefore, we advise you to read through this document carefully before using your product and keep it for future reference.
- Page 3 • Warning for hazardous situations with regard to life and property. WARNING • Warning for electrical shock Please contact your authorized Beko dealer or visit www.beko.us to locate and get information for the closest authorized Beko service center Please fill in the information below for future reference.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1 Your Washer Overview ............6 Specifications . - Page 5 Descaling the washer ..........61 8 Troubleshooting 9 WARRANTY STATEMENT FOR THE BEKO CLOTHES WASHERS 75 10 HOW TO GET SERVICE 5 / English Owner’s Guide &...
-
Page 6: Your Washer
1 Your Washer Overview 1- Power cable 2- Top panel 3- Control panel 4- Drain hose 5- Loading door 6- Filter cap 7- Adjustable feet 8- Detergent drawer 6 / English Front-Loading Automatic Washer... -
Page 7: Specifications
Your Washer Specifications Front Loading Automatic Washer Models WMY 10148 C0 - WMY 10148 W0 Height (in) / (cm) 33.1 / 84 Width (in) / (cm) 23.6 / 60 Depth (in) / (cm) 24.6 / 62,5 Net Weight (lbs) / (kg) 167.6 / 76... -
Page 8: Important Safety Instructions
2 Important Safety Instructions WARNING • To reduce the risk of fire, electric shock or injury to persons while using your appliance follow basic safety precautions, including the following: • Read all instructions before using the washer. • Do not wash articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, or other flammable or explosive substances (acetone, alcohol, kerosene, some liquid household cleaners, some spot removers,... - Page 9 Important Safety Instructions • Do not repair or replace any part of the appliance or attempt any servicing unless specifically recommended in the user-maintenance instructions or in published user-repair instructions that you understand and have the skills to carry out. •...
- Page 10 Important Safety Instructions • Store laundry detergents and additives in a cool, dry place out of children’s reach due to danger of chemical poisoning and skin irritation. Follow the manufacturers’ instructions when using laundry products. • Do not machine wash fiberglass materials. Small particles can stick to fabrics washed in following cycles and may lead to skin irritation.
- Page 11 • All broken and faulty components, panels and parts must only be replaced with original Beko spare parts by a Beko Service technician. • Do not force the washer door open when it is locked. The door 11 / English Owner’s Guide &...
- Page 12 Important Safety Instructions must be closed any time during the program cycle. • Do not use fabric softeners or products to reduce static unless recommended by the manufacturers of the fabric softener product. • Check the drain pump filter occasionally to remove coins, buttons and such small objects.
-
Page 13: Installation Instructions
3 Installation Instructions Read this first ! This washer can be individually installed in free-standing and built-in installations. You can also install your washer with your dryer as a free-standing or built-in pair. Before you install your appliance, read the following instructions completely and carefully: •... -
Page 14: Installation Clearances
Installation Instructions • Never place your washer on a carpet. This prevents air circulation. The electrical components of the machine may overheat and cause damage. • Do not stand appliance on the power cable. • Do not install and operate your washer in ambient temperatures lower than 32˚F (0˚C). -
Page 15: Allowable Clearances For Undercounter Installation
The dimensions are for the recommended spacing. Counter depth should be 23.5-24.5”(60-62 cm). Custom undercounter installation – Washer only Minimum counter width should be 50” (127 cm) for a pair of Beko washer & dryer. Custom undercounter installation – Washer & Dryer 50”... -
Page 16: Allowable Clearances For Closet Installation
(148 cm2) air opening located at 3 in (7.62 cm) from the bottom of closet door. Stacked Installation You can stack your Beko washer and dryer (model no.: DHP 24412 W / DHP 24400 W) by using a special stacking kit (Part No.2985300200). If necessary, consult your dealer or technical service for supplying the stack kit. -
Page 17: Removing Shipping Bolts
Installation Instructions Removing shipping bolts WARNING • Shipping bolts must be removed before operating the washer! Otherwise, the appliance will be damaged seriously! 1.Loosen all the bolts with a spanner wrench until they rotate freely. 2.Remove the shipping bolts by turning them gently. 3.Bolt hole covers (supplied in the bag with the owner’s guide) are fitted into the holes on the rear panel with a special lock mechanism. -
Page 18: Leveling The Washer
Installation Instructions Leveling the washer WARNING • Do not use any tools to loosen the lock nuts. Otherwise, they can be damaged. 1.Manually (by hand) loosen the lock nuts on the feet. 2.Adjust them until the washer stands level and firmly. 3.Important: Tighten all lock nuts up again. - Page 19 (208-240V, 60Hz) located on the appliance. For this purpose, a junction box (as seen in picture below) must be obtained. Junction box is supplied with Beko Clothes Dryer. • Only one appliance must be connected to a properly grounded individual branch circuit outlet.
-
Page 20: Power Supply And Circuit
Installation Instructions Power supply and circuit Connect the clothes washer to the junction box supplied. Junction box must be connected to an earthed outlet protected by a fuse of suitable capacity. Important: • Wall power connection should comply with national regulations. •... -
Page 21: Water Supply Connection
Installation Instructions Water Supply Connection Your washer comes with both cold and hot water connections. Connect the blue marked cold water supply hose to the cold water inlet valve/faucet and the red marked hot water intake hose to the hot water inlet valve/faucet. Screw the connecting bolts by hand and tighten the connection properly using a plier. - Page 22 • Do not remove the filters located on the water supply hoses (on faucet/hose and hose/inlet valve connections). • Always use genuine “Beko” water supply hoses when connecting with this washer. Old or worn-out hoses must not be reused. It is not advised to extend inlet or drain hoses, if necessary consult your dealer or technical service about hose extensions.
-
Page 23: Drainage
Installation Instructions Drainage WARNING • Drain hose should not be bent. Be sure that there are no kinks or cuts on it. • Drain hose outlet must not contact the drained water. Drain hose may be connected into a sink, into the drain of a sink, to a standpipe and floor drain. -
Page 24: Installation Checklist
Installation Instructions Installation Checklist • Water inlet hoses and accessory bags must be removed from the wash drum. • Transportation/shipping bolts must be removed. • Washer must be properly leveled by using the adjustable feet. • Water inlet hoses are connected to the water faucets, secured and checked for any leaks by turning on both faucets. -
Page 25: Disposal Information
Installation Instructions Disposal Information Packing Disposal WARNING • Packing materials of the appliance are potentially dangerous for children. Materials such as plastic bags, films or wrappings must be kept away from children or disposed properly to prevent the danger of suffocation. CAUTION •... -
Page 26: Operating Instructions
4 Operating Instructions First Use WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Before the first use, • Be sure that the washer is installed properly by a qualified installer or service technician in accordance with all national and local codes and requirements. -
Page 27: Laundry Tips
Operating Instructions WARNING • Be sure that siiica gel package, which is located inside the drum, has been removed from the washer before the first use. Granules in this package do not contain poisonous or harmful materials. It is not a detergent and it is not adible. Do not swallow. Do not use for any purpose. -
Page 28: Preparing The Laundry
Operating Instructions CAUTION • Wash the items which are care labeled as “machine-washable”. Do not machine wash items that are having symbol on fabric care label. • Sort the laundry according to the following fabric types, color groups and wash them separately: •... -
Page 29: Loading The Washer
Operating Instructions • Place small items of laundry (e.g. tights) in a cloth bag, pillow case or something similar. This can also help you to avoid searching for lost socks. • Handle curtains special care. Remove non-stainless curtain runners and lead tape. Place runners that can’t be removed in a cloth bag, pillow case or something similar. -
Page 30: Detergent Use
Operating Instructions additional items in the drum for better load distribution and spinning. • Make sure that there is no clothing obstructing the door or caught between the door and rubber seal. • Push the loading door firmly and make sure that the door has been closed properly (especially if you load the washer with full load or big items). -
Page 31: Detergent Quantity
Operating Instructions CAUTION • The detergents labeled as “HE compatible” may also lead to high sudsing and inefficient tumble action. Don’t use such detergents. Always follow the instructions and information given by laundry detergent manufacturers when using these products. WARNING •... -
Page 32: Detergent Dispenser
Operating Instructions Light soiling No visible stains or soiling Normal soiling A few visible light stains or soiling Heavy soiling Highly visible stains or soiling Detergent Dispenser Detergent dispenser of your washer has three separate compartments for main wash detergent, fabric softener and liquid bleach. -
Page 33: (Ii) Main Wash Detergent Compartment
Operating Instructions (II) Main Wash Detergent Compartment Add HE (High efficiency) powder detergent to this compartment numbered as “II” before starting the wash program. Use the detergent manufacturer’s dosing cup and follow the instructions on the package. If you use a liquid detergent, be sure to use a HE (High efficiency) detergent and add detergent directly to main wash compartment before operating your washer. -
Page 34: Liquid Fabric Softener Compartment
Operating Instructions Liquid Fabric Softener Compartment Add the recommended amount of liquid fabric softener to the middle compartment marked as “” and dilute it with warm water to the maximum fill line. CAUTION • Especially concentrated fabric softeners must be diluted with warm water otherwise siphon may be clogged in time. -
Page 35: (I) Liquid Chlorine Bleach Compartment
Operating Instructions use liquid detergent. (I) Liquid Chlorine Bleach Compartment Add liquid chlorine bleach to the right compartment numbered as “I”. Measure 1/3 cup (80 ml) of bleach and pour it into the special container located in the right compartment of the dispenser. This container ensures dispensing and dilution of bleach during the first rinse of wash cycle. -
Page 36: Selecting A Program And Operating Your Washer
5 Selecting a Program and Operating Your Washer Control panel 1 - Program selection knob 2 - Temperature level lights 3 - Spin level indicator lights 4 - Duration information display 5 - Child lock enabled light 6 - End Time Setting button 7 - Door lock enabled light 8 - Program Follow-up indicator lights 9 - On / Off button... -
Page 37: Programs
Selecting a Program and Operating Your Washer Programs • Heavy Duty Use to wash your heavily soiled, durable cotton and linen laundry. You can choose Heavy Soil option for a perfect cleansing. Heavy Soil option prolongs heating step and adds extra rinsing. •... - Page 38 Selecting a Program and Operating Your Washer • Hand Wash You can wash your woolen/delicate clothes that bear “hand wash only” labels for which hand wash is recommended on this program. It washes the laundry with very tender washing movements without damaging your clothes.
- Page 39 Selecting a Program and Operating Your Washer • Fitness Wear This program is used to wash half capacity of normally or lightly soiled daily cotton, synthetics or blended clothes. e.g.: daily clothes and sportswear that have been used only once. •...
-
Page 40: Program Selection
Selecting a Program and Operating Your Washer • Tub Clean Use regularly (once in every 1-2 months) to clean the drum and provide the required maintenance. Run the programme without any laundry in the machine. To obtain better results, put powder limescale remover for washing machines into detergent compartment no. - Page 41 Selecting a Program and Operating Your Washer 2 Select the desired program with the Program Selection knob. 41 / English Owner’s Guide & Installation Instructions...
-
Page 42: Program And Consumption Table
Program and consumption table Program and consumption table Wash Water Max Spin Temperature Speed (rpm) °F / °C Extra Hot Hot /Cold 167 / 75 01:16 Hot /Cold 133 / 56 01:11 Normal • • Extra High Full Warm Hot /Cold 110 / 43 01:06 Cold... - Page 43 Program and consumption table Wash Water Max Spin Temperature Speed (rpm) °F / °C Hot /Cold 140 / 60 01:04 Warm Hot /Cold 110 / 43 01:04 Wrinkle Free • • • High Cold Hot /Cold 86 / 30 01:04 Tap Cold Cold 60 / 15...
- Page 44 Program and consumption table Wash Water Max Spin Temperature Speed (rpm) °F / °C Warm 95 / 35 01:02 Wool Cold • 86 / 30 00:57 High Tap Cold 60 / 15 00:47 Extra Hot Hot /Cold 167 / 75 01:39 Hot /Cold 140 / 60...
-
Page 45: Temperature Selection
Selecting a Program and Operating Your Washer Temperature selection Whenever a new programme is selected, the recommended temperature for the selected programme appears on the temperature indicator. CAUTION • If the programme has not reached the heating step, you can change the temperature without switching the product to Pause mode. -
Page 46: Spin Speed Selection
Selecting a Program and Operating Your Washer Spin speed selection Whenever a new programme is selected, the recommended spin speed of the selected programme is displayed on the spin speed indicator. CAUTION • If the programme has not reached the spinning step, you can change the spinning speed without switching the product to Pause mode. -
Page 47: Auxiliary Function Selection
Selecting a Program and Operating Your Washer Auxiliary function selection Select the desired auxiliary functions before starting the programme. The chosen auxiliary function indicator will light up. CAUTION • When you try to change an auxiliary function that is not allowed to be selected with the current program, the indicator light of the relevant auxiliary function will flash and an audio warning is given. - Page 48 Selecting a Program and Operating Your Washer CAUTION • Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The frame of the auxiliary function will not be illuminated; only the inner area will be illuminated. •...
-
Page 49: End Time
Selecting a Program and Operating Your Washer End Time With the End Time function, the startup of the programme may be delayed up to 24 hours. After pressing the End Time button, the program’s estimated ending time is displayed. If the End Time is adjusted, the End Time indicator is illuminated. -
Page 50: Changing The Selections After Program Has Started
Selecting a Program and Operating Your Washer Changing the selections after program has started After the programme has started you can make the following changes. Switching the product to pause mode Press the Start/Pause button to switch the machine to pause mode while a programme is running. -
Page 51: Child Lock
Selecting a Program and Operating Your Washer Child Lock Use the Child Lock function to prevent children from tampering with the product. You can also avoid any changes being made in a running program. CAUTION • You can switch the product on and off with the On / Off button when the Child Lock is active. -
Page 52: Preparation
6 Preparation 1. Turn on both hot and cold water faucets fully. Check and be sure the water connection is tight. 2. Place the laundry in the drum. 3. Add laundry additives (e.g. detergent, fabric softener,bleach). Starting the program 1. Close the door 2. -
Page 53: Door Locking System
Preparation CAUTION • If you press the On / Off button, the program information set as default will be displayed. Door locking system There is a locking system on the loading door of the product that prevents the door from opening in cases when the water level is unsuitable. -
Page 54: Cancelling The Program
Preparation 5. Make changes in auxiliary functions, temperature and speed settings if necessary. 6. Press the Start / Pause button to then restart the product. Cancelling the program The programme is cancelled when the product is turned off and on again. -
Page 55: End Of Program
Preparation If you want to re-spin the clothes: 1. Rearrange the previously placed clothes in the drum. 2. Select the spin program. 3. Adjust the spin speed. End of program “End” warning appears on the display when the program is completed. -
Page 56: User Maintenance Instructions
7 User maintenance instructions WARNING • Be sure to unplug the power cable before attempting maintenance or cleaning of your appliance to minimize the risk of electric shock. Cleaning detergent dispenser Remove any powder/liquid residue buildup in the dispenser drawer. To do this;... -
Page 57: Cleaning The Door Seal
User maintenance instructions Cleaning the door seal Be sure to check the rubber door seal after unloading your washer. Pull the seal back to search for any foreign objects. Residual metal objects such as pins and coins may form rust stains on rubber seal, and cause the seal to leak. -
Page 58: Cleaning The Outer Cabinet And Control Panel
User maintenance instructions Cleaning the outer cabinet and control panel When necessary: • Wipe the exterior panels of your washer with soapy water or mild detergent. Dry it with a soft cloth. • Use only a soft and damp cloth to clean the control panel. CAUTION •... -
Page 59: Cleaning The Drain Pump Filter
User maintenance instructions Cleaning the drain pump filter Filter system in your washer prevents solid items such as buttons, coins and fabric fibers clogging the pump impeller during discharging of the washing water. Thus, a good water discharge is achieved and the pump life is extended. - Page 60 User maintenance instructions 3. Follow the below procedures in order to drain water. Product has an emergency water draining hose, in order to drain the water: a Pull the emergency draining hose out from its seat b Place a large container at the end of the hose. Drain the water into the container by pulling out the plug at the end of the hose.
-
Page 61: Descaling The Washer
User maintenance instructions Descaling the washer Hard water can cause scale build-up inside the drum and other parts of your washer in time. Scaling may lead to some serious problems such as clogging in hoses, heater or pump failure eventually. To prevent scaling, wash drum should be cleaned frequently. -
Page 62: Troubleshooting
8 Troubleshooting Problem Reason Solution * Press and hold the On / A program The product may have switched to self protection Off button for 3 seconds to cannot be mode due to a supply problem reset the product to factory started or settings. - Page 63 Troubleshooting Problem Reason Solution * Stablize the product by Product vibrates Product might be standing unbalanced. adjusting the feet. or makes noise. A hard substance might have * Clean the pump filter. entered into the pump filter. Transportation safety bolts are * Remove the transportation safety bolts.
- Page 64 Troubleshooting Problem Reason Solution * Drain the water by Loading door The cover lock is activated due to the water level inside the running the Pump or Spin cannot be product. programme. opened. Washer might be heating up * Wait until the process is over. the water or it may be at the spinning cycle.
- Page 65 Troubleshooting Problem Reason Solution * Product waits until taking Washing takes Water pressure is low. in an adequate amount longer than of water to prevent poor specified in the washing quality due to the manual.(*) decreased amount of water. Therefore, the washing time extends.
- Page 66 Troubleshooting Problem Reason Solution * Timer indicator will not Programme Timer may stop during water intake. countdown until the product time does not takes in an adequate amount countdown. (On of water. The product will models with wait until there is a sufficient display) (*) amount of water to avoid poor washing results due to...
- Page 67 Troubleshooting Problem Reason Solution * Use the recommended Washing Insufficient amount of detergent has been used over amount of detergent performance is a long period of time. appropriate for water poor: Laundry hardness and type of laundry. turns * Select the proper Washing was made at low Grey.
- Page 68 Troubleshooting Problem Reason Solution * Select the proper program Washing Wrong program cycle and cycle and temperature for the performance temperature might have been laundry to be washed (See is poor: Stains “Laundry Tips” & “Program selected. could not Cycle Selection”). be removed.
- Page 69 Troubleshooting Problem Reason Solution * Washer must be operated Washing Oily accumulations of prior wash cycles on the drum may empty at “Tub Sanitize” cycle performance have stuck to the laundry. with detergent. is poor: Oily The detergent may have stains appear on * Softener should not come been placed into the wrong...
- Page 70 Troubleshooting Problem Reason Solution * There may be an imbalance Rinsing of laundry in the machine. performance is The laundry in the drum poor. may be tangled up too much. Laundry should be Intermediate spins may be rearranged and re-spun. No spinning is performed when skipped.
- Page 71 Troubleshooting Problem Reason Solution * If detergent is put in the Laundry does Detergent is put in the wrong compartment. prewash compartment not smell like the when the prewash cycle is softener. (**) not selected, the product can take this detergent during the rinsing or softener step.
- Page 72 Troubleshooting Problem Reason Solution * Use HE detergent. Too much foam Not using HE detergent forms inside the * Use only a sufficient amount Excessive amount of detergent is used. of detergent. product. (**) Detergent was stored under * Store detergent in a closed improper conditions.
- Page 73 Troubleshooting Problem Reason Solution * Use the recommended Laundry remains Excessive foam might have occurred and automatic foam amount of detergent. wet at the end of absorption system might have the programme. been activated due to too much detergent. Unbalance detection due to * Add more laundry (e.g.
- Page 74 Troubleshooting Problem Reason Solution (*) The product does not switch to the spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the product and to its surroundings. Laundry should be rearranged and re-spun. (**) Regular drum cleaning is not performed.
-
Page 75: Warranty Statement For The Beko Clothes Washers
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. 1 year * limited warranty from date of first installation Beko will repair or replace at no cost to the consumer any defective parts of the washer if used under normal household conditions (warranty is void if the product is used commercially e.g., bed + breakfast,... -
Page 76: How To Get Service
10 HOW TO GET SERVICE Please contact your local authorized Beko dealer, or call our Toll Free Customer Hotline number at 1-888-352 BEKO (2356) for direction to an Authorized Beko Service Agent or contact via http://www.beko. us . You can also look up for authorized dealer list at “Where To Buy”... - Page 80 www.beko.com...
