Ref
Component
SD/MMC Slot
Headphone
Connector
Top Components
Ref
Component
Power Button
Bottom Components
Ref
Component
Mini-USB Connector Connects to the charger or USB cable.
Cradle Connector
Accepts a SD (Secure Digital) or MMC (MultiMediaCard)
card for accessing data such as MP3 music.
Connects to stereo headphones.
Turns on and off the device. (Pressing briefly or for a long
duration makes a difference. See Sections 1.6 and 13.1 for
information.)
Connects to the cradle (purchased separately).
Description
Description
Description
3
