5. Remove the three screws that secure the center hinge to the refrigerator, then remove the
center hinge. Save the screws to reuse.
6. Remove the sleeves and hole caps from the refrigerator door, then install them in the
opposite side of the door.
7. Take the left-side self-locking block and stopper from the accessory bag and install them
in the bottom left side of the refrigerator door as shown below.
Left door-self-
locking block
Left door-
open stopper
8. Remove the center hinge, remove the center hinge shaft with a slotted screwdriver, install
hinge shaft on opposite side of the hinge and install the hinge to the left of the box.
In the order shown above, the
center hinge shaft is changed.
9. Insert the door stopper on the bottom left side of the refrigerator door onto the hinge pin
you installed in the middle left side of the refrigerator.
10. Take the left-side top hinge from the accessory bag and install it on the top left side of the
refrigerator with the screws you previously removed, and the hinge pin in the door sleeve
of the refrigerator door.
08
Sleeve
