COMPANY PROFILE After two decades of experience in the health industry, founder utilized his knowledge and expertise in massage therapy from an Asian-Pacific perspective to establish our brand - . Our massage therapy business was expanded to Hong Kong in 2012 and is conferred 2017 Hong Kong Top Brand Award. Based in Hong Kong, we are specializing in design &...
Page 55
Thank you for purchasing ’s products. Before using the product, please read this manual thoroughly, particularly the Safety Precautions section, for the correct use of the product. This manual should be well kept for easy reference. It enables you to perform a safe and efficient operation.
Safety Precautions 1. Important safety warning • Please read this manual instruction carefully before operation. • Any other usage that is not listed in this manual instruction is forbidden. • Keep children and pets away from the movable parts of this product. •...
Page 57
Safety Precautions • Pregnant women or women that are in menses period. • People who got injured or skin diseases. • Children under 14-year old or people mentally unbalanced without being supervised are not allowed to use this machine. • People who are told by doctor to have rest or people who feel unwell. •...
Page 58
Safety Precautions Installation Instruction Calf installation instructions 1. After connecting the lower leg and the air tube on the massage chair with the wire harness, untie the fixed pipeline belt and insert the connecting part into the seat frame (Fig. 1). 2.
Page 59
Safety Precautions Place Massage Chair Installation placement Make sure there is enough space for the massage chair to be tilted at least 8 cm. Do not expose the massage chair directly to a high-temperature environment, such as in front of heating equipment, and place it in a location where it can avoid high temperatures and direct sunlight.
Page 60
Safety Precautions Place Massage Chair Move method Use the rear casters to move the massage chair. Move the chair by tilting it downward and backward about 45° as shown in the diagram. Note: Excessive force will cause the chair to flip over and damage. 1.
Page 61
Safety Precautions Before Use Check around Ensure that there are no people, pets, or other objects around the machine. Make sure there is no foreign object in the gap of the machine. Before starting the massage, please ensure that there are no foreign objects in the leg and foot areas, as well as other positions.
Name and Function of Components Horn cover Head cushion Shoulder air bag assembly Back cushion Controller placement slot Arm air bag Assembly Extra pad Armrest assembly Calf massage Mechanism Side cover P.07...
Page 63
Name and Function of Components Both sides of the head 3Ddigital audio music playback Shoulder Airbag massage Head Neck to seat Back roller massage Waist heating Heating function Hand Airbag massage Calf heating Heating function Calf Airbag massage Roller Sole massage P.08...
Page 64
Name and Function of Components I. Introduction to the remote controller 1. Power Button: Turn on or off the massage chair. 2. Shoulder Position Up/Down Button: Adjust the shoulder position up or down. 3. Auto Mode: The automatic massage functions include Relieve Soreness, Neck & shoulder Massage, Spine Care, Stretch Massage, Good-night Sleep, and more modes.
Page 65
Name and Function of Components I. Introduction to the remote controller 8. Pause Button/Bluetooth: Short press to start or pause the massage function. Long press to enable or disable Bluetooth. 9. Seat Position Up/Down Button: Adjust the reclining angle of the massage chair up or down.
How to Use II. Start massage 1. Press the Power Button to turn it on. 2. After the massage chair is turned on, the angle of the massage chair will be adjusted automatically, and the shoulder position detection will begin after the adjustment is completed.
Page 67
How to Use III. Automatic program 1. Automatic program selection: (1) Press the automatic program button on the remote control to select and start the desired massage program. (2) There are various automatic programs to choose from, including Fast Massage, Comfort Massage, Relax Massage, Full Body Massage, Neck &...
Page 68
How to Use Function Description Display Spine 3D intensity in the most strong state of the whole Care 2.0 process, protect the health of the whole spine. Full-body Increase body flexibility by stretching body muscle. Stretch The massage manipulator slowly slides down from the shoulder and neck to the waist, then massage Back manipulator slowly slide from the waist to the neck and...
Page 69
How to Use IV. Automatic program 1.Massage technique, select the remote technique key to choose massage technique. (1) There are massage techniques including stop, knead, shiatsu, tapping, knock, kneading and tapping, 3D1, 3D 2, etc. The techniques are cyclically adjusted by the technique keys.
Page 70
How to Use 4.Massage area, select the remote part key to select the massage area. (1) There are massage areas, including (fixed , partial, upper back, lower back, (2) Information interface area display. Function Description When choosing fixed-point and Massage at a fixed location Spot H0 partial massage area, you can adjust the massage area by...
Page 71
How to Use V. Other function 1. Heating, press the heating key, Cycle to switch Backrest and calf heating, backrest heating, calf heating and off heating. (1) Information interface heating display. Heating Backrest+calf Backrest calf 2. Roller, press the roller massage key, you can adjust the intensity of roller massage and turn off.
Page 72
1.Maxcare Massage Chair Download and install : (1). Android and Harmony OS: Scan the QR code to download and install or download it from Google. (2). Apple: Search for the Maxcare Massage Chair in the AppStore to download. 8:30 Maxcare Massage Chair 取消...
Page 73
How to Use 2. Massage chair controlled by APP (1). In the APP interface, select "Bluetooth Settings" to search for and add devices; Select Bluetooth in the device list. (2). After the device is successfully connected, it will automatically enter the APP interface. At this time, you can control the massage chair through your mobile phone.
Cleaning and Maintenance Cleaning • Before cleaning, please ensure that the switch is turned off and the power plug is disconnected from the socket. • Use soft cloths to clean the surface of product and control panel. • Do not pull the plug from the socket with wet hands. •...
Page 75
Maintenance and Cleaning of PU Leather PU leather is made by the coating and drying of polyurethane. Compared with genuine leather, PU leather is more resistant to tear, heat and sunlight. Depending on its nature and chemical substances, however, it should be kept away from any dusty, high/low-temperature, humid environment, under direct sunlight or places with corrosive substance.
Troubleshooting The following symptoms do not indicate malfunction. Please check the below phenomenon to find out the solution before contact customer services department. If the problem still cannot be solved, please do not dismantle or repair the product. You should stop using it and contact us immediately.
FAQs and Solutions Abrupt stop during operation. Fault 1. Power disconnected. Please check if the power cord is connected. 2. Rated working time (20 minutes) is up, and sleep mode is activated. Please press the power button to restart. Solution 3.
