- Page 1 All manuals and user guides at all-guides.com WatchGuard XTM 3 Series Hardware Guide XTM 33, 33-W FS2E5, FS2E5W...
-
Page 2: Notice To Users
Copyright© 1998–2011 WatchGuard Technologies, Inc. All rights reserved. WatchGuard, the WatchGuard logo, Firebox, LiveSecurity, and any other mark listed as a trademark in the “Terms of Use” portion of the WatchGuard Web site that is used herein are either registered trademarks or trademarks of WatchGuard Technologies, Inc. -
Page 3: Hardware Specifications
The WatchGuard® XTM 33 is a network security device for small organizations and branch offices. Note This Hardware Guide applies to XTM 33 and XTM 33-W devices. If your XTM 3 Series device has a different model number, your hardware is described in the XTM 3 Series Hardware Guide that applies to that model. -
Page 4: Package Contents
All manuals and user guides at all-guides.com Hardware Specifications Package Contents CD-ROM with this Hardware Guide XTM 3 Series appliance Quick Start Guide Hardware warranty card AC adapter (12V/2A) with international plug kit Power cable clip, to attach to the cable and connect to the device. This decreases the tension on the power cable. -
Page 5: Front View
After the external interface connection fails back to the primary external interface, the indicator is not lit. The WAP indicator is lit when the XTM 3 Series wireless device is activated as a wireless access point or as a wireless client. - Page 6 10, 100, or 1000 Mbps. Antenna (wireless models only) The XTM 3 Series Wireless device has a wireless antenna to the right of the network interfaces. A rear cooling fan may be installed on some models.
-
Page 7: Ac Power Adapter
Hardware Specifications AC Power Adapter The AC power adapter supplies power for the XTM 3 Series device. You must use the correct plug for the AC power adapter for the power source used in your country. The international plug kit includes four plugs: Q-NA (North America), Q-UK (United Kingdom), Q-EU (European Union), and Q-SAA (Asia). -
Page 8: Environmental Requirements
10% – 95% Non-condensing Safety Notices All WatchGuard products are designed and tested to meet strict safety requirements. These requirements include product safety approvals and other global compliance standards. Read these instructions carefully before you operate the product, and refer to them as needed for continued safe operation of your product. - Page 9 Hardware Specifications Sicherheitshinweise Alle WatchGuard Produkte wurden entwickelt und getestet um die strikten Sicherheitsrichtlinien zu erfüllen. Diese Richtlinien beinhalten Produktsicherheit Freigaben und andere weltweite Sicherheitsstandards. Vor Inbetriebnahme des Produktes lesen Sie die Anleitung sorgfältig durch und bei Bedarf beziehen Sie sich auf sie für einen dauerhaft sicheren Betrieb Ihres Produktes.
-
Page 10: Avis De Sécurité
Hardware Specifications Avis de sécurité Tous les produits de WatchGuard sont conçus et testés pour répondre à des exigences de sécurité strictes. Ces exigences incluent l'homologation de la sécurité du produit et la conformité à d'autres normes globales. Lisez ces instructions avec attention avant de mettre en route l'appareil et reportez-vous-y au besoin pour assurer une utilisation sûre de l'appareil. -
Page 11: Restore Factory Default Settings
Fireware XTM OS, you can restore the XTM 3 Series device to the factory default settings and build your configuration again. To set the XTM 3 Series device to the factory default settings: 1. Disconnect the power supply. - Page 12 Signal Attenuation The strength of the wireless signal can vary based on the distance between the XTM 3 Series device and the wireless client, the orientation of the antennas, and many environmental factors such as physical obstructions...
-
Page 13: Legal And Regulatory Information
WatchGuard Technologies, Inc. (“WatchGuard”) and you agree as set forth below or on the reverse side of this card, as applicable: 1. - Page 14 WITH REGARD TO ANY PRODUCT WILL IN NO EVENT EXCEED THE PURCHASE PRICE PAID BY YOU FOR SUCH PRODUCT. THIS SHALL BE TRUE EVEN IN THE EVENT OF THE FAILURE OF ANY AGREED REMEDY. IN NO EVENT WILL WATCHGUARD BE...
-
Page 15: Declaration Of Conformity
All manuals and user guides at all-guides.com Legal and Regulatory Information Declaration of Conformity Hardware Guide... -
Page 16: Fcc Certification
In particular, modifying antenna gain to exceed 2.0 dBi voids the FCC certification. CE Notice The CE symbol on your WatchGuard Technologies equipment indicates that it is in compliance with the Electromagnetic Compatibility (EMC) directive and the Low Voltage Directive (LVD) of the European Union (EU). -
Page 17: Vcci Notice Class A Ite
All manuals and user guides at all-guides.com Legal and Regulatory Information CANADA RSS-210 The term “IC:” before the radio certification number only signifies that Industry of Canada technical specifications were met. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. -
Page 18: Korean Class A Notice
All manuals and user guides at all-guides.com Legal and Regulatory Information Korean Class A Notice Korean Wireless Notice Taiwanese Class A Notice Taiwanese Wireless Notice WatchGuard XTM 3 Series... -
Page 19: Rohs Statement
WEEE statutes, and that the recovery of our product per the specific EU country legislative requirements is seamless for our product’s end users. If you have a WatchGuard product that is at its end of life and needs to be disposed of, please contact WatchGuard Customer Care Department at: U.S. Customers: 877.232.3531 International Customers: +1.206.613.0456... - Page 20 In accordance with the regulations, the products of WatchGuard do not need to be registered for the following reasons: 1. WatchGuard does not import more than 1 metric ton per year of a substance as defined by REACH. 2. WatchGuard products are non-chemical products that are not designed to release any substance under normal and reasonably predictable application.
-
Page 21: Gnu General Public License ("Gpl")
All manuals and user guides at all-guides.com Legal and Regulatory Information GNU General Public License (GPL) Each of the following programs are wholly or partially licensed under the GPL: ARPTables, bpalogin, bridge- utils, busybox, ebtables, glibc, hostapd, iproute, ipset, iptables, iputils, linux, nmap, ppp, pptpd, rp-pppoe, wireless_tools, wpa_supplicant. -
Page 22: Terms And Conditions For Copying, Distribution, And Modification
3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: WatchGuard XTM 3 Series... - Page 23 All manuals and user guides at all-guides.com Legal and Regulatory Information Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange;...
- Page 24 INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. WatchGuard XTM 3 Series...
