- Page 1 Instruction Manual Electric Fryers With Cabinet (Series instructions） User's Guide (Please read before using the machine)
- Page 2 Instruction Manual Welcome to Our Luxury Combination Oven Series! Thank you for choosing our luxury combination oven. To ensure you get the most out of your product and to minimize the risk of damage or injury, please read this manual carefully before use. Keep it handy for future reference.
-
Page 3: Basic Parameters
Instruction Manual 2. Basic Parameters： Model HEF-26 HEF-26-2 The use of voltage 3N-380V 50/60Hz 3N-380V 50/60Hz 10KW 2×10KW Power Temperature setting range 50-190℃ 50-190℃ Number of cylinders Normal oil content 2×30L Number of fry basket Installation dimensions 420×830×1080 800×830×1080 The amount of food loaded in each batch must not exceed the limits specified in the table below:... -
Page 4: Installation Instructions
Instruction Manual 4. Operating Instructions: 4.1 Before use, ensure the power installation is functioning correctly. The power supply voltage must match the furnace's required operating voltage. 4.2 Adjust the oil level in the fryer according to your actual needs. 4.3 Turn on the power. When the green indicator light illuminates, the furnace is receiving power. Turn the thermostat knob clockwise to set the desired temperature (align it with the red mark). - Page 5 Instruction Manual Important Safety Information This product must only be operated by a trained chef or an experienced individual. Product modifications or refitting are strictly prohibited as they can lead to serious accidents. Always cut off the power before cleaning. Do not use water to flush the product or its components.
-
Page 6: Cleaning And Maintenance
Instruction Manual 7. Cleaning and Maintenance： 7.1 Before cleaning, always disconnect the power supply to prevent accidents. 7.2 After daily use, clean the product with a damp cloth and a non-corrosive cleaner. Do not flush the electrical box or other components directly with water to prevent water infiltration, which could affect the electrical performance. -
Page 7: Declaration Of Conformity
HEF101V, HEF102V, HEF11L, HEF11L2, HEF131V, HEF161C, HEF161V, HEF162C, HEF162V, HEF26, HEF262, HEF81, HEF81A, HEF82A, HEF83A, HEF88, HEF8L, HEF8L2. Application of This Declaration of Conformity is issued under the sole responsibility of the importer: Adexa Territory Legislation & Direct Limited. Council Directives(s) For the object of this declaration, the essential requirements and principal safety objectives have been demonstrated.
