BENY BCPP-A1-16 User Manual

Portable ev charger
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ZHEJIANG BENYI NEW ENERGY CO.,LTD.
WENZHOU BRIDGE INDUSTRIAL ZONE, BEIBAIXIANG TOWN, ZHEJIANG, CHINA
TEL: +86-577-5717 7008 FAX: +86-577-5717 7007
VERSION: 20230829
benyi@zjbeny.com
www.beny.com
This catalogue has been printed on ecological paper.
Zhejiang Benyi New Energy Co.,Ltd.all rights reserved.
If the models and specification in this product catalogue is changed due to the change of products, we wil not inform.
Portable
EV Charger
User Manual
WWW.BENY.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCPP-A1-16 and is the answer not in the manual?

Questions and answers

Related Manuals for BENY BCPP-A1-16

Summary of Contents for BENY BCPP-A1-16

  • Page 1 WENZHOU BRIDGE INDUSTRIAL ZONE, BEIBAIXIANG TOWN, ZHEJIANG, CHINA TEL: +86-577-5717 7008 FAX: +86-577-5717 7007 VERSION: 20230829 benyi@zjbeny.com www.beny.com This catalogue has been printed on ecological paper. Zhejiang Benyi New Energy Co.,Ltd.all rights reserved. WWW.BENY.COM If the models and specification in this product catalogue is changed due to the change of products, we wil not inform.

  • Page 2: Table Of Contents

    CONTENTS 1. Safety Information 1. Safety Information Thank you for purchasing and using the Benyi electric vehicle mode 2 charger. 2. Product Introduction This document contains important instructions and warnings that must be followed 2.1. Product Appearance when using and maintaining the EV Charger. In order to help you to use the product correctly,please read this manual carefully 2.2.

  • Page 3: Product Introduction

    2. Product Introduction Cautions For safe electricity usage, it is not recommended to use the device to charge in the open air on rainy days. Do not immerse the AC Charging device in water Do not step on the cable, pull the cable, bend the cable or tie the cable Do not drop the control box or put heavy objects on its surface 2.1.

  • Page 4: Product Specification

    2.2. Product Specification 2.3. Plug Types Item Parameter Model BCPP-A1-16 Standard IEC 62752,IEC 61851-21-2 Rated Input/Output Voltage 230V(100~265V) Frequency 50Hz/60Hz Rate Charging Current 8A/10A/13A/16A ZH-3 YP-39A ZH-70A 20A/250V~ Standby Power Consumption <1.5W H07BZ5-F H05VV-F H07RN-F Operating Temperature -30℃~50℃ 3G 2.5mm²...

  • Page 5: Product Packing List

    2.4. Product Packing List 2.5. Product Functions Leakage Over Current Ground Over Voltage Protection Protection Protection Protection Portable EV Charger User Manual WWW.BENY.COM Relay Over CP Signal Under Voltage Adhesion Temperature Abnormal Protection Protection Protection Protection Quantity Item Portable EV Charger...

  • Page 6: Product Features

    3. Operating Status 2.6. Product Features 3.1. LED Light Description Build-in with Over Current Protection, Over Voltage Protection, Under Voltage Protection, Over Temperature Protection, Relay Adhesion Protection, Ground Protection, CP Signal Abnormal Protection, Fire Protection, Anti-pressure Protection and Type B Leakage Protection. It can be charged by appointment, 0-24 hours.
  • Page 7 OLED Screen OLED Screen Status Status Over Voltage Under CP Vol Voltage Over Leakage Current Relay Emergency Adhesion stop charging, Over Relay Temp Adhesion restart charger to check if it is normal; If not, please contact Check if socket Relay the dealer No Action is grounded,...

  • Page 8: Oled Screen Description

    4. How to Plug and Play 3.2. OLED Screen Description Power-on and self-test, Press Press Press Left and Picture Status Plug the connector into Left Key Right Key Right Together the vehicle. Poor lgnore poor grounding grounding and start charging Wait for the vehicle to be ready to start charging.

  • Page 9: How To Set Charging Current

    5. How to set charging current 6. How to set a timed charging Press both at Press both at same time same time Reserve: 0h Reserve: 0h Press the left Press the right to to select current select time Reserve: 0h Reserve: 4h Press both at same time, Press both at...

  • Page 10: How To Emergency Stop Charging

    7. How to emergency stop charging 8. How to set temporarily charging when the socket without ground wire Press both at same time Press both at same time Press the left to stop charging, Plug connector Press the right to into vebicle cancel Wait vehicle ready,...

  • Page 11: Warranty Description

    9. Permanently turn off the ground detection setting Double-click to enter the setting interface Reserve: 0h Double-click and hold for 5s to enter the ground detection setting interface Click the left button to confirm, Turn off right to cancel Gnd Detection 10.
