Structure Diagram - Adexa HEB-8F Instruction Manual

Instruction Manual

1.2. Structure Diagram

Figure 1: HEB-8F
1——Furnace body 2——Timing Control
4——Spray Switch 5——Spray Light
7——Upper Heating Light 8——Temperature Light 9——Thermostat
2. Electrical Principles & Basic Parameters
2.1.
Electrical Principles
ST1 ST2——Thermostat
——Temperature Limiter
HL1~HL4——Indicator light S——Point Switch HL——
Electromagnetic Valve
YV——
3——Power Light
6——Upper Heating Thermostat
——Electric Fan PT——Timer
EH1 EH2 EH3——Heated Tube
3
Inside Chamber Lighting
