Summary of Contents for Adexa YXD-8A
- Page 1 Instruction Manual Electric Convection Oven Instruction Manual...
- Page 2 1. Profile of Function & Structure Diagram Profile of Function YXD-8A Electric Convection Oven is elaborately researched and made by the technicians in our factory, who employ the merits of this kind of foreign and domestic products. It contains advantage of fashionable style, reasonable structure, easy operation, all stainless steel body, durable and ease of maintenance.
- Page 3 Instruction Manual all rich food. 1.2 Structure Diagram 1——Furnace body 2——Timing Control 3——Power Light 4——Spray Switch 5——Spray Light 6——Temperature Light 7——Thermostat 2. Electrical Principle & Basic Parameters Electrical Principle SB1——Temperature Limiter SB2——Point Switch KT—— Timer...
-
Page 4: Operating Principle
C1~C2—— Starting capacitance YV——Electromagnetic valve M1~M2——Fan Operating principle ⚫ Hot Air Circulation Function ⚫ Time Control Function ⚫ Spray Function 2.2 Basic Parameters Model YXD-8A Commodity Electric Convection Oven Voltage（V） Power (W) 6.4kw Frequency(Hz) Dimension（mm） 834*672*572 Temperature of inside chamber（℃）... -
Page 5: Special Remarks
Instruction Manual ⚫ Do not use the product without installing of the rubber feet. ⚫ Please install the rubber feet on the device 4. Installation location requirements ⚫ The product must be placed in accordance with the instructions in a solid place. ⚫... - Page 6 Instruction Manual 3. Do not disassemble and refit the product, which will lead to serious accidents. 4. Please don’t open the enclosure of the product. Product inside contains high-voltage circuit. disassembling shell may lead to electric shock. 5. Please make sure to pull out the plug and cut off the power before cleaning. 6.6.
-
Page 7: Routine Inspection
Instruction Manual ⚫ Clockwise twist the timer knob and set the desired time. (Time Range between 0-120 minutes) ⚫ Clockwise twist hot air circulation thermostat knob and set the desired temperature, then the temperature lights will be on. (Temperature range between 0 ~ 300 ℃) ⚫... - Page 8 Instruction Manual performance.and hindering electric shock accidents. ⚫ Add the grease to the active place of the door at least every year to keep the lubrication ⚫ Must be regularly tested by an experienced professional and technical personnel.(commend at least once a month) ⚫...
