Related Manuals for AlphaESS SMILE-G3
Summary of Contents for AlphaESS SMILE-G3
- Page 1 YOUR SMART ENERGY SMILE-G3 RESIDENTIAL SERIES CAPACITY 10.1 kWh modular expandable to 60.5 kWh Picture 200% PV Input Grid-Forming Function Off-Grid Parallel Operation Faster Response for VPP Control...
- Page 2 SMILE-G3 Model SMILE-G3-S5 System Specification Nominal Output Power 5000 W Capacity Range 10.1 ~ 60.5 kWh (95% DoD) Battery Chemistry LFP (LiFePO4) IP Protection IP65 (Outdoor) System Dimension (W x D x H) 610 x 230 x 1168 mm（with Bracket）...
- Page 3 SMILE-G3-BAT-10.1P...
-
Page 5: Legal Provisions
Legal Provisions Legal Provisions The information contained in these documents is the property of AlphaESS. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, be it electronic, mechanical, photographic, magnetic or otherwise, without the prior written permission of AlphaESS. -
Page 6: Information On This Document
Information on this Document 1. Information on this Document 1.1. Validity This document is valid for the SMILE-G3-BAT-10.1P. 1.2. Target Group he instructions in this document may only be performed by qualified persons who must have the following skills: Knowledge of how batteries work and are operated ... -
Page 7: Intended Use
This product is not suitable for supplying life-sustaining medical devices. Please ensure that no personal injury would lead due to the power outage of the system. Alterations to the AlphaESS product, e.g., changes or modifications are not allowed unless the written permission of AlphaESS is achieved. - Page 8 Safety 2.2. IMPORTANT SAFETY INSTRUCTIONS This product has been designed and tested under international safety requirements. However, to prevent personal injury and property damage and ensure long-term operation of this product, please do read this section carefully and observe all safety information at all times.
- Page 9 Wear suitable personal protective equipment for all work on the battery pack. 2.2.5. Notice of Property Damage If the product doesn't start at all, please contact AlphaESS service as soon as possible. Otherwise, the battery could be permanently damaged.
- Page 10 Symbols on the System 3. Symbols on the System Symbol Explanation Beware of a danger zone This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site. Beware of electrical voltage The product operates at high voltages.
-
Page 11: Eu Declaration Of Conformity
Restriction of the use of certain hazardous substances 2011/65/EU (L 174/88, June 8, 2011) and 2015/863/EU (L 137/10, March 31, 2015) (RoHS) AlphaESS confirms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. -
Page 12: Product Overview
(5) BAT- Power Connector (6) BMS COM 1 (7) BMS COM 2 (with terminal resistance) 6.1.2. LED Display The five LED indicators on AlphaESS energy storage inverter provide information about the SOC operational status of the battery. Description Indicator LEDs show SOC≤5.2%... - Page 13 Instructions 9.5%＜SOC≤25.2% 25.2%＜SOC≤50% 50%＜SOC≤75.2% 75.2%≤SOC≤100% Error Description Troubleshooting Indictor Code Display Wait for automatically recovery. If Temperature the problem is not be solved yet, difference please call the service. Stop discharging and charging High- until this code is eliminated and Temperature wait for the temperature to drop.
- Page 14 Instructions Error Description Troubleshooting Indictor Code Display Error 01 Hardware error Wait for automatical recovery. If the problem is not be solved yet, please call the service. Error 05 Hardware error Switch on circuit breaker after Error 06 Circuit breaker open powering off...
- Page 15 Instructions NOTE: In the case of work mode, if the protection code 09 appears, please press the power button 5 times within 10 seconds, the BMS will be forced to turn on the MOSFET of discharge so that the inverter can detect the battery open voltage and charge the bat- tery.
- Page 16 Instructions 6.2. Dimensions φ9x15 ≥300mm ≥300mm ≥300mm 241.5 212.4 ≥300mm ≥300mm ≥300mm ≥300mm ≥300mm...
- Page 17 Instructions 6.3. Scope of Delivery 6.4. Mounting Location 0° 50℃ -10℃ IP65/Outdoor 90kg 6.5. Installation M5*10 2.5N.m SW10 ≥70mm...
-
Page 18: Electrical Connection
Instructions 6.6. Electrical Connection 6.6.1. Grounding M5*10 2.5N.m 6.6.2. Connecting to the Inverter... - Page 19 Instructions...
- Page 20 Instructions 6.6.3. Connecting Expansion Batteries Connect the cables between the batteries and route them from the rear side of the battery to the wall. DANGER Danger to life due to short-circuiting of the battery when doing battery electrical connection. Touching the short-circuit connection of the battery results in death or lethal injuries due to electric shock and massive energy release.
-
Page 21: Technical Data
Technical Data 6.7. Commissioning 6.8. Cable Cover and Switch Cover Installation 7. Technical Data... - Page 22 Alpha ESS Co., Ltd. Alpha ESS Suzhou Co., Ltd. +86 513 806 068 91 +86 512 6828 7609 info@alpha-ess.com info@alpha-ess.com www.alpha-ess.com www.alpha-ess.com Building 10-A, Canal Town Industrial Park, JiuHua Road 888, High-Tech Industrial Development 99 Taihu E Rd, Wuzhong District, Suzhou 215000 Zone 226300 Nantong City, Jiangsu Province Alpha ESS Europe GmbH Alpha ESS Australia Pty.
