Summary of Contents for AREBOS AR-HE-GK2NW
- Page 1 User’s Manual – A S Glass ceramic hob REBO Glass ceramic hob AR-HE-GK2NW/ AR-HE-GK4NW/ AR-HE-GK5NW Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Glass ceramic hob REBO List of contents 1. Introduction and safety precautions ....3 1.1 Introduction ........................... 3 1.2 Explanation of the symbols ......................3 1.3 Safety precautions ..........................4 2. Installing the device ........5 3. Ventilation and safety distances .....6 4. -
Page 3: Introduction And Safety Precautions
User’s Manual – A S Glass ceramic hob REBO Thank you for buying our product. Please read the operating instructions carefully before using the product for the first time. If you hand over the product to third parties, these operating instructions must also be handed over. -
Page 4: Safety Precautions
User’s Manual – A S Glass ceramic hob REBO Warning of electrical voltage! 1.3 Safety precautions Your safety is most important to us. Therefore, please ensure that you read the operating instructions before installing and using the ceramic hob. If you are unsure about any information in this manual, please contact the dealer from whom you purchased the appliance. -
Page 5: Installing The Device
Model W (mm) L (mm) H (mm) D (mm) B(mm) A(mm) X (mm) AR-HE-GK2NW 50min AR-HE-GK4NW 50min AR-HE-GK5NW 50min Cut a hole in the worktop. At least 1.97 in (50 mm) of space should be left around the hole. -
Page 6: Ventilation And Safety Distances
User’s Manual – A S Glass ceramic hob REBO Check that the connection cable does not come into contact with sharp edges and/or hot surfaces. 3. Ventilation and safety distances Make absolutely sure that the following conditions are met for adequate ventilation of the hob and that the supply and exhaust air is not blocked. -
Page 7: Connecting The Hob To The Mains
User’s Manual – A S Glass ceramic hob REBO A screw B mounting bracket C screw hole D Bottom base E Glass ceramic plate F worktop Note: illustrations may vary Installation of the heat protection below the hob If the hob is installed above a drawer, furniture compartment of similar, of if the hob is accessible from below: ... -
Page 8: Technical Data
The installer must use an H05GG-F type power cable. After installation, the connection cable and the underside of the hob must no longer be accessible. 6.Technical data AR-HE-GK2NW AR-HE-GK4NW AR-HE-GK5NW Size (mm) 300*520*58 590*520*58 770*520*58... -
Page 9: Extra Cooking Zone Circle For The Cooking Zone Bottom Left
● Upper cooking zone up to max. 2200W (model:AR-HE-GK4NW) ● Upper cooking zone up to max. 2300W (model:AR-HE-GK5NW) ● Lower cooking zone up to max. 1200W (model: AR-HE-GK2NW/AR-HE-GK4NW/AR-HE-GK5NW) 7.3 Extra cooking zone for the Double/Triple/Oval zone ● The Double/Triple/Oval cooking zone have three heating zones, so you can see a central heating zone (A) or two (B) or three (C) or oval zone at once. -
Page 10: Residual Heat Indicator
The residual heat indicator warns for each cooking zone separately with the "H" symbol. 7.5 Timer 7.5.1 Model:AR-HE-GK2NW ● Select the desired cooking zone with the corresponding slider control. ● Press the timer button , The timer indicator will show “30” minutes. -
Page 11: Safety Systems
User’s Manual – A S Glass ceramic hob REBO 7.5.3 Canceling and changing the time setting: • To cancel the time setting, press the timer key again. The remaining time display and the red dot disappear and the timer is canceled. •... -
Page 12: Cleaning And Maintenance
User’s Manual – A S Glass ceramic hob REBO Hotplates should not be switched on without a pan on top. The base of the pan should be flat and dry. Pans that have been used on gas cookers are not normally completely flat and absorb heat badly. -
Page 13: Troubleshooting
User’s Manual – A S Glass ceramic hob REBO Clean the radiant glass surface frequently, when it is cool. Never use abrasive products or pads. Clean with a damp cloth and soapy water. Once a week, clean thoroughly with specific products that preserve and protect radiant cooktops hobs. -
Page 14: Error Codes
User’s Manual – A S Glass ceramic hob REBO contact a qualified technician. Board error Contact a certified electrician The touch controls are The control is locked/the key Unlock the control panel. unresponsive lock has been activated See safety chapter. The touch controls are difficult There is a slight film of water Make sure the touch control... -
Page 15: Environmentally Friendly Disposal
You can obtain the addresses from your city or local government. You can find out about other return options created by us on our website www.arebos.de. The separate collection of WEEE is intended to enable the reuse, recycling or other forms of recovery of WEEE and to avoid the negative consequences of disposal on the environment and human health. -
Page 16: Eu Declaration Of Conformity
Hereby declare that the devices described in the following comply with the relevant, fundamental safety and health requirements of the EU directives due to their design and construction as well as in the versions marketed by us. Product name: AREBOS Glass ceramic hob Article number: 4252023117241 4252023117227 4252023117234 Model number: AR-HE-GK2NW AR-HE-GK4NW AR-HE-GK5NW If the device is modified without our consent, this declaration of conformity loses its validity. - Page 17 REBO Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 97074 Würzburg You can find the return address in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 The court of entry in the commercial register is Würzburg, HRB 10082 WEEE-Reg.-Nr. DE 61617071...
