Summary of Contents for AREBOS AR-HE-IK4
- Page 1 User’s Manual – A S Induction hob 4 hot plates REBO Induction hob 4 hot plates AR-HE-IK4 Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Induction hob 4 hot plates REBO List of contents 1. Safety instructions .......... 3 1.1 Introduction ..............3 1.2 Explanation of the symbols ..........3 1.3 General safety instructions ..........4 2. Installing the device ........5 3. -
Page 3: Safety Instructions
User’s Manual – A S Induction hob 4 hot plates REBO Thank you for buying our product. Please read the operating instructions carefully before using the product for the first time. If you hand over the product to third parties, these operating instructions must also be handed over. -
Page 4: General Safety Instructions
User’s Manual – A S Induction hob 4 hot plates REBO Warning of electrical voltage! 1.3 General safety instructions • Your safety is most important to us. Therefore, please ensure that you read the instruction manual before installing and using the induction hob. If you are unsure about any information in this manual, please contact the dealer from whom you purchased the appliance. -
Page 5: Installing The Device
User’s Manual – A S Induction hob 4 hot plates REBO • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand hazards involved. -
Page 6: Commissioning The Device
User’s Manual – A S Induction hob 4 hot plates REBO • The distance between the underside of the appliance and the separator panel must respect the dimensions given in the figure (min. 50 mm). • In order to ensure the correct operation of the product, do not obstruct the minimum required clearance (min. - Page 7 User’s Manual – A S Induction hob 4 hot plates REBO • Attention! To avoid permanently damaging the glass-ceramic top, do not use: Pots with bottoms that are not perfectly flat. Metal pots with enameled bottom.
-
Page 8: Technical Data
User’s Manual – A S Induction hob 4 hot plates REBO 4. Technical data Model AR-HE-IK4 Product dimensions 590 x 520 x 59 mm Installation dimensions 560 x 490 x 52 mm Voltage 220-240 V Frequency 50/60 Hz Maximum power... -
Page 9: Switching The Hob On/Off
User’s Manual – A S Induction hob 4 hot plates REBO 6.1 Switching the hob On/Off • To switch the hob on, press the button and the cooking zone display light up. To switch off, press the same button until the display switches off. All the cooking zones are deactivated. -
Page 10: Auto Switch Off
User’s Manual – A S Induction hob 4 hot plates REBO 6.7 Auto switch off • The hob will automatically switch off when you did not set cooking time, forgot to switch off the hob and did not operate the hob at all. The relationship between the power level and default switch off time is shown in below figure. -
Page 11: Cleaning
User’s Manual – A S Induction hob 4 hot plates REBO Ideal for long-cooking recipes (rice, sauces, roasts, fish) Medium level with liquids (e.g. water, wines, broth, milk), creaming Cooking / pasta simmering / Ideal for long-cooking recipes (less than a liter in thickening / volume: rice, sauces, roasts, fish) with liquids (e.g. -
Page 12: Noises Made By The Hob
User’s Manual – A S Induction hob 4 hot plates REBO Error Possible Cause Remedy code No Pan or did not detect the pan Put on the pan NTC short or open Contact the after-sales service and specify the error code High voltage Contact the after-sales service and specify the error code... -
Page 13: Environmentally Friendly Disposal
You can obtain the addresses from your city or local government. You can find out about other return options created by us on our website www.arebos.de. The separate collection of Waste electrical and electronic equipment is... -
Page 14: Eu Declaration Of Conformity
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 97074 Würzburg You can find the return address in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 The court of entry in the commercial register is Würzburg, HRB 10082 WEEE-Reg.-Nr. DE 61617071...
