- Page 1 YL-300PB Ink jet printing & banding machine User manual...
-
Page 3: Table Of Contents
Contents 1. For your safety 2. Product Introduction and package details 3. Part name and function how to set the printing 4. Installing and removing of band. 5. How to control the temperature 6. How to control the length 7. How to band and print at the same time 8. -
Page 4: For Your Safety
For your safety For your safety Please carefully read this user manual before operating the machine. Maintenance requirements 1. Make sure AC 220V power is supplied. The voltage fluctuation must be kept at a minimum. 2. High temperature, high humidity or any other environmental conditions may render the unit not operational due to the tape being jammed around the roller or otherwise. -
Page 5: Product Introduction And Package Details
Product Introduction and package details Ink Jet Printing& Banding Machine(YL-300PB) *Multi System - Bank notes are banded and printed at the same time. - Contents to be printed are typed in using WIFI from the administrator's smart phone. - Various information including bank name, i.e., Bank name, branch name, operator, year, month, day, hour, minute, current count, and etc. -
Page 6: Part Name And Function How To Set The Printing
Part name and how to set the printing [ Banding part ] Power/Reset (red) Button Auto/Forwarder (yellow) Button Start/Backward (green) Button Print Ink cartridge exchange On Spacer Beak Reverse click Idle Roller Guide roller Main roller Roll fixing Toggle switch band unroll direction Length control volume... - Page 7 Please enter the desired information according to the method below. ◆ Connecting to smart device 1. In the smart device settings, select Bindtec YL-300PB-xxxxxx and when the password window appears, enter 12345678 to connect. 2. Open the Internet (Chrome, etc.) and enter 192.168.4.1 in the address bar to display...
- Page 8 4. Select what to print on the second line. 5. Click the Upload button to save the data. Example) Select 4th Data Format, 3rd Select Time Format, write "Bindtec" in User Input1, write "Kim" in User Input2, select 1st in Line1, select 3rd in Line2, press the Upload button and operate the set It is printed as follows.
- Page 9 ◆ Set the printing time When you press the Time button, the following screen appears. Time can be saved in two ways 1. If you click the Upload button of Local Time, the time of the smart device is saved as the set time.
- Page 10 5. If you save the password after turning on the password, the password input window is displayed. In this case, be careful not to forget the password. If you forget your password, please contact BINDTEC.
-
Page 11: Installing And Removing Of Band
Installing and removing of band ④ Idle roller ③ Guide roller ①Power/Reset button ⑥Auto/forward button ⑤ Main roller ⑦Start/backward button fixing ② Roll ⑨Toggle switch Length ⑧ control volume 1. Open the Front Plate. ⑨Toggle Switch can change the mode from “Feed” to “Start.” The machine is in Inserting Band Mode if the switch is raised, and the lamp of the ①... -
Page 12: How To Control The Temperature
A blinking ① Power Button indicates that the current temperature has reached its set value. Moreover, pushing the ① Power Button will cut off any leftover band, and a new band should be placed in the machine (please hold the ends of the band during automatic cutting). -
Page 13: How To Band And Print At The Same Time
How to band and print at the same time Preparation} 1. Connect the power cable to the power inlet 2. Turn the power switch ON. 3. Feed the band to the unit as explained above. 4. Move the toggle switch down to switch to banding mode. 5. -
Page 14: How To Change Ink Cartridge And Battery
How to change ink cartridge and battery [Cartridge exchange] Proceed in the order below. 1. After power on the and move the ink exchange switch upwards(On) to move the cartridge to a good position for replacing the cartridge. (The cartridge on the right prints the top row, and the left one prints the bottom row.) 2. -
Page 15: Checking Before Troubleshooting
Checking before troubleshooting If the machine does not operate or does not operate smoothly, check the following. 1) Check if the power/reset button (red) and start/reverse button (green) are turned on when the power is turned on. 2) If only the power/reset button (red) is on and blinking, open the front case and move the toggle switch to the bottom. -
Page 16: Product Specifications
Product specifications 18 cycles/minute Speed 135 (w) x 100(H) mm Banding Size AC 110,220V /50,60H,z 1.6A Power Supply 150W Power Consumption Plate type Heater paper 30,40mm Band Width 410 (W) × 320 (D) × 500 (H) mm Product Dimensions 24kg Weight... -
Page 17: Warranty
WARRANTY BINDTEC Co., Ltd., warrants that it will repair and replace parts under the following terms if any defects in the material or workmanship of the binder occur within 12 months from the day of purchase by the user. A purchase receipt or other evidence for the date of purchase must be shown to receive warranty services. - Page 20 #1018~19, 177 Sagimakgol-ro, Jungwon-gu, Seongnam-si, Gyeonggi-do, S. Korea 13202 Tel.: +82-31-734-2868 / Fax: +82-31-734-2869 Email: sales@bindtec.kr http://www.bindtec.kr...
