- Page 1 YL-420(S) USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS 1. Safety Features Overview and Precaution 2. Product Introduction and Accessories 3. Part Names and Functions 4. Band Installation 4-1) How to feed the band for 420(30)(50) 4-2) How to feed the band for 420S 5. Operation 5-1) How to change Standby Time before Banding 5-2) Banding Regardless of Sensor Detecting an Object 6. -
Page 3: Safety Features Overview And Precaution
Safety Features Overview and Precaution For your safety Please read this user manual carefully before operating the banding machine. Maintenance requirements 1. Make sure that the power is supplied. Voltage fluctuation must be kept at a minimum. 2. High temperature and humidity or any other environmental conditions may render the unit nonoperational as the band may get jammed around the roller and so on. -
Page 4: Product Introduction And Accessories
Product Introduction and Accessories Automatic banding machine with paper/film YL-420(30)(50),420S * Easy installation for easy relocation * Korea’s first rail banding machine * Compatible of paper and film bands * Banding without warming up * Banding without any odor and harmful substances... -
Page 5: Part Names And Functions
Part Names and Functions 5. Object Sensor Arch 9. Rail 2. Feed Button Opening/Closing Lever 3. Auto Button 4. Start Button Front Cover 1. Power Switch 8. Band Set Lever 7. Tension Control Knob 6. Temperature Band Reel Cover Control Knob... - Page 6 1. Power Switch Turn the power ON or OFF. 2. Feed Button The band is fed to the rail when the red button is pressed. RED LED lights up when the band is normally set. Otherwise, the RED LED blinks. 3.
-
Page 7: Band Installation
Band Installation 4-1) How to feed the band for 420(30)(50) 1) Check the condition of the band. Cut off the end of the new band with scissors if it is roughly cut, wrinkled, or contaminated, as such poor conditions may cause a jam. 2) Pull the front cover and band reel cover to open them. -
Page 8: 4-2) How To Feed The Band For 420S
4-2) How to feed the band for 420S 1) Check the condition of the band. Cut off the end of the new band with scissors if it is roughly cut, wrinkled, or contaminated, as such poor conditions may cause a jam. 2) Turn the toggle switch to OFF. - Page 9 6) While holding the band anti-skid lever with your hand, insert the band in order and release the band anti-slip lever again. (If the band is inserted normally, the band will rise from the bottom of YL-420 on top.)
- Page 10 8) After turning the toggle switch to ON, supply the band. 9) When the band supply is complete, insert the band from ‘6)’ into the YL-420 and press the feed button. At this time, the feed motor rotates and the band is accurately seated on the rail.
-
Page 11: Operation
Operation 1) Turn ON the power using the power switch. Power 2) Check whether the FEED BUTTON LED START BUTTON LED are lit. Feed Button 3) Auto Mode: Press the Auto Button Auto Button to turn on the ORANGE LED. Then, put an object on the object sensor to allow the machine to start Start Button banding automatically. -
Page 12: 5-1) How To Change Standby Time Before Banding
5-1) How to change Standby Time before Banding You can adjust the time to start banding after the sensor detects an object in auto mode using the heater temperature control knob. Min 0.0 sec Max 1.0 sec Turn OFF the power switch → Press the feed button → Turn ON the power switch →... -
Page 13: Sheet Replacement
Sheet Replacement 1) Take out the installed band. 2) Turn OFF the power switch → Turn ON the power switch while pressing the feed and auto buttons together → Check if both FEED BUTTON LED AUTO BUTTON LED are blinking → Release the feed and auto buttons Hold plate 3) Operate the machine by repeatedly pressing the feed button for a short period until the hold plate... -
Page 14: 6-1) Life Expectancy Of Heater Sheet
9) Turn ON the power by pressing the power switch. 10) Press the start button, and the rail and hold plate will return to their initial positions. 6-1) Life expectancy of Heater Sheet Check the condition of the heater sheet before starting the banding operation. The sheet has expired if its color has changed to black, and it would need to be replaced with a new one. -
Page 15: Failed Band Removal
Failed Band Removal When the rail is jammed with the band: 1) Turn OFF the power switch. 2) Press the rail opening/closing lever to open the rail. 3) Cut the band around the hold plate using scissors. 4) Turn the band roll counterclockwise to completely remove the band. -
Page 16: Checking Before Troubleshooting
Checking before Troubleshooting Check the following if the machine cannot operate or the operation is not smooth: 1) If the START BUTTON LED is OFF: *Check if the power cord is plugged. *Check if the power switch is turned OFF. →... -
Page 17: Extra Functions
Extra Functions The following functions operate when each button is pressed and held: 9-1) Feed Button 9-2) Auto Button 9-3) Start Button Band Removal in case of Jam 9-1) Feed Button (Red): Used to remove the band in a jam Press and hold the feed button. -
Page 18: 9-3) Banding Soft Object
Press and hold the auto button once again to exit. Then, the buzzer will ring once to confirm that the mode has been deactivated. 9-3) Banding Soft Object Start Button(Green): Used to enter or exit the “After banding, the slide moves forward and feeds if no object is sensed”... -
Page 19: Specifications
Specifications 420(30): 26 cycles/min Banding Speed 420(50): 24 cycles/min Min: 30 (W) × 10 (H) mm Banding Size Max: 400 (W) × 200 (H) mm AC 110/220 V, 50/60 Hz Power Supply 250 W Power Consumption 0.5~4 kg Tension 420(30): paper/film 30 mm Band Width 420(50): paper/film 50 mm 560 (W) -
Page 20: Product Warranty
Product Warranty BINDTEC Co., Ltd. warrants that it will repair and replace parts under the following terms if any defects in the material or workmanship of the machine occur within 12 months from the day of purchase by the user. - Page 22 #1018~1019, 177 Sagimakgol-ro, Jungwon-gu, Seongnam-si, Gyeonggi-do, Republic of Korea Tel : +82-31-734-2868 / Fax : +82-31-734-2869 E-mail: sales@bindtec.kr http://www.bindtec.kr...
