- Page 1 YL-303series User manual...
-
Page 3: Table Of Contents
Table of Contents 1. Product Description 2. Band Installation and Unpacking 3. Major Part 4. Operation & Temperature and Tension Control 5. Troubleshooting 6. Cleaning & Maintenance Warning 1. Make sure that the rated AC voltage complies with the marked AC power beside the product before you plug the power cord in the power inlet. -
Page 4: Product Description
1. Product Description ● Designed the machine to be used in the office and small space. ● It straps the package automatically by start button or foot switch ● Reduce the error to the minimum ● Installed the jam free mechanism ⅰ. -
Page 5: Band Installation And Unpacking
2. Band Installation and Unpacking 1. Installation YL-303R *First be sure that band is in slot correct direction and then insert the band into the reel guide. *If the tip of band is much bend or damaged, cut it off by scissor. 2. - Page 6 1. Installation YL-303H *First be sure that band is in correct direction and then insert the band into the reel guide. slot pentagonal wrench *If the tip of band is much wrench bolt bent or damaged, cut it off by scissor.
- Page 7 YL-303B 1. Installation *First be sure that band is in correct slot direction and then pentagonal wrench insert the band into the reel guide. *If the tip of band is much wrench bolt bent or damaged, cut it off by scissor.
-
Page 8: Major Part
3. Major Part YL-303H top plate power cable inlet safety s/w machine assemble heater volume slot chassis foot s/w inlet reel operation panel YL-303B top plate pushing s/w safety s/w machine assemble heater volume slot *Press the pushing s/w to strap package. - Page 9 Major part of the machine feed slide set chute guide slide cam motor reduction gear slide guide heater guide main motor main roller heater ms15 band storage box 슬라이드 ms17 slide guide idle lever tension device idle lever tension lever solenoid-1 solenoid-2...
- Page 10 4.Operation [GENERAL] Place the package after band installation, and press the start button. Then the machine straps the package and the band feeds again automatically for next strapping. 1. Turn the power switch on and preheat the machine about 1minute. 2.
- Page 11 reset button: If any problem happens with the machine, pull the band out of the machine, and press the reset button. This button will not operate after the band is installed. release button: This button is to remove the damaged band. If the band stop during feeding or if you like to remove the band, then pull the while pressing this release button.
-
Page 12: Troubleshooting
5.Troubleshooting STATE Check and Management *Check if the power cord is unplugged.(Check if the power is on.) 1. Machine does not *Check if the voltage is AC220 operate *Check if the safety switch operate.(Check if the cover is properly closed) 2. -
Page 13: Cleaning & Maintenance
6.Cleaning & Maintenance *Cleaning of idle roller and main roller Separate the snap ring and disassemble the idle roller. Remove band debris by using methyl alcohol. Press the start switch and clean the surface of roller clearly. *Cleaning of slide and heater Disassemble and remove the band debris by using methyl alcohol. - Page 14 PRODUCT WARRANTY BINDTEC CO.,LTD warrants that it will repair and replace parts in accordance with the following terms if any defects in the material or workmanship of the binder occurs within 12 months from the day on which the user purchases it.
- Page 16 BINDTEC CO.,LTD #1011,177 Sagimakgol-ro,Jungwon-gu, Seongnam-si, Gyeonggy-do, Korea TEL : +82-31-734-2868 FAX : +82-31-734-2869 E-mail : sales@bindtec.kr http://www.bindtec.kr...
