FULMINE USER MANUAL
LPOL14KOS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FULMINE LPOL14KOS and is the answer not in the manual?

Questions and answers

Related Manuals for Solaris FULMINE LPOL14KOS

Summary of Contents for Solaris FULMINE LPOL14KOS

  • Page 1 FULMINE USER MANUAL LPOL14KOS...

  • Page 2: Table Of Contents

    Contents Instruction ---------------------------------------------------------------------------------------------2 ----------------------------------------------------------------------2 Application According to Purpose ---------------------------------------------------------------------------- ------------2 Indoor use only ----------------------------------------------------------------------------------------2 Safety operation 2 Lamp --------------------------------------------------------------------------------------------------3 3 Supply Voltages, Mains Cord and Connection to Mains ------------------------------3 Housing -------------------------------------------------------------------------------------------------4 Operating Environment ---------------------------------------------------------------------------4 Installation -------------------------------------------------------------------------------------------- 5 7 Operation ------------------------------------------------------------------------------------------- 6 -------------------------------------------------------------------------------------------- 6 Controls ---------------------------------------------------------------------------------------- 6...

  • Page 3: Instruction

    1. Instruction 1.1Application According to Purpose This product is a lighting effect which creates special light effects with one lamp. To generate these effects, ● the product must be connected to mains and a DMX-512 compatible controller. This product is designed for 110/230V, 50/60Hz operation and exclusively for indoor use. ●...

  • Page 4: Housing

    Housing ATTENTION: DANGER OF LIFE! RISK OF BURNS! RISK OF FIRE! RISK OF SHORT CIRCUIT! Always ensure during inst3ll3tion, operation, transport and when storing the product that no shocks or other ● forces impact the housing! The housing must not touch onto any other devices or objects during operation! ●...

  • Page 5: Operation

    This product can be operated suspended or as a stand-alone system. Should your lighting effect show any signs of damage, do not install the device! In this case, have your lighting effect repaired by your specialized dealer. The manufacturer does not accept responsibility or liability for damage to property or personal injury resulting from an improperly installation! As a stand-alone system the device must be installed vertically on an absolute planar, firm, fireproof, shock- and vibration-free surface.

  • Page 6: Menu Structure

    ■ Channel：Show current channel ■ Mode：Show current run mode ■ Temp：Show current temperature First page of menu ● 001 Return 中/EN Invert Setup ■ Add：Setup address ■ Return：back to display 中/EN：Press or ENTER to change the language ■ ■ Invert：For display invert ■...

  • Page 7: Channel

    Adjust Inset password Light correct Corresponding current Test 0-255 channel Return YES/NO Reset Head YES/NO Reset Reset XY YES/NO Reset All YES/NO 　 Error message Error message DMX data Channel value Info SoVware version 01-01-01 　 Usage Pme 7.3 Channel Function DMX Value Function...
  • Page 8 Color 5 30～35 Color 6 36～41 Color 7 42～47 Color 8 48～53 Color 9 54～59 Color 10 60～65 Color 11 66～71 Color 12 72～77 White + Color 1 78～83 Color 1+ Color 2 84～89 Color 2+ Color 3 90～95 Color 3+ Color 4 96～101 Color 4+ Color 5 102～107...
  • Page 9 Gobo4 25～29 Gobo5 30～34 Gobo6 35～39 Gobo7 40～44 Gobo8 45～49 Gobo9 50～54 Gobo10 55～59 Big white shake 60～64 Middle white shake 65～74 Small white shake 75～84 Gobo1 shake 85～94 Gobo2 shake 95～104 Gobo3 shake 105～114 Gobo4 shake 115～124 Gobo5 shake 125～134 Gobo6 shake 135～144...
  • Page 10 White shake 80～89 Gobo1 shake 90～99 Gobo2 shake 100～109 Gobo3 shake 110～119 Gobo4 shake 120～129 Gobo5 shake 130～139 Gobo6 shake 140～149 Gobo7 shake 150～159 Anti-clockwise water flowing effect of gobo, 160～205 from fast to slow White 206～209 Clockwise water flowing effect of gobo, 210～255 from slow to fast Gobo rotation...

  • Page 11: Use Of The Replacement

    Macro function Without effect 0～49 Fixed gobo focus automatically at 5M 50～59 Fixed gobo focus automatically at 10M 60～69 Reserved function 70～149 Rotation gobo focus automatically at 5M 150～159 Rotation gobo focus automatically at 10M 160～169 Reserved function 170～255 Reset Without effect 0～100 Effect motor reset(keep 5 seconds)
