GR Product Name: GRACE NON TUFTED KING BED
GR Product Number: 182403A PCO KIN / 182403B PCO KIN / 182403A PCC KIN / 182403B PCC KIN
Assembled Dimension: 82.67"W x 90.75"D x 58.25"H
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 21.11.2024
Prevent accidentally discarding small parts
or hardware. Retain all carton contents until
assembly and installation are complete.
Product Specialist: 800-491-4958
Online: www.grandinroad.com
MADE IN VIETNAM
Page 1 of 8
Advertisement
Related Manuals for Grandinroad GRACE 182403A PCO KIN
Summary of Contents for Grandinroad GRACE 182403A PCO KIN
- Page 1 Product Specialist: 800-491-4958 Online: www.grandinroad.com GR Product Name: GRACE NON TUFTED KING BED GR Product Number: 182403A PCO KIN / 182403B PCO KIN / 182403A PCC KIN / 182403B PCC KIN Assembled Dimension: 82.67"W x 90.75"D x 58.25"H Prevent accidentally discarding small parts or hardware.
-
Page 2: Required Tools
Ø5/16 " x 19mm Allen key 4 x 60mm Full - Thread Bolt Ø5/16 " x 55mm Curve Washer Ø5/16 " Hex Nut Ø5/16 " Screw #4 x 30mm Open Wrench MADE IN VIETNAM Product Specialist: 800-491-4958 Page 2 of 8 Online: www.grandinroad.com... - Page 3 Assemble in location for intended use Ltr. Qty. Components Headboard HB Post Leg - L HB Post Leg - R Wood block Footboard Side Rail - L & R Slat Roll Support Leg MADE IN VIETNAM Product Specialist: 800-491-4958 Page 3 of 8 Online: www.grandinroad.com...
- Page 4 Step 1: Take the HB Post Leg - L (L) and HB Post Leg - R (M) out of the back Headboard (K). Step 2: Attach the Wood Block (N) to the HB Post (L), (M) by using Bolt(B) with the Allen Key (E). MADE IN VIETNAM Product Specialist: 800-491-4958 Page 4 of 8 Online: www.grandinroad.com...
- Page 5 Step 3: Attach the HB Post Leg - L (L) and HB Post Leg - R (M) to theHeadboard (K) using Bolt (A), Spring Washer (C) and Flat Washer (D)with the Allen Key (E). Step 4: Attach the Legs (S) to the Footboard (O). MADE IN VIETNAM Product Specialist: 800-491-4958 Page 5 of 8 Online: www.grandinroad.com...
- Page 6 Footboard (O) using Thread Bolt (F), Curve Washer (G) and Hex Nut (H) with the Open Wrench (J). P(R) P(L) Step 6: Attach the Support Leg (R) to the Slat Roll (Q). MADE IN VIETNAM Product Specialist: 800-491-4958 Page 6 of 8 Online: www.grandinroad.com...
- Page 7 Step 7: Place the Slat Roll (Q) to Side Rail - L&R (P). P(L) Step 8: Tighten Screws (I) to the Side Rail - L&R (P) with Screwdriver(not included). MADE IN VIETNAM Product Specialist: 800-491-4958 Page 7 of 8 Online: www.grandinroad.com...
- Page 8 Clean with soft cloth only. Please contact one of our Product Specialists for assembly assistance or questions at 1-800-491-4958 or email ps@grandinroad.com. Specialists are available weekdays 8:00am to 8:00pm EST or Saturday 9:30am to 6:00pm. MADE IN VIETNAM Product Specialist: 800-491-4958 Page 8 of 8 Online: www.grandinroad.com...
