Installation Instructions for
K-117 Add-A-Faucet
(Connecting to a DTA-53, K-115 & K-116
Prerinse Faucet)
CHECK FOR CONCEALED DAMAGE
FILE CLAIM WITH DELIVERING FREIGHT CARRIER
WARNING:
Equipment that includes a faucet may expose you to chemicals, including lead, that are known to the
State of California to cause cancer or birth defects or other reproductive harm. For more Info.,visit www.p65warnings.ca.gov.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Add-A-Faucet K-117 and is the answer not in the manual?

Questions and answers

Related Manuals for Advance Tabco Add-A-Faucet K-117

Summary of Contents for Advance Tabco Add-A-Faucet K-117

  • Page 1 Installation Instructions for K-117 Add-A-Faucet (Connecting to a DTA-53, K-115 & K-116 Prerinse Faucet) Equipment that includes a faucet may expose you to chemicals, including lead, that are known to the State of California to cause cancer or birth defects or other reproductive harm. For more Info CHECK FOR CONCEALED DAMAGE Faucets on this page may expose you to chemicals, including lead, that are known to the State of California to cause cancer or birth defects or other reproductive harm.
  • Page 2 Step 1: Locate the longest Chrome Riser from Prerinse Faucet model DTA-53, K-115 or K-116 (Figure A). Remove the bottom nut from this Riser (Figure B & C). (Figure B) Bottom Riser (Figure A) (Figure C) Step 2: Using the Riser Nut you just removed in Step 1, insert the Nut onto the Prerinse Faucet Body and tighten (Figure D &...
  • Page 3 Step 3: Insert the K-117 Faucet Body tightly into the Riser Nut on the Prerinse Body and tighten. (Figure F). K-117 Body (Figure F) Step 4: Locate the long Prerinse Riser and insert into the smaller existing thread on the K-117 Body and tighten (Figure G & H). Long Riser (Figure G)
  • Page 4 Step 5: Insert K-117 Swing Spout into the existing thread on the K-117 Body, and tighten nut (Figure I & J). (Figure I) (Figure J) Step 6: Check all connections and make sure they are tight. Long Riser From Prerinse K-117 Swing Spout K-117 Body Riser Nut...
