Installation Instructions For
"EC" SERIES DROP-IN SINKS
DI-1-5SP-EC
DI-1-10SP-EC
DI-3-10-EC
DI-2-10-EC
WARNING:
Equipment that includes a faucet may expose you to chemicals, including lead,
that are known to the State of California to cause cancer or birth defects
or other reproductive harm. For more Info.,visit www.p65warnings.ca.gov.
CHECK FOR CONCEALED DAMAGE
FILE CLAIM WITH DELIVERING FREIGHT CARRIER
Advertisement
Table of Contents
Related Manuals for Advance Tabco EC Series
Summary of Contents for Advance Tabco EC Series
- Page 1 Installation Instructions For “EC” SERIES DROP-IN SINKS DI-1-5SP-EC DI-1-10SP-EC DI-3-10-EC DI-2-10-EC WARNING: Equipment that includes a faucet may expose you to chemicals, including lead, that are known to the State of California to cause cancer or birth defects or other reproductive harm. For more Info.,visit www.p65warnings.ca.gov. CHECK FOR CONCEALED DAMAGE FILE CLAIM WITH DELIVERING FREIGHT CARRIER...
- Page 2 Contents: Material Required: (1) Drop-In Sink • Silicone Sealant (1) Gooseneck 4” O.C. Deck Mount Faucet • Plumbing Putty (1 OR 2) K-6 Basket Drain(s) (4) Under-Counter Mounting Brackets (4) Nuts Tools Required: Recommended Safety • Ruler or Tape Measure Materials: •...
- Page 3 STEP 3 • Install Drain(s) through Sink Body. Apply a bead of Plumber’s Putty on the inside between the Drain Flange and Sink. Follow steps below... 1. Add Rubber Washer 2. Add Fiber Washer 3. Screw on Die Cast Nut and Tighten STEP 4 •...
- Page 4 Front To Back DI-5-SP-EC 10 1/2” 16 3/4” DI-1-10SP-EC 10 1/2” 16 3/4” DI-2-10-EC 23 1/2” 17 1/2” DI-3-10-EC 35 1/2” 17 1/2” For Further Assistance Contact Customer Service at: 800-645-3166 customer@advancetabco.com Edgewood, New York 11717-8380 ©ADVANCE TABCO SEPTEMBER 2018...
