N410/N610/N620/MF Series
A3 Paper Feed Unit 설치 수순서
A3 Paper Feed Unit 设置顺序书
How to Install A3 Paper Feed Unit

Advertisement

loading
Need help?

Need help?

Do you have a question about the N410 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sindoh N410 Series

  • Page 1 N410/N610/N620/MF Series A3 Paper Feed Unit 설치 수순서 A3 Paper Feed Unit 设置顺序书 How to Install A3 Paper Feed Unit...
  • Page 2 2. 설치 절차 A3 Paper Feed Unit 설치 수순서 적용 제품 : N410, N610, N620 Series ● 본체와 연결하는 방법 1. 액세서리 점검 Tape를 제거 하고 모든 Tape 및 포장재가 제거 되었는지 다시 확인해 주십시오. 다음 목록과 액세서리의 수량 및 상태를 점검해 주십시오. 주의 - 쐐기 부품 [A]를 제거하십시오. 이름 모양 수량 제거 방법: Jam Door을 열고 Jam Door를 Bolt 잡은 후 쐐기의 끝단을 당기시면 됩니다. M4X10 쐐기 [A]의 위치는 아래의 그림을 참고해 주십시오.
  • Page 3 A3 Paper Feed Unit의 저판에 Safety Part를 복합기의 2단 Tray [F]를 제거해 주십시오. Bolt [E](부품1) 4개로 고정해 주십시오.(Bolt (Tray 제거시 Side Fence를 A5용지 위치로 조립시 hole을 볼 수 있게 Safety Part 위치 조정후 빼내 주십시오.) 조정함) A3 Paper Feed Unit의 Tray [B]/[C]를 다시 세트해 주십시오.(Tray 세트시 Side Fence를 A5용지 위치로 조정후 세트해 주십시오.) 복합기를 A3 Paper Feed Unit에 세트해 주십시오. A3 Paper Feed Unit를 2개의 Bolt [E](부품1)로 고정시켜 주십시오. 복합기의 2단 Tray를 다시 세트해 주십시오. (Tray 세트시 Side Fence를 A5용지 위치로 조정 후 세트해 주십시오.)
  • Page 4 복합기의 후측 Cover [G](Bolt 14개)를 제거해 복합기의 후측 Cover [G]를 다시 세트해 주십시오. 주십시오.(Bolt 12개 조립)(2개 Bolt (P)는 연결 Bracket [K]을 고정시 사용함) 표시된 그림대로 케이블 [H]를 복합기의 Connector와 연결해 주십시오. 그리고 Clamp (I)를 본체 Frame에 설치한 다음에 [H]를 고정해 주십시오. 연결 Bracket [K]를 좌/우측에 각각 장착해 주십시오.(Bolt 각 2개) 용지를 용지 Tray에 넣고 메인 스위치를 켜 주십시오. 시스템의 작동과 복사 품질을 점검해 주십시오.
  • Page 5 A3 Paper Feed Unit 设置顺序书 2. 设置顺序 ● 与本体的连接方法 适用产品:N410,N610,N620 Series 请拆除胶带后再次确认所有胶带及包装材料是 1. 同封品清点 否已经全部拆除。 请参照以下目录清点同封品的数量和状态。 注意 - 请拆除掉楔子部品[A]。 名称 图 示 数量 拆除方法: 打开Jam Door, 扶住Jam Door并 螺丝 拽动楔子的端部将其取出。 M4×10 楔子部品[A]的位置请参考下图。 螺丝 M3×6 连接铁片 警告 安全部件 - 将复合机向A3 Paper Feed Unit上设置前 请务必再次确认电源线的安全性。...
  • Page 6 请将A3 Paper Feed Unit底板上的安全部件用 请将复合机的2段 Tray[F]拆除。 (Tray 拆除时 4个螺丝[E](部品1)固定好。 (螺丝组装时可以 请将Side Fence调整至 A5用纸的位置后再进行 调整安全部件的位置使得螺丝孔对正) 拆除) 请将A3 Paper Feed Unit的 Tray[B]/[C]重新 设置。 ( Tray 设置时请将Side Fence调整至 A5 用纸的位置再进行设置) 请将复合机设置在 A3 Paper Feed Unit上。 请将A3 Paper Feed Unit通过 2个螺丝[E]进行 固定。 请将复合机的2段Tray重新设置好。 (Tray 设置时请将Side Fence调整至A5用纸的 位置再进行设置)
  • Page 7 请将复合机后盖[G](14个螺丝)拆除。 请将复合机的后盖[G]重新设置好。 (组装12个螺 丝)(2个螺丝(P)在固定连接铁片[K]时使用) 如图所示请将电线[H]与复合机的Connector 进行连接, 然后将线夹(I)设置在本体Frame 上, 对[H]进行固定。 请将左右两侧的连接铁片[K]进行安装。 (各 2个螺丝) 请将用纸放入用纸Tray中并开启主开关。 请对系统运转状态及打印品质情况进行确认。...
  • Page 8: Check Accessories

    How to Install A3 Paper Feed Unit 2. Installation procedure Applicable products : N410, N610, N620 Series ● How to connect to the device body Remove all tapings and wrappings and make 1. Check Accessories sure they are all removed. Refer to the following list to check the number of Caution accessories and their conditions.
  • Page 9 On the lower pate of the A3 Paper Feed Unit, Remove the upper Tray [F] from the MFP. use 4 bolts [E](part1) to secure the safety (When removing the tray, adjust the side part.(adjust position of the safety part to fence to the A5 paper position first.) make the holes visible when fastening bolts.) Place Tray [B] and [C] of the A3 Paper Feed...
  • Page 10 Remove the rear cover [G](14 bolts) from the Fasten 12 bolts to put the rear cover [G] back MFP. to the device (use 2 bolts, in (P), to fix the connection bracket [K]). As in Figure, connect the cable [H] to the connector of the device.
  • Page 11 ■ Memo...
  • Page 12 JSBK9932D *JSBK9932D* Printed in China...
