- Page 1 NEWPORT STATION QUICK INSTALLATION GUIDE JUD200...
-
Page 2: Getting Started
GETTING STARTED... - Page 3 Step 1. Start Device Driver Installation (In the next section please refer to the installation steps that correspond to your PC system’s OS.) • Please install the driver completely before following the steps below. Step 2 Plug the Power Adapter into Port 1 Step 3. Connect the USB 2.0 Cable Micro-B connector to Port 2 and the Type-A connector to the host laptop. Step 4.
-
Page 4: Step 1. Device Driver Installation
When the installation is complete, select “Yes, I want should launch automatically. to restart my computer now” and click “Finish” to restart. • Make sure that the Newport Station is NOT connected to your host computer. *Driver download is available at www.j5create.com in “support > download” area. Executing the Setup.exe application will launch the following screen. Click ”Next” to continue. - Page 5 Installation on MAC (Snow Leopard) Insert the Driver CD into the CD-ROM drive and run Click “Continue” and “Agree” to proceed the “LAN9500-2.2.0.pkg” file to draw drivers. • Make sure that the Newport Station is NOT connected to your host computer. *Driver download is available at www.j5create.com in “support > download” area.
- Page 6 Run the “NEWPORTSTATION.dmg” drivers. Type your password then click “OK”. It will take few minutes to process. When installation has completed, click “Close”. Click “j5create-NEWPORT-STATION-V.XXXXX”...
- Page 7 Type your password then click “OK”. Click “Continue” to proceed It will take few minutes to process. Click “Restart” to complete...
- Page 8 Extra Features Cooling Function: Set your laptop on the top of the j5 create Newport Station to keep your laptop cool. Hardware Specific Function...
- Page 9 DISPLAY FUNCTION INSTRUCTIONS: Display Mode Display Resolution Extended mode Select the resolution you want to be displayed on the device. Display Orientation Turn the connected display device. Mirror mode Primary mode * This function is not available on MAC...
- Page 10 Display Setting on Windows 7 Display Setting on Windows Vista/XP Right click on the desktop and go to “Screen Resolution” Right click on the ( ) icon in the lower right-hand side of the toolbar.
- Page 11 Display Setting on MAC (Snow Leopard). For a complete list of instructions for each function, Go to ( ) and then “System Preferences”. please refer to the User Manual Choose the “Display” or “Arrangement” tab to adjust.
- Page 12 Required Environment • Microsoft Windows 7, Vista, XP (32-bit or 64-bit) • Mac OS X v10.6 (Snow Leopard) / v10.7 (Snow Lion) • Available USB 2.0 port • Minimum System Requirements • CPU: Intel / AMD single core1.5 GHz or above • RAM: 1 GB or Higher Package Contents • Newport Station • USB 2.0 cable (Type-A to Mini-B) 1 Meter • Power Adapter (5V/3A) • Driver CD with E- Manual • Quick Installation Guide Regulatory Compliance...
- Page 13 Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any commercial damage, including but not limited to special, incidental, consequential, or other damage.
-
Page 14: Technical Support
2. Online Support Please visit the j5 create website (www.j5create.com) to find the latest software for your device. If you still experience issues, you can submit a trouble ticket through j5 web support. Your ticket will be handled within 24 hours. We stand behind our products and it is our goal to provide you world class support.
