Keston Heat 45 Installation And Servicing Instruction

Fan powered high efficiency modulating condensing gas boiler
Hide thumbs Also See for Heat 45:
Table of Contents

Advertisement

Quick Links

Download this manual
Heat 45 & 55
Heat 45P & 55P
Installation and Servicing Instructions
FAN POWERED HIGH EFFICIENCY
MODULATING CONDENSING
GAS BOILER
When replacing any part on this appliance, use only spare parts that you can be
assured conform to the safety and performance specification that we require.
Do not use reconditioned or copy parts that have not been clearly authorised by Keston.
For the very latest copy of literature for specification and maintenance practices visit our website www.kes-
ton.co.uk where you can download the relevant information in PDF format.
April 2018
UIN 208964 A08
