Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Operation..............................10 Technical specifications........................15 Protecting the environment......................17 LST-310 Lighting Stand...
Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. LST-310 Lighting Stand...
Page 6
NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – danger zone. LST-310 Lighting Stand...
Risk of injury due to tipping of the stand during loaded transport! If the stand is moved without having removed the installed devices, the stand may tip over and cause injuries and property damage. Remove the installed devices before transporting the stand. LST-310 Lighting Stand...
Page 8
The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. LST-310 Lighting Stand...
Extension tubes secured by safety bolt and cotter pin Mounting for crossbar with TV spigot Crossbar: 1.20 m Maximum weight-bearing capacity: 18 kg Minimum height: 1.77 m Maximum height: 3.10 m Maximum vertical lift: 1.33 m Weight: 11 kg LST-310 Lighting Stand...
Risk of injury due to tipping of stand on an unsuitable ground! When the stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage. Install the stand only on even and solid ground. LST-310 Lighting Stand...
Page 11
The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. LST-310 Lighting Stand...
Page 12
Operation Comply with regulations When installing and operating, make sure to follow the standards and regulations that apply in your country. LST-310 Lighting Stand...
Page 13
Tighten the Allen screws on the upper and lower tube clamps with the supplied Allen key. Attach up to four spotlights to the crossbar. Observe the instructions of the respective manufacturers. The maximum load capacity of 18 kg in total must not be exceeded. LST-310 Lighting Stand...
Page 14
Loosen the safety screw on the carriage to which the three feet are attached. Fold up the feet of the stand. Pack the individual parts of the system in their original packaging if possible, and store the package in a dry place protected against moisture. LST-310 Lighting Stand...
Mounting slots Holder type Flange, Æ 28 mm, for TV spigot Load, max. (with centric load) 18 kg Transport dimensions (B × H × T) 150 mm × 1400 mm × 150 mm Weight 8 kg Colour black LST-310 Lighting Stand...
Page 16
Technical specifications Further information Stand type Lighting stand Incl. crossbar Crank LST-310 Lighting Stand...
Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. Please follow the instructions and markings on the packaging. Observe the disposal note regarding documentation in France. LST-310 Lighting Stand...
