- Page 1 ASUS VIVOBOOK M1503QA/M1503IA Repair Manual...
- Page 3 Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
- Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
- Page 5 ASUS VIVOBOOK M1503QA/M1503IA Overview Top View Bottom View ❶ Array microphones ❷ Webcam shield ❸ Camera ❹ Camera indicator ❶ Air vents ❺ Display panel ❷ Audio speakers ❻ Microphone Indicator ❼ Keyboard ❽ Capital lock Indicator ❾ Camera off indicator ❿...
- Page 6 Components Top View ♦ LCD COVER ♦ FP FFC ♦ LCD BEZEL ♦ TOUCHPAD ♦ FAN ♦ BATTERY ♦ SSD ♦ TP FFC ♦ ANTENNA ♦ IO BOARD ♦ MEMORY ♦ LCD PANEL ♦ BOTTOM CASE ♦ PMIC BD ♦ THERMAL DUCT ♦...
- Page 7 Components Bottom View ♦ KEYBOARD MODULE ♦ IO BOARD ♦ LCD COVER ♦ PMIC BD ♦ LCD PANNEL ♦ TOUCHPAD MODULE ♦ BOTTOM CASE TP CONDUCTIVE ♦ MAIN BOARD ♦ CAMERA ♦ THERMAL Back...
- Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. ♦ Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
- Page 9 Appropriate Tools Tweezers material : Metal and Plastic. Please prepare and select the appropriate tools to disassemble/assemble for the VIVOBOOK X1503ZA notebook. ♦ Screwdriver ♦ Alcohol 95% ♦ Glove ♦ Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. ♦...
-
Page 10: Bottom Case
BOTTOM CASE Disassembly Notice Step 1 : Remove screw *10pcs. Torque(kgf-cm) Screws Spec Step 2 : Use plastic blade to pry the bottom case. SCREW M2*6.5L (4.6,0.8) (K) W-NI #1 2.2±0.2 SCREW M2*4L (4.6,0.8) (K) W-NI #1 2.0±0.2 Start Please follow above arrow direction with using plastic blade to pry bottom To avoid the bottom case hook, case in each blue circle location. - Page 11 DISCONNECT BATTERY CONNECTOR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet.
- Page 12 MEMORY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the MEMORY *1pc (red mark). Step 2 : Tear off the ABSORBER from MEMORY. Tear off (Front) (Rear) Assembly Notice Step 1 : Paste ABSORBER*1pc on the new RAM. Step 2 : Align and insert the new RAM module at 30°...
- Page 13 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *1pc and then remove SSD *1pc(red mark). Torque(kgf-cm) Screws Spec Step 2 : Tear off the ABSORBER from SSD. SCREW M2*2L (5.0,0.8) (K) W-NI #1 2.0±0.2 Unscrew Assembly Notice...
- Page 14 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Remove screw(red mark) *5pcs. Step 2 : Remove the BATTERY and BATTERY Cable.
- Page 15 WIFI CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the RF CABLE connector *2pcs. Torque(kgf-cm) Screws Spec Step 2 : Remove the screw *1pc. Step 3 : Remove the WIFI CARD. SCREW M2*2L (5.0,0.8) (K) W-NI #1 2.0±0.2 Unscrew...
- Page 16 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the speaker connector(red mark). Step 2 : Tear off the part of SPONGE and then tear off the part of FOIL(yellow mark). Step 3 : Tear off the part of FOIL (green mark) and then remove the SPEAKER.
- Page 17 MAIN BOARD(with Thermal module) and FAN Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the connector *6pcs (yellow mark). Torque(kgf-cm) Screws Spec Step 2 : Remove screw(red, green, blue and yellow mark) *17pc. Step 3 : Open and remove KB(with Thermal, MB, Touchpad and FAN).
- Page 18 MAIN BOARD(with Thermal module) and FAN Please be sure to pull out adapter and disconnect the battery. Assembly Notice If FFC is damage during disassembly, please replace For EDP CABLE assembly, please follow the pic below to paste sponge *1pc. new one.
-
Page 19: Thermal Module
THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Torque(kgf-cm) Screws Spec Step 1 : Remove the screw *4pcs. Step 2 : Remove the THERMAL MODULE. SCREW M2*2L (5.0,0.8) (K) W-NI #1 2.0±0.2 Recommend that the force point is at green block, pull up thermal module to take it out. Do not pull up at red block and note the thermal pipe should not have deformation. -
Page 20: Main Board
MAIN BOARD Mainboard connector placement EDP CABLE IO FFC SPEAKER TP FFC BATTERY FP FPC BL FFC KB FPC Back... - Page 21 MAIN BOARD M1503QA Materials on mainboard M3500QC AMD CPU MYLAR Z550MA SMD GASKET X1502ZA MB MYLAR M1502IA MB ABSORB X1502ZA GASKET 30X4X2T EMI GASKE_3*2*3 X542UQ SMT GASKET 5*6.5*3 Back...
- Page 22 MAIN BOARD M1503IA Materials on mainboard M1502IA CPU MYLAR Z550MA SMD GASKET M1502IA MB ABSORB X1502ZA MB MYLAR X1502ZA GASKET 30X4X2T EMI GASKE_3*2*3 X542UQ SMT GASKET 5*6.5*3 Back...
- Page 23 IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect IO connector(yellow mark). Step 2 : Remove the IO BD. Step 3 : Tear the tape (red mark) and then remove IO FFC. Disconnect Assembly Notice Please make sure to paste materials before...
-
Page 24: Touchpad Module
TOUCHPAD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect connector (red mark) *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Tear off TP rubber, tape and sponge (red mark) and then remove the FP FFC and TP FFC. Step 3 : Tear off the TP CONDUCTIVE*1pc. - Page 25 ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the sponge(yellow mark) *2pcs. Step 2 : Tear off the FOIL and then remove the ANTENNA_MAIN. Step 3 : Tear off the FOIL and then remove the ANTENNA_AUX. Tear and then Remove MAIN Tear off and then Remove...
-
Page 26: Keyboard Module
KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the KEYBOARD MODULE. Remove Back... -
Page 27: Lcd Bezel
LCD BEZEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the hinge cap. Torque(kgf-cm) Screws Spec Step 2 : Remove screw mylar *2pcs and then remove screw *2pcs(red mark). SCREW M2.5*3.5L (4.5,0.4) (K) B-ZN #1 2.0±0.2 Step 3 : Remove LCD BEZEL. - Page 28 LCD BEZEL Please be sure to pull out adapter and disconnect the battery. Assembly Notice For LCD BEZEL assembly, please follow the steps below paste For LCD BEZEL assembly, Please follow the steps below to BEZEL ADH MYLAR *2pcs before assembling. paste sponge *2pcs before assembling BEZEL.
-
Page 29: Lcd Panel
LCD PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws *6pcs and then remove the hinges *2pcs. Torque(kgf-cm) Screws Spec Step 2 : Pull out LCD adhesive *2pcs. SCREW M2.5*3L (4.5,0.4) (K) W-NI #1 2.0±0.2 Step 3 : Remove LCD PANEL ASSY. - Page 30 OLED LCD BKT + LCD PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Pull out LCD adhesive *2pcs. Step 2 : Remove LCD PANEL. Please pull the adhesive up about 30 degree slowly, and don't pull out the tape in Remove the panel vertical direction! 。...
- Page 31 CAMERA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the connector *1pc(red mark) from the PMIC BD. Step 2 : Remove the CAMERA and EDP CABLE. Disconnect Assembly Notice For CAMERA assembly, please follow the below steps. 1.
- Page 32 PMIC BOARD (FOR BENT OLED SKU) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the PMIC BD. Remove Back...
- Page 33 LCD COVER Assembly Notice Please be sure to pull out adapter and disconnect the battery. When reuse the OLED PNL BKT and assembly the OLED PNL: When reuse the LCD PANEL: Step 1 : Please paste new BKT ADHESIVE *2pcs, then release paper of BKT ADHESIVE *2pcs. Step 2 : Align the up and left site.
- Page 34 LCD COVER Assembly Notice Please be sure to pull out adapter and disconnect the battery. For new LCD COVER & BKT ,please use below SPONGE NEW BKT NEW LCD COVER Back...
