  • Page 1 ASUS VIVOBOOK M1405Y & I1405Y Series Repair Manual...
  • Page 3 Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
  • Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
  • Page 5 ASUS VIVOBOOK M1405Y & I1405Y Series Overview Bottom View Top View ❶ Array microphones ❷ Webcam shield ❸ Camera ❹ Camera indicator ❺ Display panel ❶ Air vents ❻ Microphone off indicator ❷ Audio speakers ❼ Keyboard ❽ Capital lock indicator ❾...
  • Page 6 Components Top View LCD COVER BOTTOM CASE TOUCHPAD MODULE CAMERA POWER EXTEND BOARD IO BOARD DMIC RUBBER LCD BEZEL IPS LCD PANEL SPEAKER OLED EDP CABLE FP FFC FP FFC (BY SKU) IO FFC MAIN OLED LCD PANEL THERMAL MODULE HINGE IPS EDP CABLE WIFI CARD...
  • Page 7 Components Bottom View OLED LCD COVER IPS LCD COVER KEYBOARD MODULE IO BOARD LCD COVER ADHESIVE OLED LCD BEZEL OLED LCD PANNEL IPS LCD PANNEL CAMERA BEZEL ADHESIVE H BEZEL AD SPONGE H PANEL BKT TOUCHPAD MODULE THERMAL MODULE PANEL BKT PULL AD SIDE BOTTOM CASE MAIN BOARD...
  • Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
  • Page 9 ASUS VIVOBOOK M1405Y & I1405Y Series Appropriate Tools Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad Substitute: GA500 Thermal Grease Thermal Pad GA500 Thermal Grease Tweezers (...
  • Page 10: Bottom Case

    BOTTOM CASE Disassembly Notice Step 1 : Remove screw *10pcs. Torque(kgf-cm) Screws Spec Step 2 : Use plastic blade to pry the bottom case. 2.8±0.2 SCREW M2*7L (4.6,0.8) (K) B-ZN SCREW M2*4L (4.6,0.8) (K) B-ZN 2.8±0.2 Start Please follow above arrow direction To avoid the bottom case hook, with using plastic blade to pry bottom don't insert plastic blade in each...
  • Page 11 DISCONNECT BATTERY CONNECTOR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet.
  • Page 12 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *1pc and then remove SSD *1pc (red mark). Torque(kgf-cm) Screws Spec SCREW M2*2L (5,0.8) (K) W-NI 2.0±0.2 Remove (Front) (Rear) Assembly Notice When installing the SSD, please keep the SSD less then 15 degrees with motherboard,...
  • Page 13 MEMORY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the MEMORY *1pc (red mark). Step 2 : Tear off the ABSORBER from MEMORY. Tear off Please check and remove the spec label from the ABSORBER, and paste it back to the old RAM.
  • Page 14 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Remove screw (red mark) *4pcs. Step 2 : Remove the BATTERY.
  • Page 15 WIFI CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the RF CABLE connector *2pcs. Torque(kgf-cm) Screws Spec Step 2 : Remove the screw *1pc. Step 3 : Remove the WIFI CARD. SCREW M2*2L (5.,0.8) (K) W-NI 2.0±0.2 Unscrew...
  • Page 16 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the speaker connector. Step 2 : Tear off the tape (red mark) *3pcs and then remove the SPEAKER. Tear and Remove Assembly Notice For Speaker assembly, please follow the below steps.
  • Page 17 MAIN BOARD(with Thermal module) and FAN Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the connector *7pcs (yellow mark). Torque(kgf-cm) Screws Spec Step 2 : Remove screw (red, green, blue and yellow mark) *13pc. Step 3 : Open and remove KB (with Thermal, MB, Touchpad and FAN).
  • Page 18: Thermal Module

    THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Torque(kgf-cm) Screws Spec Step 1 : Please follow the screws numbers to remove screw (red mark) *4pcs. Step 2 : Remove the THERMAL MODULE from MB. SCREW M2*2L (5,0.8) (K) W-NI 2.0±0.2 Recommend that the force point is at green block, and pull up thermal module to take...
  • Page 19: Main Board

    MAIN BOARD Mainboard connector placement EDP CABLE IO FFC SPEAKER FP FPC BL FFC KB FPC TP FFC BATTERY Back...
  • Page 20 MAIN BOARD Materials on mainboard M1502YA CPU MYLAR AUTO X1502ZA MB MYLAR X1502ZA GASKET 30X4X2T Back...
  • Page 21 IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the tape (red mark) *1pc and then remove the IO BOARD (with IO FFC). Step 2 : Disconnect IO FFC from the IO BOARD. Disconnect Assembly Notice Please make sure to paste materials before assembling on the IO BD.
  • Page 22 TOUCHPAD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the tape (red mark) and TP CONDUCTIVE TAPE (yellow mark) . Screws Spec Torque(kgf-cm) Step 2 : Disconnect & remove the FP FFC and TP FFC. SCREW M2*1.5L (7,0.4) (K) B-ZN 2.0±0.2 Step 3 : Tear off the TP CONDUCTIVE TAPE *1pc and Remove the screw (red mark) *3pcs .
  • Page 23 ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the FOIL and then remove the ANTENNA_AUX. Step 2 : Tear off the FOIL and then remove the ANTENNA_MAIN. Tear off and then Remove Tear off and then Remove MAIN Assembly Notice...
  • Page 24: Lcd Bezel

    LCD BEZEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove BEZEL SCREW MYLAR *2pcs. Torque(kgf-cm) Screws Spec Step 2 : Remove screw *2pcs. Remove Step 3 : Remove the hinge cap *1pc. 2.0±0.2 SCREW M2.5*3.5L (4.5,0.4) (K) B-ZN Step 4 : Remove LCD BEZEL.
  • Page 25 LCD PANEL (FOR OLED) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws *6pcs and then remove the hinges *2pcs. Torque(kgf-cm) Screws Spec Step 2 : Pull out LCD adhesive *2pcs. 2.0±0.2 Step 3 : Remove LCD PANEL ASSY.
  • Page 26 OLED BKT + LCD PANEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Pull out LCD adhesive *2pcs. Step 2 : Tear off the CONDUCTIVE TAPE (red mark) *3pcs. Tear off Step 3 : Remove LCD PANEL. Please pull the adhesive up about 30 degree slowly, and don't pull out the tape in vertical direction! CONDUCTIVE TAPE *3PCS...
  • Page 27 LCD PANEL ASSEMBLY NOTICE (FOR OLED) Assembly Notice Please be sure to pull out adapter and disconnect the battery. When reuse the OLED PNL BKT and assembly the OLED PNL: When reuse the LCD PANEL: Step 1 : Please paste new BKT ADHESIVE *2pcs, then release paper of BKT ADHESIVE *2pcs. Please use the fingertip to clean the residual glue on PANEL or BEZEL.
  • Page 28 LCD PANEL (FOR IPS) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws (red and green mark) *6pcs, then remove hinges *2pcs. Torque(kgf-cm) Screws Spec Step 2 : Remove screw (blue mark) *1pc from panel bracket. Step 3 : Push the hooks (blue mark) of LCD cover to the left and right side, then flip up the panel module and 2.0±0.2 SCREW M2*4L (4.5,0.55) (K) B-ZN...
  • Page 29 ASSEMBLY NOTICE (FOR IPS PANEL) Assembly Notice Please be sure to pull out adapter and disconnect the battery. Assembly Notice Please follow the steps bellow to assemble the brackets and LCD Panel. For 144hz IPS panel assembly, please Step 1 : Place the new brackets *2pcs on LCD COVER. follow the picture below to paste the Step 2 : Lock screw *1pc (red mark), then remove the release paper *2pcs new GASKET to tidy cable.
  • Page 30 CAMERA and PMIC BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the connector *2pcs (red mark) and then remove the CAMERA and PMIC BOARD. Step 2 : Tear off the Mylar (yellow mark) and then remove the EDP CABLE. Disconnect PMIC BD (BY SKU) Assembly Notice...
  • Page 31 ASSEMBLY NOTICE Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please follow the bellow picture to tidy the EDP Cable. The cables need to be snapped into the back cover hook and limit Back...
