Asus M6000 Series Disassembly Procedure

Chapter 3
Hide thumbs Also See for M6000 Series:
Table of Contents

Advertisement

Quick Links

See also: User Manual
D I S A S S E M B L Y
P R O C E D U R E

Disassembly Procedure

Please follow the information provided in this section to perform the complete
disassembly procedure of the notebook. Be sure to use proper tools
described before.
A
SUS M6000 Series Notebook consists of various modules. This chapter describes the
procedures for the complete notebook disassembly. In addition, in between procedures,
the detailed disassembly procedure of individual modules will be provided for your
service needs.
The disassembly procedure consists of the following steps:
• Battery Module
• Optical Drive Module
• HDD Module
• Second Memory Module
• CPU Module
• Keyboard Module
• First Memory Module
• Mini PCI Module
• LCD Module
• Top Case Module
• Motherboard Module
• Bottom Case Module
3 - 1
3
Chapter

Advertisement

Table of Contents
loading

Related Manuals for Asus M6000 Series

Summary of Contents for Asus M6000 Series

  • Page 1: Disassembly Procedure

    Be sure to use proper tools described before. SUS M6000 Series Notebook consists of various modules. This chapter describes the procedures for the complete notebook disassembly. In addition, in between procedures, the detailed disassembly procedure of individual modules will be provided for your service needs.

  • Page 2: Battery Module

    Second Memory Module S E C O N D The M6000 Series Notebook do not have onboard RAM. There are two SO-DIMM M E M O R Y sockets for installing SO-DIMM RAM. It can upgrade the total memory size up to 2GB M O D U L E with a 1GB module on each socket.

  • Page 3: Optical Drive Module

    D I S A S S E M B L Y P R O C E D U R E M2*3L Optical Drive Module O P T I C A L Press latch here then pull it out. D R I V E R E M O V A L Keyboard Module K E Y B O A R D...
  • Page 4 D I S A S S E M B L Y P R O C E D U R E 2. Unlock 3 keyboard latches then pull out the keyboard forward and lay the keyboard on the front side . 3.

  • Page 5: Cpu Module

    D I S A S S E M B L Y P R O C E D U R E M2*3L CPU Module C P U M O D U L E The illustrations below show how to remove the CPU module from the notebook. R E M O V A L Removing CPU C P U...

  • Page 6: Mini Pci Module

    D I S A S S E M B L Y P R O C E D U R E First Memory Module F I R S T The first memory module is under keyboard. Open the two latches to pop up memory module at M E M O R Y 45 degrees angle then pull it out .

  • Page 7: Lcd Module

    D I S A S S E M B L Y P R O C E D U R E LCD Module L C D The illustrations below show how to remove and disassemble the LCD module. The M O D U L E module contains LCD panel, Inverter board, LCD Hinge bracket, Hinge cover, LCD front cover, LCD back cover Removing LCD Module...
  • Page 8 D I S A S S E M B L Y P R O C E D U R E 4. Remove 2 screws(M2.5*6L(K)) at top side, then lift the LCD module away from the system. M2.5*6L Disassembling LCD Module L C D 1.
  • Page 9 D I S A S S E M B L Y P R O C E D U R E 4. Disconnect the speaker cable and LCD cable then take Inverter board off. Remove 8 screws (M2*3L(K) x 4 ,(M2*6L(K) x2 ,(M2.5*4L(K) x 2) and 2 fixed slices off , then take the LCD Bracket away.
  • Page 10 D I S A S S E M B L Y P R O C E D U R E M2*3L 7. Detach the right & left antenna and its cable. Reomve the speaker cable, then remove 1screw(M2*3L(K)) and 1 screw on the other T O P C A S E side.Then take two speaker s away...
  • Page 11 D I S A S S E M B L Y P R O C E D U R E 10. Remove 1 screw (M2.5*4L(K)) and 1 screw on the other side, then take right and lift hinge off. M2.5*4L M2.5*4L 11.
  • Page 12 D I S A S S E M B L Y P R O C E D U R E M2*3L M2*3L Top Case Module The illustrations below show how to disassemble and remove the top case module of the notebook. Removing Top Case Module T O P C A S E...
  • Page 13 D I S A S S E M B L Y P R O C E D U R E M2*6L M2*3L M2*6L Removing touch pad 3. Loosen the touch pad FPC cable then separate the top case module from the bottom case module.
  • Page 14 D I S A S S E M B L Y P R O C E D U R E M2*6L 2. Take the VGA heat sink module away and remove 2 tapes then disconnect modem cable. M O T H E R B O A R D R E M O V A L 3.
  • Page 15 D I S A S S E M B L Y P R O C E D U R E M2*6L Take the optical drive FPC away and remove 6 screws(M2*6L(K)). M2*6L Remove the audio FPC and pull out the card reader dummy & PCMCIA dummy. Finally, pull out the motherboard from the bottom case carefully.
  • Page 16 D I S A S S E M B L Y P R O C E D U R E Bottom Case Module B O T T O M The illustrations below show how to disassemble and remove the bottom case C A S E module of the notebook.
  • Page 17 D I S A S S E M B L Y P R O C E D U R E M2*3L 4. Remove 1 screw (M2*6L(K)) then remove the MIC out the hole and pull out the audio board upward then take it away. M2*6L 5.
  • Page 18 D I S A S S E M B L Y P R O C E D U R E 7. Remove 1 screw (M2*6L(K)) and 1 screw on the other side and then take 2 speakers away. M2*6L M2*6L 8.
