Product code: FS10082
Fontana Sensor Faucets
LIMA ELECTRONIC 2" RISING VESSEL SINK SOAP
DISPENSER CHROME FINISH INSTALLATION
INSTRUCTIONS
BEFORE YOU BEGIN
Before you begin, please read the installation instructions below. Observe
all local building and safety codes.
damages, do not install.
plumber otherwise warranty might be voided.
POSSIBLE TOOLS REQUIRED*
Level
Plumbers Tape
Tape Measure
Adjustable Wrench
Hex Wrench
Thread Sealant
Pencil or Marker
Screwdriver
Drill
*not included
fontanasensorfaucets.com
Fontana Sensor Faucet
1
Customer Service: 800-684-4489
Advertisement
Related Manuals for FONTANA SENSOR FAUCETS LIMA FS10082
Summary of Contents for FONTANA SENSOR FAUCETS LIMA FS10082
- Page 1 © Product code: FS10082 Fontana Sensor Faucets LIMA ELECTRONIC 2" RISING VESSEL SINK SOAP DISPENSER CHROME FINISH INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN Before you begin, please read the installation instructions below. Observe all local building and safety codes. damages, do not install.
- Page 2 © Fontana Sensor Faucets Size Product Type: Product Type: Commercial Commercial Main Construction Material: Main Construction Material: Brass Brass Mount Type: Mount Type: Deck Deck Handle Type: Soap Pump: Infra-Red 6 Volt Noise-Free Power Rating: Power: 3 Amp Fuse, AC: 230V DC: 1.5V 4 (D) Batteries / AC Adapter Optional 8”...
- Page 3 © Fontana Sensor Faucets Installation Method Install the bracket Insert the pump Insert the locking on the wall onto the bracket plate into bracket Unscrew the Add soap into full soap onto the pump, empty bottle. the empty bottle. and do not over tighten.
- Page 4 © Fontana Sensor Faucets Battery case Battery case cover － ＋ Screws ＋ － Batteries fontanasensorfaucets.com Fontana Sensor Faucet Customer Service: 800-684-4489...
- Page 5 © Fontana Sensor Faucets 1. Remove cover of battery case. 2. Install four (4) D size alkaline batteries. Anode Cathode Note: Make sure the batteries are installed in correct orientation (polarity). 3. Replace battery case cover. 4. Tighten screws. The standard life cycle time is 2 years, based on average use 2000 times/month.
- Page 6 © Fontana Sensor Faucets Commissioning Sequence Care & Cleaning Before using the soap dispenser for the first time the • Wipe away any debris adhering to the spout or following sequence must be carried out. sensor. Fill the bottle full of soap.
