DIJON HAND FREE DECK MOUNT SOAP DISPENSER
IN SATIN BRASS FINISH INSTALLATION INSTRUCTION
BEFORE YOU BEGIN
Before you begin, please read the installation instructions below. Observe
all local building and safety codes.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
Please note all products must be installed by a professional and certified
plumber otherwise warranty might be voided.
POSSIBLE TOOLS REQUIRED*
Plumbers Tape
Thread Sealant
Fontana Sensor Faucet
Fontana Sensor Faucets
Tape Measure
Drill
Level
Adjustable Wrench
Pencil or Marker
1
©
Product code: FS10055
Hex Wrench
Screwdriver
fontanasensorfaucets.com
Customer Service: 800-684-4489
*not included
Advertisement
Related Manuals for FONTANA SENSOR FAUCETS DIJON FS10055
Summary of Contents for FONTANA SENSOR FAUCETS DIJON FS10055
- Page 1 © Product code: FS10055 Fontana Sensor Faucets DIJON HAND FREE DECK MOUNT SOAP DISPENSER IN SATIN BRASS FINISH INSTALLATION INSTRUCTION BEFORE YOU BEGIN Before you begin, please read the installation instructions below. Observe all local building and safety codes. Unpack and inspect the items for any shipping damages. If you find damages, do not install.
- Page 2 © Fontana Sensor Faucets Size Product Type: Commercial Main Construction Material: Brass Mount Type: Deck Handle Type: Infra-Red Power Rating: 3 Amp Fuse, AC: 230V DC: 1.5V Batteries Required: 4 AA Batteries (not supplied) 6.6” 5” Number of Tap Holes:...
- Page 3 © Fontana Sensor Faucets Installation Method Install the bracket Insert the pump Insert the locking on the wall onto the bracket plate into bracket Unscrew the Add soap into full soap onto the pump, empty bottle. the empty bottle. and do not over tighten.
- Page 4 © Fontana Sensor Faucets Battery case Battery case cover － ＋ Screws ＋ － Batteries fontanasensorfaucets.com Fontana Sensor Faucet Customer Service: 800-684-4489...
- Page 5 © Fontana Sensor Faucets 1. Remove cover of battery case. 2. Install four (4) D size alkaline batteries. Anode Cathode Note: Make sure the batteries are installed in correct orientation (polarity). 3. Replace battery case cover. 4. Tighten screws. The standard life cycle time is 2 years, based on average use 2000 times/month.
- Page 6 © Fontana Sensor Faucets Commissioning Sequence Care & Cleaning Before using the soap dispenser for the first time the • Wipe away any debris adhering to the spout or following sequence must be carried out. sensor. Fill the bottle full of soap.
