Summary of Contents for Fisher-Price POWER WHEELS MOTOR CYCLES HARLEY-DAVIDSON Rocker
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE T4869 Owner's Manual Shop genuine replacement parts for FISHER PRICE T4869 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
- Page 2 Please read this manual and Please read this manual and save it with your original save it with your original sales receipt. sales receipt. Tool needed for assembly: Tool needed for assembly: Phillips screwdriver Phillips screwdriver (not included). (not included). Use only with a Power Wheels Use only with a Power Wheels ®...
-
Page 3: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be non-warranty repairs for a minimal charge. To find the authorized damaged by riding this vehicle indoors. Fisher-Price ® will not... -
Page 4: Electrical Hazard
IMPORTANT INFORMATION ELECTRICAL HAZARD DANGER • To prevent electric shock, do not immerse in water; wipe clean with a damp cloth. WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. -
Page 5: Parts
PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. -
Page 6: Parts Picture
PARTS PICTURE Parts Not Shown Vehicle Frame Headlight 6 Volt Battery Charger Front Wheel Assembly Headlight Retainer – 2 Battery Retainer Label Sheet Handlebar Seat #8 x ¾" Screw – 10 Handlebar Bracket 6 Volt Battery P5065pr-0920... -
Page 7: Battery Charging
BATTERY CHARGING ELECTRICAL HAZARD CAUTION WARNING Use the charger in dry locations only. • Battery can fall out and injure a child if vehicle tips over. Always use About Thermal Fuses battery retainer. Your Power Wheels ® 6 Volt (4.0 Amp/Hr.) battery is equipped •... - Page 8 BATTERY CHARGING Seat Battery Connector Charger • Loosen the screws on each side of the seat. Set the Connector screws aside. • Pull the tabs on each side of the seat and lift to remove it. • Fit the charger connector and the battery connector together •...
-
Page 9: Assembly
ASSEMBLY WARNING Handlebar Children can be harmed by small parts, Top of Front sharp edges and sharp points in the Wheel Assembly vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. - Page 10 ASSEMBLY • Insert two screws into the outer holes in the handlebar bracket • Insert four screws into the headlight and tighten. and tighten. Hint: You may need to turn the handlebar to each side to insert and tighten the screws. Headlight •...
- Page 11 ASSEMBLY Headlight Retainer • Fit a headlight retainer to the back of the headlight, as shown. • Insert two screws into the headlight retainer and tighten. • Repeat this procedure to assemble the other headlight retainer. P5065pr-0920...
-
Page 12: Decoration
DECORATION Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... -
Page 13: Battery Installation
BATTERY INSTALLATION ® IMPORTANT! Use only a Power Wheels 6 volt lead-acid Battery Retainer rechargeable battery. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least ® 18 hours using the enclosed Power Wheels 6 volt charger before operating your vehicle for the first time. -
Page 14: Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care Disposal If a battery leak develops, avoid contact with the leaking acid • Your Power Wheels ® battery is a non-spillable, sealed lead-acid and place the damaged battery in a plastic bag. See information battery. It must be recycled or disposed of in an environmentally below for proper disposal. -
Page 15: Safe Driving Rules
SAFE DRIVING RULES Teach Safety Rules to Children RIDING HAZARD While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment WARNING skills are still very immature. Unsupervised driving by children can lead to serious injury. -
Page 16: Vehicle Operation
VEHICLE OPERATION IMPORTANT! Use this vehicle ONLY outdoors. Most interior Reverse flooring can be damaged by riding this vehicle indoors. Fisher-Price will not be responsible for damage to the floor ® if the vehicle is used indoors. Reverse Forward Drive IMPORTANT! To prevent damaging the motors and gears, teach your child to stop the vehicle before switching direction. -
Page 17: Vehicle Care
VEHICLE CARE BUMPER-TO-BUMPER* LIMITED WARRANTY • Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. *One year limited warranty from the date of •... -
Page 18: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 9 AM and 7 PM (EST) Monday through Friday and 11 AM-5 PM (EST) Saturday. - Page 19 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the motor harness suddenly stopped connector is plugged into the battery connector, and that there are no loose wires around the motors. ®...
- Page 20 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the fi rst time. After fi rst-time use, recharge the battery for at least 14 hours after each use.
- Page 21 Manufactured by Fisher-Price under license from Harley-Davidson Motor Company. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2009 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc., unless otherwise indicated.
