Denon AVR-X3600H Service Manual

Integrated network av receiver

Hide thumbs Also See for AVR-X3600H:

User manual (310 pages)

Quick start manual (14 pages)

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

page of 193

/ 193
Troubleshooting
Bookmarks

Quick Links

Download this manual

INTEGRATED NETWORK AV RECEIVER

AVR-X3600H

• For purposes of improvement, specifications and design are subject to change without notice.

• Please use this service manual when referring to the operating instructions without fail.

• Some illustrations used in this service manual are slightly different from the actual product.

Service Manual

Click here!

On-line service parts list

http://dmedia.soundunited.com/documents/details/25940

ONLINE PARTS LIST

(P5)

WEB owner's manual

NA:

http://manuals.denon.com/AVRX3600H/NA/EN/index.php

EU:

http://manuals.denon.com/AVRX3600H/EU/EN/index.php

AP:

http://manuals.denon.com/AVRX3600H/AP/ZH/index.php

Upload is planned for the time of a future press release.

BEFORE SERVICING THIS UNIT

ELECTRICAL

MECHANICAL

REPAIR INFORMATION

UPDATING

Confidential

Ver. 1

Table of Contents

Need help?

Do you have a question about the AVR-X3600H and is the answer not in the manual?

Questions and answers

Summary of Contents for Denon AVR-X3600H

Page 1 Service Manual Ver. 1 INTEGRATED NETWORK AV RECEIVER AVR-X3600H Click here! On-line service parts list http://dmedia.soundunited.com/documents/details/25940 ONLINE PARTS LIST (P5) WEB owner’s manual http://manuals.denon.com/AVRX3600H/NA/EN/index.php http://manuals.denon.com/AVRX3600H/EU/EN/index.php http://manuals.denon.com/AVRX3600H/AP/ZH/index.php Upload is planned for the time of a future press release. BEFORE SERVICING THIS UNIT...
Page 2 BEFORE SERVICING THIS UNIT SAFETY PRECAUTIONS NOTE FOR SCHEMATIC DIAGRAM HANDLING THE SEMICONDUCTOR AND OPTICS ONLINE PARTS LIST Accessing the Parts List Searching Part Numbers or Ref. Numbers NOTE FOR PARTS LIST SERIAL NUMBER Serial Number Organization SKU Code of this Unit POST-SERVICE PRECAUTIONS Initializing this Unit JIG FOR SERVICING...
Page 3: Safety Precautions
SAFETY PRECAUTIONS The following items should be checked for continued protection of the customer and the service technician. Leakage current check Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective.
Page 4: Note For Schematic Diagram
NOTE FOR SCHEMATIC DIAGRAM WARNING: Parts indicated by the z mark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer. CAUTION: Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check.
Page 5: Note For Parts List
Click here! On-line service parts list http://dmedia.dmglobal.com/Document/DocumentDetails/XXXXX ONLINE PARTS LIST (P5) WEB owner’s manual http://manuals.denon.com/AAAAAAA/NA/EN/index.php http://manuals.denon.com/AAAAAAA/EU/EN/index.php http://manuals.denon.com/AAAAAAA/AP/ZH/index.php http://manuals.denon.com/AAAAAAA/JP/JA/index.php Upload is planned for the time of a future press release. BEFORE SERVICING THIS UNIT NOTE : If the web browser does not open automatically, copy the URL and paste it into the address bar (3) Next, click the "Sheet"...
Page 6 SERIAL NUMBER Serial Number Organization The 14-digit serial number that contains the code of the manufacturing plant and the manufacturing date. 14 digits Factory Manufactured Cumulative Year, month code code serial number The last Month 2digit of year (01 ～ 12) SKU Code of this Unit Product SKU SKU Code...
Page 7: Initializing This Unit
POST-SERVICE PRECAUTIONS Initializing this Unit Make sure to initialize this unit after replacing the microcomputer or any peripheral equipment, or the digital PCB. 1. Press the power button to turn off the power. 2. While holding down buttons "ZONE2 SOURCE" and "DIMMER" simultaneously, press the power button to turn on the power.
Page 8: Schematic Diagrams
ELECTRICAL SCHEMATIC DIAGRAMS PRINTED CIRCUIT BOARDS SCH01 HDMI SW1 DIGITAL, F HDMI SCH02 HDMI SW2 INPUT, FRONT CNT SCH03 HDMI TX 4CH AMP, 5CH AMP SCH04 CPU SPK, H2L, TUNER, GUIDE R, FFC GUIDE SCH05 CPU LEVEL CHG FRONT, CNT, FUNCTION, USB SCH06 DIGITAL CNT VIDEO, GUIDE L, SIDE CNT, SMPS SCH07 DSP...
Page 9 SCHEMATIC DIAGRAMS SCH01 HDMI SW1 HDMI SW1 FROM CEC5V_1 D.SUPPLY CEC3.3V L1007 CB05YTYH221 CEC1.1V1 L1019 P1_C- DGND TO 1A OPEN-2012 P1_C+ P1_D0- P1_D0+ P1_D1- FROM P1_D1+ HDMI SW2 P1_D2- P1_D2+ L1008 MI1206K260R-10 R1162 TO 0A 0-2012 L1009 CB05YTYH221 N1005 C1233 OPEN-2012 A111989-A-01-T AVDD11RX_1...
Page 10 SCH02 HDMI SW2 HDMI SW2 N1001 A111989-A-01-T R1017 RX1_5V HP_DET Q1000 HPD1 RT1N141C STBY5V DDC_SDA Q1001 FROM RT1N441C CEC5V DDC_SCK R1019 CEC3.3V D.SUPPLY RX1_DDCDA L1000 CB05YTYH221 CEC1.1V2 CE_REMOTE R1021 RX1_DDCCL L1016 DGND TXC- TO 6A RX1_C- OPEN-2012 TXC_SHLD TXC+ RX1_C+ TX0- RX1_0- TX0_SHLD...
Page 11 SCH03 HDMI TX HDMI TX GPIO VDD33IO CEC5V CEC3.3V U1034 CEC1.1V L1088 TLV75712PDBVR BD160 DGND PVDD33 D1102 L1115 L1087 L1086 LRB521S-30 OPEN-2012 BD160 CB05YTYH221 TO 9A L1083 AVDDH33 L1082 CB05YTYH221 CB05YTYH221 AVDD11 L1140 CB05YTYH221 C2245 2R2U-K-1005 VDD33 R2156 L1084 CB05YTYH221 VDD11 R2157 OPEN...
Page 12 SCH04 CPU TO 4B TO 5B TO 6B TO 7B TO 8B TO 9B TO CPU LEVEL CHG TO ADV8003 TO D.SUPPLY NET PHY ADV7180 C1356 OPEN-0603 DSP1CLK CEC_COM CEC_COM DSP1MISO H5VDET R1488 DSP1MOSI Q1043 HINSELC DSP1RST 2SD2114K HINSELB R1490 DSP1CS HINSELA 100K...
Page 13 SCH05 CPU LEVEL CHG CPU LEVEL CHG TO 4C TO DIGITAL CNT SWM3.3V FROM M3.3V D.SUPPLY DGND TO 5C SWM3.3V DGND TO CPU TO B7 GND LINE POWER+ LINE POWER- LINE ANALOG AUDIO DIGITAL AUDIO TMDS SIGNAL VIDEO SIGNAL COMPONENT(Y)
Page 14 SCH06 DIGITAL CNT TO 6C DIGITAL CNT TO D.SUPPLY DA+5V N1018 MUTE3.3V N1018 C125Z2-21C DA3.3V DA3.3V DACPCMS1 DACPCMS1 AP_CK N1044 AP_CK. AP_DA AP_DA. N1044 DAC_ZERO_MUTE_1. DAC_ZER0_MUTE1 C125Z2-15C DAC_ZERO_MUTE. DAC_ZER0_MUTE DAC_RST1. DAC_RST1 SEL_CLK SEL_CLK DGND DGND SEL_DATA SEL_DATA DACMCK.. DACMCLK VOL_CLK MVOL_CLK DACBCK..
Page 15 SCH07 DSP TO 9C TO C0 TO DIR/A.PLD TO CPU MP OPEN N1034 1.0-16-6PB-2 DSP1CS DSP1MISO DSP1MOSI DSP1CLK DGND DA3.3V L1129 CB05YTYH221 L1130 CB05YTYH221 DSP1MISO DSP1CLK DSP1MOSI DSP1CS R2181 10K*4(AR) R1649 OPEN R1653 R1654 R1655 OPEN R1837 C1429 OPEN-0603 U1023 C1430 OPEN-0603 W9812G6KH-5...
Page 16 SCH08 MAIN DAC TO 1D TO 2D TO C2 TO 3D TO 4D MAIN DAC FROM FROM FROM FROM FROM DIR/A.PLD DIR/A.PLD DIR/A.PLD DIR/A.PLD AD_VDCOM ADIN_LEGO_L DAGND ADIN_LEGO_R DAGND A/DIN_R DAGND A/DIN_L 100N-K-1608 C2188 100N-K-1608 C2187 DACRTNGND DA+5V A/DIN_L A/DIN_R DA+5V DA3.3V R2075...
Page 17 SCH09 DIR A.PLD TO A5 TO 5D TO 6D TO B3 TO B0 TO 7D TO C1 TO VIDEO PLD DIR/A.PLD FROM NET PHY FROM HDMI TX TO HDMI TX FROM HDMI SW1 TO CPU FROM NET PHY *FILTER COMPONENTS VALUE TYPE TOLERANCE...
Page 18 SCH10 ADV8003 ADV8003 DV5V FROM DV3.3V DV1.8V D.SUPPLY DGND DVDD_TX AVDD3_1_TX PVDD5_TX DVDDIO_TX AVDD3_1_TX AVDD3_1_TX TO 0E L1038 L1039 L1042 M21,N21 D20,D21 CB05YTYH101 CB05YTYH221 CB05YTYH221 A13,B13 PVDD5_TX AVDD2_TX PVDD3_TX PVDD_TX DDR_1.8V PVDDR_TX AVDD3_1_TX AVDD3_1_TX AVDD3_1_TX PVDD5_TX DVDDIO_TX L1044 L1049 A16,A21 V21,W21 D5,D12 CB05YTYH221...
Page 19 SCH11 ADV8003 DDR ADV8003 DDR TO E2 TO E3 TO E4 ADV8003 ADV8003 ADV8003 U1028 A3R12E40DBF-8E(512Mb) U1029 A3R12E40DBF-8E(512Mb) DDR2 DDR1 DDR_1.8V DDR_1.8V DGND DGND DR_TXDQSB1 DDR_1.8V DDR_1.8V DGND DGND DR_TXDQSB3 DDR_1.8V DR_TXDQ14 DGND DR_TXDM1 DR_TXDQS1 DGND DR_TXDQ15 DR_TXDQ30 DGND DR_TXDM3 DR_TXDQS3 DGND DR_TXDQ31...
Page 20 SCH12 D.SUPPLY L1054 CB05YTYH221 D.SUPPLY L1055 CB05YTYH221 OPEN L1056 CB05YTYH221 R1814 OPEN STBY5V N1033 R1813 OPEN 1.117V CEC5V OPEN TO A6 N1033 L1020 L1133 1.5A CEC3.3V TYS50402R2N-10 OPEN-2012 A2505-WV06_6P CEC1.1V2 CEC1.1V2 U2806 L1134 OPEN R1050 DGND RESETOUT CEC_POWER OPEN-2012 R1812 2R7-1608 D5.2V D5.2V...
Page 21 SCH13 NET PHY TO B9 NET PHY TO CPU NET_I2S2_DOUT NET_I2S2_BCKIN NET_I2S2_DIN NET_I2S2_LRCKIN R1322 NET_I2S0_DOUT. R1321 NET_I2S_BCLKOUT. NET_TDM_DOUT_1 R1320 NET_I2S_LRCKOUT. NET3.3V FROM LEGO5V D.SUPPLY DGND 19 18 17 TO E9 DIR/A.PLD TO D6 C2147 9 10 47/6.3 R1207 R1208 NET_I2S0_DOUT C1176 4R7U-M-1608 NET_I2S_LRCKOUT...
Page 22 SCH14 VIDEO PLD TO B2 TO/FROM HDMI TX VIDEO PLD DOPI_PCK DOPI_PCK DOPI_D0 DOPI_D0 DOPI_D1 DOPI_D1 DOPI_D2 DOPI_D2 U1011 DOPI_D3 DOPI_D3 EPM570F256C4N DOPI_D4 DOPI_D4 DOPI_D5 DOPI_D5 DOPI_D6 DOPI_D6 DOPI_D7 DOPI_D7 R2189 8KOPI_Y11/R7 8KOPI_Y11/R7. 47*4(AR) DGND 8KOPI_C2/B2 DV3.3V PO8KI_Y9/R5 PO8KI_Y5/R1_PLD PO8KI_Y4/R0 PO8KI_Y3/G7_PLD PO8KI_Y2/G6_PLD POHI_HSYNC.
Page 23 SCH15 ADV7180 ADV7180 L1034 CBC2518T220M L1033 CBC2518T220M L1032 CB05YTYH221 DV1.8V L1031 CB05YTYH221 DV3.3V DGND CEC3.3V TO E7 X1019 28.63636MHz(7P) C2218 10N-K-0603 C2217 R2263 82N-K-1005 1K69-F R2261 R2273 OPEN R2126 DOPI_PCK DECIN_V. R2264 C2211 10N-K-0603 C2210 100N-K-0603 C2421 C2387 OPEN-0603 U2022 DVDDIO 100N-K-0603 ADV7180...
Page 24 SCH16 INPUT1 CN4201 CN4204 CN4202 CN4208 CN4210 CN4211 TO CP4206 TO CP4205 TO CP4203 TO _CP4203 TO CP404 TO CP405 FRONT_CNT 2/2 _ L7 INPUT 1/1 _ E1 SIDE_CNT 1/1 _ J5 INPUT 1/1 _ G1 11CH_AMP MAIN JK4201 R4201 C4277 OPEN SAT_L...
Page 25 SCH17 INPUT2 AGND INPUT 2/3 A-7V A-7V AMP_FL AMP_FL AMP_FR AMP_FR JK4203_4 AMP_C AMP_C 4P JACK AMP_SL AMP_SL JK4203 C4301 R4374 R4375 C4302 R4376 22/50 22/50 AMP_FL AMP_SR AMP_SR Q4221 Q4222 A-7V 1NC2002AC1 INC2002AC1 R4389 R4381 470K R4387 R4388 100K MU_F C4308 10N-K...
Page 26 SCH18 F. HDMI INPUT 3/3 JK201 A111989-G-01-T_W/O_FLNG HP_DET F.HPD R2003 R2004 DDC_SDA JK202 L2001 LBC2012T4R7M DDC_SCK JK202 A111989-G-01-T_W/O_FLNG CE_REMOTE F.CEC TXC- TXC_SHLD TXC+ HP_DET F.HPD TX0- F..HDMI5V TX0_SHLD DGND FDGND TX0+ DDC_SDA F.DDC_SDA TX1- DDC_SCK F.DDC_SCL TX1_SHLD TX1+ F.CEC TX2- RXD_C- F..RX_C- TX2_SHLD...
Page 27 SCH19 SIDE CNT CP1018 CP1017 CP1023 CN4007 TO N1018 TO N1026 TO N1024 TO CN4200 HDMI _ DIGITAL CNT _ H3 HDMI _ DIGITAL CNT _ H5 MAIN 2/2 _ M9 HDMI _ DIGITAL CNT _ N5 SIDE_CNT 1/1 CP4700 VIDEO_M8 B/PIRIN_DE M3.3V...
Page 28 SCH20 VIDEO & RS232C VIDEO&RS232 PART VIDEO_F/CNT 1/2 CVBS INPUT SW NJM2595MTE1 INPUT AVR-X3600 OUT PUT SW4 SW5 MUTE MUTE GAME GAME VIN 3 CBL/SAT C5028 VIN 4 Blu-ray 10/50 VIN 5 GAME IC5001 NJM2595M R5012 CN5000 JACK5000 OPEN V+5V V+5V CBL/SAT CBL/SAT...
Page 29 SCH21 FRONT CNT VIDEO_F/CNT 2/2 CP1039 CP1040 TO N1043 TO N1044 FRONT_CNT PART HDMI _ DIGITAL CNT_D5 HDMI _ DIGITAL CNT_D3 FUSE F5006,F5007,F5008,F5009 F5005 AVR-X3600 T1.6AL/250V T1.25AL/250V CP5000 F5005A F5005B T1.25AL 250V F5005 TRG_15V_A C5046 MAIN TRANS TAP OPEN CP5003 F5006 TO CN5000 A2505-WR08...
Page 30 SCH22 AMP1-5CH PAGE 1 AVR-X3600 AMP SCH 5CH-AMP B'D 1/2 60.8V 59.4V 60.0V 60.3V R403 R405 R406 R401 R703 270(1) C401 270(1) CP501 DHPTF1608 471P 115T C402 100N-K A2001-WRB02-K 2P D401 OPEN C403 R407 1N4148 1.1V 10N-K Q401 0.6V Q403 R411 680K Q402...
Page 31 SCH23 AMP2-5CH TO F3 TO F4 PAGE 2 PAGE 2 PAGE 2 AMP B'D 1/3_M10 AMP B'D 1/3_A10 5CH-AMP B'D 2/2 R533 R535 R706 R537 R531 270(1) CP504 270(1) C449 DHPTF1608 471P 115T C450 D419 OPEN A2001-WRB02-K 2P 100N-K 1N4148 Q437 Q439 R541...
Page 32 SCH24 AMP3-4CH PAGE 3 4CH-AMP B'D 1/1 R579 R581 R708 270(1) R651 R648 270(1) CP506 C468 DHPTF1608 471P 115T C492 D431 A2001-WRB02-K 2P OPEN 100N-K 1N4148 Q464 R650 680K Q453 Q456 KTA1024Y KTA1024Y Q455 2N5401S C532 R594 R640 220P-100V 2SD2560 D432 R630 R637...
Page 33 SCH25 SPK MAIN 1/2 SPK PART CN4215 R4000 470(2) CN4215 H/PR 4P/200MM R4016 +HIGHB L4000 TO CP408 SP-2507 RLY4000 D4000 LBAS16HT1G C4000 HFD27/012-S HIGHGND 47N-50V(PEF) -HIGHB R4002 R4003 R4001 470(2) C4003 10(2) H/PL OPEN CN4216 CN4216 JACK4006 FR_GND 5P/270MM C4001 C4002 JXZ-201B(RD,BK) CHASSISGND...
Page 34 SCH26 TUNER & REG SPK PART A8 TO F5 MAIN 2/2 REG PART D4021 A_-8V OPEN CP4009 A_+8V VIDEO_F/CNT_J8 U4007 D4010 D4009 KIA7812API CP4009 1N4007 1N4007 C125Z1-17 TRG_15V TRG_12V H/PL H/P_L H/P_GND H/P_GND CP4003 H/PR H/P_R VIDEO_F/CNT_F9 VGND VAGND VAGND V_-5V V-5V U4000...
Page 35 SCH27 FRONT FRONT 1/2 AVR_S950_X2600_X3600 FRONT MODEL AVRS950 AVRX2600 AVRX3600 AREA E3/E2 E2/E1C/K E2/E1C OPTION A R4440 OPEN OPEN FL4400 R4441 OPEN OPEN OPEN CIG25-1801N R4462 1.2K 1.2K R4463 1.2K 1.2K TUNED STEREO SLEEP AUTO HDMI DIGITAL ANALOG S.BACK CN4402 MUTE USB B'D CP4406...
Page 36 SCH28 SMPS AVR-X3600 SMPS OPTION BK901 AC100-120V:T2AL 250V M3_BURRING AC220-240V:T1.6AL 250V D9002 1N4007 LF901 J9008 OPTION OPTION F9001B F9001A LIVE SQ2424 29mH D9001 1N4007 JUMPER F9001 C9002 0.01UF/250V Neutral R9008 ¡Ü JK901 ZD911 C9012 D9003 1N4007 ZD908 YW396-03AV ¡Ü 2200PF/1KV-3225 P6KE150A D9012 P6KE120A...
Page 37 PRINTED CIRCUIT BOARDS DIGITAL, F HDMI Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu). DIGITAL (A SIDE) F HDMI (A SIDE) F HDMI (B SIDE) N1017 Q1023 C1293 Q1024 R1025 R1027 D1005 R1023 BKT1000 C1948 C1954 D1007 D1006 R1026 R1024 R2060 R2073 R1028...
Page 38 INPUT, FRONT CNT INPUT (A SIDE) INPUT (B SIDE) FRONT CNT (A SIDE) FRONT CNT (B SIDE) SEL_CLK SEL_DATA MVOL_CLK SEL_CLK MVOL_DATA MVOL_MUTE SEL_DATA ZVOL_CLK AEXP_DATA_2 ZVOL_DATA SEL_CLK AEXP_STB ZVOL_STB SEL_DATA AEXP_CLK AEXP_STB MVOL_CLK AEXP_OE AEXP_CLK MVOL_DATA AEXP_DATA1 MVOL_MUTE AEXP_OE ZVOL_STB ZVOL_CLK AEXP_DATA1...
Page 39 4CH AMP, 5CH AMP 4CH AMP (A SIDE) 4CH AMP (B SIDE) 5CH AMP (A SIDE) 5CH AMP (B SIDE) ASODET THERMALDET_A THERMALDET_B DCDET3 THERMALDET_E THERMALDET_F C421 C429 R471 HN4A06J Q441 C526 C519 C544 C477 C469 C524 A G N D A G N D A G N D C550...
Page 40 SPK, H2L, TUNER, GUIDE R, FFC GUIDE SPK (A SIDE) H2L (A SIDE) H2L (B SIDE) AVR-X3600 H2_L B'D JACK4010 JACK4009 JACK4007 JACK4008 JACK4000 JACK4001 JACK4002 JACK4003 JACK4004 JACK4005 JACK4006 7020-08461-000-0S C4116 C4019 C4015 C4013 STEP:MP 3.HEIGT_2L 2.NC C4118 C4017 C4009 C4002 RLY4008...
Page 41 FRONT, CNT, FUNCTION, USB FRONT (A SIDE) FRONT (B SIDE) CNT (A SIDE) CNT (B SIDE) CLAMP653 GASKET POSITION CNT B'D(MM) CP4402 CP4403 7020-08412-000-2S 7020-08412-000-2S CNT B'D(MM) M3.3V D/MGND SWM3.3V A+7V A-7V MICGND V.AUX/GND H/PGND H/PL H/PR FRONT_IRIN SWM5V POWERKEY REDLED FLCLK FLDATA...
Page 42 VIDEO, GUIDE L, SIDE CNT, SMPS VIDEO (A SIDE) VIDEO (B SIDE) SMPS (A SIDE) SMPS (B SIDE) RQ6C050BCTCR R1077 Q522 R1078 BK902 C5289 NEUTRAL(W) Sec. R1079 Sec. C835 Pri. Pri. JK901 CY901 470PF/400V Sec. ( 471 ) Pri. Sec. Sec.
Page 43: Level Diagram
LEVEL DIAGRAM FRONT ch AVR-X3600H LEVEL DIAGRAM FRONT ch NJU72750 NJU72343 ANALOG H/POUT SPEAKER LINE IN ＋ GAIN ADJ. AK4458VN AK5358B ＋＋ PREOUT －－ to ZONE2 +30dB NJU72343 MAX. OUTPUT 4.2Vrms SP OUT Differential Out 4.48Vrms/8Ω AK4458 MAX SIGNAL LEVEL...
Page 44 CENTER, SURROUND ch AVR-X3600H LEVEL DIAGRAM CENTER ch SURROUND ch NJU72343 SPEAKER ＋ GAIN ADJ. AK4458VN ＋＋ PREOUT －－ +30dB NJU72343 MAX. OUTPUT 4.2Vrms SP OUT Differential Out 4.23Vrms/8Ω AK4458 MAX SIGNAL LEVEL 0dBFS +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) 0dBFS = +/-2.8Vpp=1.98Vrms...
Page 45 SUBWOOFER ch AVR-X3600H LEVEL DIAGRAM SUBWOOFER ch NJU72343 PREOUT GAIN AK4458VN ＋＋－－ NJU72343 MAX. OUTPUT 4.2Vrms +30dB MAX SIGNAL LEVEL Differential Out DOLBY LIMIT LEVEL (ALLch-3dBFS) AK4458 0dBFS +20dB 0dBFS = +/-2.8Vpp=1.98Vrms -10dBFS +10dB PREOUT 300mVrms -20dBFS...
Page 46 ASSIGN1_2 ch AVR-X3600H LEVEL DIAGRAM ASSIGN1/2 (SURROUND BACK/HEIGHT1/HEIGHT2) ch NJU72343 NJU72750 ＋ SPEAKER GAIN AK4458VN ＋＋ PREOUT －－ +30dB NJU72343 MAX. OUTPUT 4.2Vrms SP OUT Differential Out 4.23Vrms/8Ω AK4458 MAX SIGNAL LEVEL 0dBFS +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) 0dBFS = +/-2.8Vpp=1.98Vrms...
Page 47 ZONE2 (w/ Source) ch AVR-X3600H LEVEL DIAGRAM Distribution ZONE2(w/ Source) NJU72750 NJU72750 NJU72750 SPEAKER LINE IN ＋ BT_TX PCM5100 AK5358B NJW1194 Digital in TONE ZONE2 PCM5100 MONO GAIN MONO PCM9211 To LEGO +30dB SP OUT 4.70Vrms/8Ω Differential Out PCM5100 0dBFS = 2.1Vrms...
Page 48 ZONE2 (w/o Source) ch AVR-X3600H LEVEL DIAGRAM Distribution ZONE2(w/o Source) NJU72750 NJU72750 NJU72750 SPEAKER LINE IN ＋ BT_TX PCM5100 AK5358B NJW1194 Digital in TONE ZONE2 PCM5100 MONO GAIN MONO +30dB SP OUT 4.70Vrms/8Ω PCM5100 0dBFS = 2.0Vrms 0dBFS +20dB +20dB...
Page 49 BLOCK DIAGRAM ANALOG AUDIO DIAGRAM AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 7-INPUT/3-OUT MAIN_L InA1 OutA LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT NJU72750 MAIN_R InB1 OutB InA1 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C...
Page 50 DIGITAL AUDIO DIAGRAM AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA TMDS TMDS FRONT IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 51: Component Out
VIDEO DIAGRAM AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA FRONT TMDS TMDS HDMI OUT1 IN_3 TMDS OUT_1 HDMI 27MHz HDMI OUT2 TMDS OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS IN_3 OUT_0 IN_1 HDMI1 MN864788 (1080p ->...
Page 52: Power Diagram
POWER DIAGRAM AVR-X3600 VCC DIAGRAM MAIN +B S1(AMP +B) MAIN -B 36mA +3.3V ( PCM5100A*2 ) AP7361-ADJ 148mA 112mA KIA7805API DA+5.0V ( AK4458VN*2 / AK5358BET / PCM9211 ) 699.9mA 386mA 238mA A+7.0V ( NJU72750*3 , NJU72343*2 , NJW1194 , NJM2068 , NJM2115 , NJM4580 , NJM8080*13 ) KIA7808API 313.9mA 12V ( RELAY )
Page 53: Wiring Diagram
WIRING DIAGRAM AVR_X3600 WIRE DIAGRAM SPK JACK SPK PCB DIGITAL PCB LEGO V4.0 MODULE FRONT CNT PCB VIDEO PCB INPUT PCB 5CH AMP PCB FAN 2 FAN 1 4CH AMP PCB FRONT PCB VOLUME PCB SELECT PCB H/P PCB USB PCB...
Page 54 SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. The semiconductor which described a detailed drawing in a schematic diagram are omitted to list. 1. IC's R5F564MJCDFC (DIGITAL : U1018) Pin Name Symbol Pu/Pd STBY STOP Function STBY XCIN...
Page 55 Pin Name Symbol Pu/Pd STBY STOP Function Pin Name Symbol Pu/Pd STBY STOP Function STBY STBY MIC_DET/_H/P_ Headphone insert detect pin/Microphone insert detect pin (A/D P10/IRQ0 CEC_IN CEC-D control pin 126 PE6/IRQ6/AN104 SW3VPu BY3VPu converter) ADV8003_SPI_CS DV3VPu GUI control pin(ADV8003) 127 VCC Power supply pin P52/RXD2...
Page 56 PCM9211 www.ti.com SBAS495 – JUNE 2010 PIN CONFIGURATIONS PCM9211 (DIGITAL : U1040) PT PACKAGE LQFP-48 DESCRIPTION (TOP VIEW) NAME TOLERANT 26 MS/ADR1 Software control I/F, SPI chip select / I2C slave address setting1(2) ERROR/INT0 VDDRX 27 MODE Control mode setting, (see the Serial Control Mode section, NPCM/INT1 RXIN1 MPIO_A0...
Page 57 PCM9211 LC89091JA (DIGITAL : U1004) PCM9211 BLOCK DIAGRAM www.ti.com SBAS495 – JUNE 2010 BLOCK DIAGRAM FILT LC89091JA AUXIN 0 AUTO RXIN7 RXIN 0 RXIN0 SCKO DOUT RXIN 1 RXIN1 MAIN OUTPUT RXIN 2 RXIN2 AUXIN0 LRCK SCKO/ BCK/LRCK PORT RXIN 3 RXIN3 AUXIN1 DOUT...
Page 58 CS49844A (DIGITAL : U1073) W9812G6KH-5 (DIGITAL : U1023) SD_A3, EXT_A3, DAO3_D3, XMTA, GPIO113 SD_A2, EXT_A2 SD_D11, EXT_D3 SD_A1, EXT_A1 SD_D12, EXT_D4 SD_A0, EXT_A0 SD_D13, EXT_D5 SD_A10, EXT_A12 GNDIO4 SD_BA0, EXT_A13 VDDIO4 SD_BA1, EXT_A14 SD_D14, EXT_D6 SD_CS, EXT_OE SD_D15, EXT_D7 SD_RAS, EXT_CS1 SD_D0, EXT_D8 SD_CAS, EXT_CS2 SD_D1, EXT_D9...
Page 59 AK4458VN 40 +105 C (Exposed pad is connected to ground) 40 +85 C (Exposed pad is open) 48-pin QFN (0.5mm pitch) AKD4458 Evaluation Board for AK4458 AK4458VN (INPUT : U1051, U1052) Block diagram Pin Configurations CLOCK BUFFER CONTROL SIGNAL GENERATOR COMMAND DECODER COLUMN DECODER...
Page 60: Functional Block Diagram
[AK4458] FUNCTIONAL BLOCK DIAGRAM No. Pin Name I/O Function PD State 4. Block Diagram and Functions CAD0_I2C Chip Address 0 Pin in I2C Bus serial control mode Chip Select Pin in 3-wire serial control mode LDOE TVDD VDD18 DVSS AVDD AVSS Hi-Z Audio Data Format Select in Parallel control mode.
Page 61: Device Information
SLAS764 – MAY 2011 www.ti.com DEVICE INFORMATION PCM5100A (DIGITAL : U1052, U1054) NJU72343 (INPUT : IC4202, IC4203) TERMINAL FUNCTIONS, PCM510x PCM510X (top view) Pin Function No. Symbol Function No. Symbol Function AREF Analog reference potential terminal DATA IC control data input Address selection terminal CLOCK IC control clock input...
Page 62: Package Outline
Bipolar Technology Package Outline GENERAL DESCRIPTION DIP16,DMP16 PACKAGE OUTLINE The NJM2586A is a wide band 3-input 1-output 3-circuit video PIN CONFIGURATION and BLOCK DIAGRAM amplifier. It is suitable for Y, Pb, and Pr signal because frequency NJM2595MTE1 (VIDEO:IC5001) range is 50MHz.The NJM2586A is suitable for AV receiver, STB, and other high quality AV systems.
Page 63: Pin Connection
2. FL DISPLAY FLD (CIG25-1801N) (FRONT : FL4400) ANODE CONNECTION 17G(AD3) 18G(AD4) SEGA1 SEGA2 SEGA3 SEGA4 SEGA5 SEGA6 SEGA7 SEGA8 SEGA9 SEGA10 SEGA11 SEGA12 SEGA13 SEGA14 SEGA15 SEGA16 SEGA17 SEGA18 SEGA19 SEGA20 SEGA21 SEGA22 SEGA23 SEGA24 SEGA25 SEGA26 PIN CONNECTION SEGA27 SEGA28 SEGA29...
Page 64 3. Remote Code Table FORMAT SHARP FORMAT: SHARP /DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED, 1=INVERTED /REMOTE ID: 1 SYSTEM ADDRESS (C1 ～ C5) : ００１１０ , EXTENSION BIT (C12,C13) : １０ FORMAT: SHARP /DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED, 1=INVERTED /REMOTE ID: 1 Data (C6 ～...
Page 65 FORMAT: SHARP /DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED, 1=INVERTED /REMOTE ID: 1 SYSTEM ADDRESS (C1 ～ C5) : ００１００ , EXTENSION BIT (C12,C13) : ０１ DATA CONSTRUCTION 48bits Data (C6 ～ C11) Key Name Data (C6 ～ C11) Key Name DENON CODE Parity GENRE1 (*1) RCSHP0420000 ００００００ RCSHP0420016 ００００１０...
Page 66 MAIN ZONE RCKSK0410389 C LEVEL DOWN RCKSK0410390 SW LEVEL UP RCKSK0410391 SW LEVEL DOWN REMOTE ID SET: 1 RCKSK0410392 SL LEVEL UP RCKSK0410393 SL LEVEL DOWN DENON CODE Parity GENRE1 GENRE2 RCKSK0410394 SR LEVEL UP ４５２３０ RCKSK0410395...
Page 67 ZONE2 RCKSK0410735 MEDIA PLAYER RCKSK0410736 MultEQ XT32 RCKSK0410741 INTERNET RADIO (Recent Play) REMOTE ID SET: 1 RCKSK0410746 DYNAMIC EQ ON RCKSK0410747 DYNAMIC EQ OFF DENON CODE Parity GENRE1 GENRE2 RCKSK0410748 DYNAMIC VOLUME (Heavy) ４５２３０ RCKSK0410749 DYNAMIC VOLUME (Medium)
Page 68 ANALOG TUNER RCKSK0430978 ZONE2 BAND AM RCKSK0430979 ZONE2 Fast Forward RCKSK0430983 ZONE2 SEARCH (RDS) REMOTE ID SET: 1 RCKSK0430992 ZONE2 PLAY/PAUSE RCKSK0430993 ZONE2 STOP DENON CODE Parity GENRE1 GENRE2 RCKSK0430994 ZONE2 PAUSE ４５２３０ ZONE2 SKIP MINUS/TUNING...
Page 69 MECHANICAL DISASSEMBLY Flowchart 1. FRONT ASSY 2. RADIATOR ASSY 3. TUNER PCB 4. REAR PANEL 5. DIGITAL PCB 6. VIDEO PCB 7. INPUT PCB 8. MAIN PCB 9. SMPS PCB 10. TRANS EXPLODED VIEW PACKAGING VIEW...
Page 70 DISASSEMBLY Flowchart • Remove each part following the flow below. • Reassemble the removed parts in the reverse order. • Read "SAFETY PRECAUTIONS" before reassembling the removed parts. • If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise. • See "EXPLODED VIEW" TOP COVER FRONT ASSY TUNER PCB SMPS PCB TRANS DISASSEMBLY DISASSEMBLY DISASSEMBLY DISASSEMBLY 1. FRONT ASSY 3. TUNER PCB 9. SMPS PCB 10. TRANS and "EXPLODED VIEW" and "EXPLODED VIEW" and "EXPLODED VIEW" and "EXPLODED VIEW" FRONT PCB TUNER PCB SMPS PCB POWER TRANS Ref. No. of EXPLODED VIEW : P 3 Ref. No. of EXPLODED VIEW : P 21 Ref. No. of EXPLODED VIEW : P 8 Ref. No. of EXPLODED VIEW : 13 F_HDMI PCB Ref. No. of EXPLODED VIEW : P 1...
Page 71: Front Assy
• For the shooting direction of each photos used in this manual, see the photo below. • A, B, C and D in the photo below indicate the shooting directions of photos. Proceeding : TOP COVER → FRONT ASSY • The photographs with no shooting direction indicated were taken from the top of the unit. (1) Remove the screws. • Photos of AVR-X3600H E3 are used in this manual. The viewpoint of each photograph (Shooting direction : X) [View from the top] ↓Shooting direction: B↓ View from the bottom (2) Cut the wire clamps, then remove the CORD HOLDERs and connectors. Remove the FFC. CP4400 CORD HOLDER ↑Shooting direction: A↑...
Page 72: Radiator Assy
(3) Remove the connector. 2. RADIATOR ASSY Proceeding : TOP COVER → FRONT ASSY → RADIATOR ASSY (1) Remove the screws. N1027 View from the bottom N1025 ↑Shooting direction: A↑ 3. TUNER PCB (2) Cut the wire clamp, then remove the connector. Proceeding : TOP COVER → TUNER PCB CP405 See "EXPLODED VIEW" for instructions on removing the TUNER PCB. 4.
Page 73: Digital Pcb
5. DIGITAL PCB 6. VIDEO PCB Proceeding : TOP COVER → TUNER PCB → REAR PANEL → DIGITAL PCB Proceeding : TOP COVER → TUNER PCB → REAR PANEL → DIGITAL PCB → VIDEO PCB (1) C ut the wire clamp, then remove the connector. Remove the FFC. (1) Remove the screws. Remove the connector.
Page 74 8. MAIN PCB Proceeding : TOP COVER → FRONT ASSY → RADIATOR ASSY → TUNER PCB → REAR PANEL → DIGITAL PCB → VIDEO PCB → INPUT PCB → MAIN PCB (1) Remove the screws. View from the bottom (2) Remove the screws. Remove the CORD HOLDER and connectors. CORD HOLDER 9.
Page 75: Exploded View
EXPLODED VIEW http://dmedia.soundunited.com/documents/details/25940 Parts List : E X2 Precautions when aﬃxing the BADGE (1) The BADGE is incredibly fragile, so using the same force as you would when applying a label is likely to cause deformation. Once deformed it is very diﬃcult to return it to its P8-1 original shape, so take care when handling it.
Page 76 SIZE : 350mm x 210mm EU toll-free leaflet (De) (E2 only) Notes on RADIO (ALL) This part together with document and zipper bag are supplied. HEOS insertion sheet (DENON) Cautions on Using Batteries (E2 Only) MIC STAND ASSEMBLY INSTRUCTIONS SPOTIFY insertion sheet (E3/E2) SAFETY INST.
Page 77: Troubleshooting
REPAIR INFORMATION TROUBLE SHOOTING SPECIAL MODE 1. POWER Special mode setting button 2. Analog video 1. Version Display Mode 3. HDMI/DVI 2. PANEL / REMOTE LOCK Selection Mode 4. AUDIO 3-1. Selecting the Mode for Service-related 5. Network / Bluetooth / USB 3-2.
Page 78 TROUBLE SHOOTING 1. POWER 1.1. The unit does not power on 1.2. Fuse is blown The unit does not power on Blown fuse Check for short circuits between the Does the power indicator on the front panel flash Check the rectifier diode in the Does the power shut down after several seconds? Check for leaks and short circuits regulator output terminal and GND...
Page 79: Analog Video
2. Analog video CVBS / COMPONENT / HDMI OUT NG Input CVBS / COMPONENT Input CVBS Input COMPONENT Input Function : CBL / SAT Function : CBL / SAT HDMI Check the input signal to the VIDEO DECODER. Can a signal be confirmed at the following To "A"...
Page 80 Input Input CVBS COMPONENT Check the settings of each IC. Check the settings of each IC. Are the following voltages set? Are the following voltages set? DIGITAL PCB DIGITAL PCB faulty. DIGITAL PCB DIGITAL PCB faulty. [N1043 : 10pin] : Hi (3.3 V) [N1039 : 9pin] : Lo (0 V) [N1043 : 11pin] : Hi (3.3 V)
Page 81 3.1. No picture or sound is output (HDMI to HDMI) No picture or sound is output. (8) When using a DENON Blu-ray/DVD player, is the "HDMI" indicator of the fluorescent display lit? Proceed to YES when using a Blu-ray/DVD player produced by other manufactures.
Page 82 (15) Are a picture and sound output when a differ- The TV is faulty. ent TV is used? Check the unit. "HDMI "Rx/Tx" Failure Detection"...
Page 83: Audio Check
4. AUDIO 4.1. AUDIO CHECK No audio output CHECK 1 INPUT SURROUND MODE SOURCE Check the ANALOG AUDIO BLOCK Audio output OK? ANALOG 2CH DIRECT ANALOG CHECK 2 INPUT SURROUND MODE SOURCE Check the DIGITAL AUDIO BLOCK Legacy Audio output OK? COAX or OPT (PCM or DolbyDigital or dts…) CHECK 3...
Page 84: Analog Audio
4.2. Power AMP (AMP PCB) 4.3. Analog audio When using the protection pass mode, do not connect speakers to the speaker terminals. No audio output. No audio output. Protection is activated. Is a voltage of ± 8V supplied to INPUT PCB Repair the ±...
Page 85: Cannot Connect To The Network
5. Network / Bluetooth / USB 5.1. Cannot connect to the network Check the connection environment The circuit of NET5V POWER Insert the LAN cable correctly and then turn on Can the output voltage (5V) to Is NET5V POWER [U1018 : 48pin Is the LAN cable correctly inserted? between [U1018-Q1082 : FET- the power again.
Page 86 5.2. Cannot establish a Bluetooth connection Check the Bluetooth device being used Are the versions of the HEOS Version displayed in The Network Module software is faulty. Version Check Mode? Is the Bluetooth device compatible with the A2DP Use a device that is A2DP profile compatible. profile? The circuit of Network Module is faulty.
Page 87 5.3. Cannot recognize the connected USB device 5.4. No picture or sound is output Check the USB device being used Checking the unit (If no picture is output) Are digital video signals(LEGOPCK, LEGOVS, The circuit around Network Module, [U1011 : Is a USB hub being used? Do not use a USB hub.
Page 88 DIGITAL test point USB test point N1017 Q1023 C1293 Q1024 CN4402 R1025 R1027 D1005 R1023 C1948 C1954 BKT1000 D1007 D1006 R1026 R1024 R2060 R2073 R1028 N1008 N1027 BKT1001 ACE TAPE L1029 U1012 C1315 C1318 NET5V_POWER C1306 C1303 Q1059 R1779 L1131 C1177 C1570 C1189...
Page 89 6. SMPS Operation waveform for each part DC 5V is not output. After primary side rectiﬁcation Primary drain (Caution: High voltage, electric shock) (Caution: High voltage, electric shock) Replace the [IC901 : TOP268EG Is [IC901 : TOP268EG] damaged? and D9001 / D9002 / D9003 / D9002 1N4007 J9008...
Page 90 PROTECTION DIAGRAM 5CH-AMP uCOM TR_THERMAL DC/ASO PROT 125pin/AN105 PROTECTION LOGIC ⇒ L_active shutdown THER PROT F 96pin/PB5 TR_THERMAL ⇒ L_active shutdown THER PROT E 161pin/P91 THER PROTA ⇒ Change Power AMP Power Supply Voltage THER PROTE ⇒ L_active shutdown THER PROT A 159pin/P93 THER PROTF ⇒...
Page 91: Hdmi Block
AUDIO CHECK PATH : Digital Signal : Analog Signal HDMI BLOCK HDMI BLOCK CHECK6 HDMI HDMI SPEAKER OUTPUT HDMI INPUT OUTPUT CHECK5 INPUT PREOUT HDMI Transceiver CHECK4 AVR Supported "HD AUDIO" OUTPUT HDMI Transceiver MN864788 ARC INPUT MN864787 FRONT HDMI INPUT Digital audio BLOCK I2S/HBR AUDIO...
Page 92 HDMI "Rx/Tx" Failure Detection 1. Prior checking Check item(1.). : Checking the HDMI connector Checking the condition of the HDMI pin (rear/front). There are deformed pins. Replace the HDMI connector. Check for deformed pins. None of the pins are deformed. Check by following the flow chart for "3.
Page 93 2. Preparations for checking HDMI Switcher reception/transmission register 2-3. Device configuration method 2-1. Necessary devices PC settings : Execute the serial communication program, Termite.exe. Check the product settings. 2-a) Player with an HDMI terminal After executing Termite.exe, click [Settings]. 2-b) TV with an HDMI terminal (* NOTE : Do not use a computer monitor.) Windows PC Serial communication software "Termite.exe"...
Page 94 Click the [click to connect] button to start communication. When the settings are correct, the following message will be displayed in the window of Termite. After a connection is established successfully, the display of the button name will change as shown in [00]Start Sub CPU Log Mode Figure 4.
Page 95: Contact Support
3. Starting detecting the point of failure Check item(3.1.). Display when an Error is not detected. Check the power supply status and communication status with the CPU of each device. Start in HDMI Diagnostics mode and follow the procedures below. 1 Auto Test Cancel the mode, and proceed to check item...
Page 96 Check item(3.2.). : Does a video signal come from HDMI Check item(3.4.). Does a video signal come from HDMI OUT to ZONE2 OUT to TV correctly? TV correctly? HDMI IN ZONE2 OUT HDMI IN HDMI OUT1/2 Go to check item (3-11.1.). (Switcher1 failure detection proce- dure) Go to...
Page 97 3-1. Error Code H1-01 failure detection procedure Checking device. [U1001 : MN864787] Check the power supply voltage. (HDMI Tx) Checking the reset waveform. (HDMI Tx) Check item(3-1.1.). Check the power supply voltage. : Check item(3-1.3.). Checking the reset waveform : Check the waveform.
Page 98 Check the I2C communication line. (HDMI Tx) Check item(3-1.4.). Check the I2C communication line : Check the CPU. Is the "I2C" waveform of the TP near the HDMI SW1 [U1003] correct (like the one shown in the diagram) when the power is turned on? I2C(HSCL) I2C(HSDA)
Page 99 3-2. Error Code H1-02 failure detection procedure Checking device. [U1003 : MN864788] Check the power supply voltage. (HDMI SW1) Checking the reset waveform. (HDMI SW1) Check item(3-2.1.). Check the power supply voltage. : Check item(3-2.3.). Checking the reset waveform : Check the waveform.
Page 100 Check the I2C communication line. (HDMI SW1) Check item(3-2.4.). Check the I2C communication line : Check the CPU. Is the "I2C" waveform of the TP near the HDMI SW1 [U1003] correct (like the one shown in the diagram) when the power is turned on? I2C(HSCL) I2C(HSDA)
Page 101 3-3. Error Code H1-03 failure detection procedure Checking device. [U1000 : MN864788] Check the power supply voltage. (HDMI SW2) Checking the reset waveform. (HDMI SW2) Check item(3-3.1.). Check the power supply voltage. : Check item(3-3.3.). Checking the reset waveform : Check the waveform.
Page 102 Check the I2C communication line. (HDMI SW2) Check item(3-3.4.). Check the I2C communication line : Check the CPU. Is the "I2C" waveform of the TP near the HDMI SW2 [U1000] correct (like the one shown in the diagram) when the power is turned on? I2C(HSCL) I2C(HSDA)
Page 103 3-4. Error Code H1-06 failure detection procedure Checking device. [U1026 : ADV8003] Check the power supply voltage. Checking the reset waveform. Check item(3-4.1.). Check the power supply volt- Check item(3-4.2.). Check the power supply volt- Check item(3-4.3.). Checking the reset : age.
Page 104 Check the I2C communication line. Check item(3-4.4.). Check the I2C communication line : Check the CPU. Is the "I2C" waveform of the TP near the CPU [U1018] correct (like the one shown in the diagram) when the power is turned on? AVSDA AVSCL U2022...
Page 105 3-5. Error Code H1-14 failure detection procedure 3-6. Error Code H1-15 failure detection procedure Checking device. [U1028/U1029 : A3R12E40DBF-8E] Checking device. [U1027 : W25Q128JVFIQ] Check item(3-6.1.). Check item(3-5.1.). Write to the GUI ROM. Check soldering of IP SCALER [U1026], DDR2 [U1028/U1029] and its peripheral circuits. Check soldering of the resistors [R1688/1689/1692/1695 to 1700/1703 to 1711] between IP SCALER and...
Page 106 3-7. Error Code H1-05 failure detection procedure Checking device. [U2022 : ADV7180] Check item(3-7.1.). Replace [U2022] with a new device. Recheck from check item (3.1.). Does Error Code H1-05 continue? Replace the PCB. Recheck from check item (3.2.).
Page 107 3-8. Error Code H1-08 failure detection procedure Checking device. [U1073 : CS49844A] Check the power supply voltage. Checking the reset waveform. Check item(3-8.1.). Check the power supply volt- Check item(3-8.2.). Check the power supply volt- Check item(3-8.3.). Checking the reset : age.
Page 108 Check the SPI communication line. Check item(3-8.4.). Check the SPI communication line : Check the CPU. Is the "SPI" waveform of the TP near the DSP [U1073] correct (like the one shown in the diagram) when the power is turned on? 3 pin CLK 4 pin MOSI 6 pin CS...
Page 109 3-9. Error Code H1-12 failure detection procedure Checking device. [U1040 : PCM9211] Check the power supply voltage. Checking the reset waveform. Check item(3-9.1.). Check the power supply volt- Check item(3-9.2.). Check the power supply volt- Check item(3-9.3.). Checking the reset : age.
Page 110 Check the communication line. Check item(3-9.4.). Check the communication line : Check the CPU. Is the waveform of the TP near the DIR [U1040] correct (like the one shown in the diagram) when the power is turned on? MOSI U1040 MISO *The diagram shows an example.
Page 111 3-10. Error Code H1-16 failure detection procedure Checking device. [U1007 : Sil9437] Check the power supply voltage. (ARC IC) Checking the reset waveform. (ARC IC) Check item(3-10.1.). Check the power supply voltage. : Check item(3-10.3.). Checking the reset waveform : Check the waveform.
Page 112 Check the I2C communication line. (ARC IC) Check item(3-10.4.). Check the I2C communication line : Check the CPU. Is the waveform of the TP near the ARC IC [U1007] correct (like the one shown in the diagram) when the power is turned on? AVSDA(R2153) U1007 AVSCL(R2152)
Page 113 3-11. Switcher1 failure detection procedure HDMI IN ZONE2 OUT Check item(3-11.2.). Checking the DDC status register : Example Send the following command from Termite.exe. b In order to check, connect the player to the HDMI terminal and configure the player as AVR source. Next, turn on the power for the player and TV and start playback on the player.
Page 114 When the results of check item (3-11.1.) are "NO" When the results of check item (3-11.2.) are "00 or 04" (Detection of 5V is not OK) (Detection of DDC is not OK.) Check the +5V voltage. (HDMI IN5 - 7) Check the DDC line.
Page 115 When the results of check item (3-11.2.) are "22 or 11" (Detection of DDC is OK.) Checking the TMDS status register (HDMI Switcher1) 3.3V TMDS Signal TMDS Check item(3-11.5.). Checking register of the TMDS CLK detection sta- Example tus register : Send the following command from Termite.exe.
Page 116 When the results of check item (3-11.7.) are "33 or 23 or 13 or 03" Example (Detection of HPD is OK / Detection of RXSENSE is OK ) Checking the EDID register. (HDMI ZONE2 OUT) Check item(3-11.8.). Check the Monitor EDID : ①...
Page 117 When the results of check item (3-11.7.) are "31 or 21 or 11 or 01" When the results of check item (3-11.7.) are "32 or 22 or 12 or 02" (Detection of HPD is OK / Detection of RXSENSE is not OK ) (Detection of HPD is not OK / Detection of RXSENSE is OK ) Check the TMDS.
Page 118 When the results of check item (3-11.7.) are "30 or 20 or 10 or 00" (Detection of HPD is not OK / Detection of RXSENSE is not OK ) Check the TMDS/HPD. (HDMI ZONE2 OUT) Check item(3-11.13.). Checking the HPD and RXSENSE. : Does the test point near HDMI output terminal [N1030] indicate (3.3V)? Does the test point (HPD) near HDMI output terminal [N1030] indi-...
Page 119 3-12. Switcher2 failure detection procedure HDMI IN ZONE2 OUT Check item(3-12.2.). Checking the DDC status register : Example Send the following command from Termite.exe. b In order to check, connect the player to the HDMI terminal and configure the player as AVR source. Next, turn on the power for the player and TV and start playback on the player.
Page 120 When the results of check item (3-12.1.) are "NO" When the results of check item (3-12.2.) are "00 or 04" (Detection of 5V is not OK) (Detection of DDC is not OK.) Check the +5V voltage. (HDMI IN1 - 4) Check the DDC line.
Page 121 When the results of check item (3-12.2.) are "22 or 11" (Detection of DDC is OK.) 3.3V TMDS Signal Check item(3-12.6.). Checking the TMDS input waveform. : Checking the TMDS status register (HDMI Switcher2) Check the TMDS waveform at the following test point. Is the waveform like the sample? Check item(3-12.5.).
Page 122 3-13. Tx failure detection procedure Check the output terminal. Check item(3-13.1.). Check the video output port for failure. : Check the Monitor 1 output video signal is correct. After checking the Monitor 1, change the HDMI cable connection from OUT1 to OUT2. Turn off the AV AMP and turn it on again.
Page 123 Checking operation between the HDMI (SW) device and the HDMI device (Tx). Checking between Monitor1 and the TV. Checking operation between the HDMI (Tx) device and TV. Connect Monitor1 to the TV and check the following items with the TV turned on. HDMI1 in HDMI5 in HDMI OUT1...
Page 124 Example When the results of check item (3-13.4.) are "30" (Detection of HPD is OK / Detection of RXSENSE is OK ) Checking the EDID register. (HDMI OUT1) Check item(3-13.5.). Check the Monitor EDID : ① Unplug the AC cord. Plug the AC cord into a power outlet. The first eight bytes are nor- ②...
Page 125 When the results of check item (3-13.4.) are "10" When the results of check item (3-13.4.) are "20" (Detection of HPD is OK / Detection of RXSENSE is not OK ) (Detection of HPD is not OK / Detection of RXSENSE is OK ) Check the TMDS.
Page 126 When the results of check item (3-13.4.) are "00" (Detection of HPD is not OK / Detection of RXSENSE is not OK ) Check the TMDS/HPD. (HDMI OUT1) Check item(3-13.10.). Checking the HPD and RXSENSE. : Does the test point near HDMI output terminal [N1031] indicate (3.3V)? Does the test point (HPD) near HDMI output terminal [N1031] indi- cate "Hi(3-5V)"?
Page 127 Checking between Monitor 2 and the TV. Connect Monitor2 to the TV and check the following items with the TV turned on. Checking the HPD/RXSENSE status register. (HDMI OUT2) Check item(3-13.11.). Check the HPD and RXSENSE register value of Example the HDMI TX device.
Page 128 When the results of check item (3-13.11.) are "03" (Detection of HPD is OK / Detection of RXSENSE is OK ) Example Checking the EDID register. (OUT2) Check item(3-13.12.). Check the Monitor EDID : ① Unplug the AC cord. Plug the AC cord into a power outlet. ②...
Page 129 When the results of check item (3-13.11.) are "01" When the results of check item (3-13.11.) are "02" (Detection of HPD is OK / Detection of RXSENSE is not OK ) (Detection of HPD is not OK / Detection of RXSENSE is OK ) Check the RXSENSE.
Page 130 When the results of check item (3-13.11.) are "00" (Detection of HPD is not OK / Detection of RXSENSE is not OK ) Checking the HPD/RXSENSE status register. (OUT2) Check item(3-13.17.). Checking the HPD and RXSENSE. : Does the test point of RXSENSE close to the HDMI output terminal [N1037] indicate the (3.3V)? Does the voltage of HPD test point close to the HDMI output terminal [N1037] indicate Hi (3-5 V)?
Page 131 3-14. Front HDMI Buffer failure detection procedure Checking operation between the HDMI (Front HDMI Buffer) and the player Checking the +5V/DDC status register ( HDMI DDC Buffer) Check item(3-14.3.). Checking the 5V status register : Example b In order to check, connect the player to the HDMI terminal and configure the player as AVR source. Send the following command from Termite.exe.
Page 132 When the results of check item (3-14.3.) are "78 or 70" When the results of check item (3-14.4.) are "00 or 04" (Detection of 5V is not OK.) (Detection of DDC is not OK.) Check the +5V voltage. (HDMI DDC Buffer) Check the DDC Line.
Page 133 When the results of check item (3-14.4.) are "22" (Detection of DDC is OK) Checking the TMDS status register (HDMI DDC Buffer) 3.3V TMDS Signal Check item(3-14.7.). Check the TMDS CLK detection status of the Check item(3-14.8.). Checking the TMDS input waveform. : Example register.
Page 134 3-15. GUI and PLD failure detection procedure Check item(3-15.1.). Does a video signal come from HDMI OUT to TV correctly? : Check item(3-15.3.). Check the PLD video signal line from the GUI : HDMI OUT 3.3V Check the video signal waveform at the following test point. Is the waveform like the sample? Example of waveform in check ①...
Page 135 When the results of check item (3-15.1.) are "YES" (When the menu display is OK) Check item(3-15.5.). Check the PLD video signal line from the HDMI Tx : HDMI HDMI OUT 3.3V Check the video signal waveform at the following test point. Is the waveform like the sample? Turn Video Conversion "ON"...
Page 136 4. Device implementation location DIGITAL (A SIDE) F-HDMI (A SIDE) N1017 Q1023 C1293 Q1024 R1025 R1027 D1005 R1023 BKT1000 R1692,R1695,R1696,R1697,R1698,R1699,R1700, C1948 C1954 D1007 D1006 R1026 R1024 R2060 R2073 R1028 BKT1001 N1008 N1027 R1703,R1704,R1705,R1706,R1707,R1710 ACE TAPE L1029 C1315 C1318 C1306 NET5V_POWER C1303 Q1059 R1779...
Page 137: Clock Flow & Wave Form In Digital Block
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK WAVE FORM ③ (1)DIRIN SPDIF (1) DIR input CH0ASD0 RXI2S0/DSD1 RXI2S1/DSD2 MCLK CH0ASD1 DACMCK U1001 RXI2S2/DSD3 CH0ASD2 DACBCK BICK MN864787 CH0ASD3 RXI2S3/DSD4 DACLRCK LRCK HDMI Tx CH0ALRCLK RXLRCK/DSD5 U1051 CH0ABCLK RXBCK/DSDSCK AK4458VN CH0AMCLK RXMCK/DSDMCK CH0ASPDIF...
Page 138: Special Mode Setting Button
(E3 and E2 model only) (See 3-5. TUNER STEP mode (E3 / E2 only)) If there are multiple DENON AV receivers in the same area, this mode prevents other AV receivers from being operated concurrently 3-6 Remote ID Setup Mode with this device. ↑...
Page 139 1. Version Display Mode 1.1. Actions Q0 HEOS Version : Q5 Restore Version : Version information is displayed when the device is started in this mode. HEOS Version RSTR "Press "STATUS" button. "Press "STATUS" button. 1.2. Starting up While holding down buttons "DIMMER" and "STATUS" simultaneously, press the power button to turn *.***.*** ************ on the power.
Page 140: Error Display
1.4. Error display See the table below for descriptions of the displayed errors and countermeasures for these. If multiple errors occur, only one item is displayed. The priority order is w, e, r, t, y, q. Condition States Display TROUBLE SHOOTING The model name, brand name and region information written in the firmware are compared FIRM ERROR to the region settings in the PCB.
Page 141 1.5. Version Display in the Setup Menu Follow the steps below to display the firmware information. (1) Press the "SETUP" button on the remote control. (2) Select "General - Information - Firmware". The version information is displayed as a 16-digit number as shown in the screenshot below. General/Firmware Version XXXX-XXXX-XXXX-XXXX...
Page 142 2. PANEL / REMOTE LOCK Selection Mode 2.1. Actions The REMOTE LOCK mode is turned off. Switch the PANEL LOCK and REMOTE LOCK modes between on and off. • PANEL LOCK Mode (with Volume) Disables reception from all keys and encoders on the front panel except the power button (including the volume).
Page 143: Service Check
3-1. Selecting the Mode for Service-related 3-1.1. Actions Select diagnostic mode (service path check mode), protection history display mode, 232C standby clear 4.OP INFO mode, Operation Info mode, TUNER STEP mode or Remote ID Setup Mode. Operation Info for the unit can be checked. 3-1.2.
Page 144: Protection History Display Mode
3-2. Protection History Display Mode 3-2.1. Actions (3) DC (if the last protection is DC) This mode enables the unit to record and display the event when the THERMAL, ASO or DC protection is PRT:DC activated. Cause : DC output of the power amplifier is abnormal. If protections have been activated multiple times, the latest protection operation is recorded.
Page 145 3-2.4. Clearing the Protection History 3-3. 232C Standby Clear Mode There are two ways to clear the protection history. 3-3.1. Actions (1) Activate Protection History Display Mode. Press the "STATUS" button to display the protection Switches from 232C standby mode to normal standby mode. history.
Page 146 3-4. Operation Info Mode 3-4.1. Actions (3) DC / ASO Protection count This mode enables the unit to display the accumulated operating time, power On count and each DC:___/ASO:___ protection count. "STATUS" 3-4.2. Starting up While holding down buttons "ZONE2 SOURCE", "DIMMER" and "STATUS" simultaneously, press the (4) Thermal Protection (A) count power button to turn on the power.
Page 147 This is a special mode that enables the reception frequency STEP of the ANALOG TUNER to be changed. This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same room.
Page 148: Network Initialization Mode
4. Protection Pass Mode 5. Network Initialization Mode 4.1. Actions 5.1. Actions • This mode allows the power to be turned on without activating protections. The following items are initialized. • This mode functions in the same way as normal power-on, except that protections are not activated. Network setup •...
Page 149 6. Clearing of Operation Info 7. Log Capture feature 6.1. Actions 7.1. Actions • Displays the accumulated operating time of the unit, the number of times the power was switched • Acquires the Network Module log. on, and the number of occurrences of each protection. •...
Page 150 DIAGNOSTIC MODE Service Path Check Mode 1.1. Actions This function is convenient for confirming problem paths in the product and checking the paths after repairing. The video system and audio system operation paths can be checked. The backup data is not rewritten. 1.2.
Page 151 Paths to be confirmed Display Settings What to confirm Input Source : HEOS Music • Digital(PCM) input ⇒ Speaker output (Height2 (ZONE2) L/R) Input Mode : Auto • Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R) Sound mode : STEREO ( b The ZONE2 input source can be switched to any source except HEOS Music.) Amp assign : 7.1ch + ZONE2 (Do not select "SOURCE"...
Page 152 Paths to be confirmed Display Settings What to confirm Input Source : CBL/SAT • Analog input ⇒ Speaker output (Height1 L/R (Top Front), Height2 L/R (Top Rear)) Input Mode : Auto • Analog input ⇒ Pre OUT output (Height1 L/R (Top Front), Height2 L/R (Top Rear)) Sound mode : MULTI CH STEREO •...
Page 153 1.6. Confirmation items for the video system See the block diagram fig.VXXth. Paths to be confirmed Display Settings What to confirm Input Source : CBL/SAT • CVBS input ⇒ CVBS output Video Conversion (IP Scaler) : OFF, All sources • Component input ⇒ Component output 1 Analog Video pass fig.V01 V01:VIDEO PASS...
Page 154: Diagnostic Path Diagram
DIAGNOSTIC PATH DIAGRAM fig.A01 AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC...
Page 155 fig.A02a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 156 fig.A02b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 157 fig.A03a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 158 fig.A03b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 159 fig.A04a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 160 fig.A04b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 161 fig.A05a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 162 fig.A05b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 163 fig.A06 AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 164 fig.A07a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 165 fig.A07b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 166 fig.A08a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 167 fig.A08b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 168 fig.A09a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 169 fig.A09b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 170 fig.A10a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 171 fig.A10b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 172 fig.V01 AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA TMDS TMDS FRONT IN_3 TMDS HDMI OUT1 OUT_1 HDMI 27MHz TMDS HDMI OUT2 OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS HDMI1 IN_3 OUT_0 IN_1 MN864788 (1080p ->...
Page 173 fig.V02 AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA TMDS TMDS FRONT IN_3 TMDS HDMI OUT1 OUT_1 HDMI 27MHz TMDS HDMI OUT2 OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS HDMI1 IN_3 OUT_0 IN_1 MN864788 (1080p ->...
Page 174 fig.V03 AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA TMDS TMDS FRONT IN_3 TMDS HDMI OUT1 OUT_1 HDMI 27MHz TMDS HDMI OUT2 OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS HDMI1 IN_3 OUT_0 IN_1 MN864788 (1080p ->...
Page 175 fig.V04 AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA TMDS TMDS FRONT IN_3 TMDS HDMI OUT1 OUT_1 HDMI 27MHz TMDS HDMI OUT2 OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS HDMI1 IN_3 OUT_0 IN_1 uCOM MN864788 (1080p ->...
Page 176 fig.V05a AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 177 fig.V05b AVR_X3600 ANALOG AUDIO DIAGRAM TO DIGTAL AUDIO BLOCK 8-CH VOLUME NJU72343 LEGO_L 8-CH VOLUME NJU72343 MAIN_L InA1 OutA 7-INPUT/3-OUT LEGO_R DA_FL NJU72750 InA2 7-INPUT/3-OUTPUT MAIN_R InB1 OutB InA1 NJU72750 PHONO_L DA_FR InA2 InB2 InA3 OutA1 MAIN_AD_IN_L CBL/SAT_L DA_C OutC InA4 OutA2 LEGO_L...
Page 178 fig.V06 AVR_X3600 DIGITAL AUDIO DIAGRAM TCA9517DGKR TMDS HDMI ZONE2 BUFFER DDC_CLK/DATA FRONT TMDS TMDS IN_3 HDMI TMDS OUT_1 HDMI OUT1 27MHz TMDS MN864787 HDMI OUT2 TMDS TMDS OUT_0 OUT_0 IN_1 HDMI1 IN_3 MN864788 HDMI (TX / RX / OSD / Scaler ) TMDS IN_0 HDMI2.0...
Page 179 fig.V07 AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA TMDS TMDS FRONT IN_3 TMDS HDMI OUT1 OUT_1 HDMI 27MHz TMDS HDMI OUT2 OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS HDMI1 IN_3 OUT_0 IN_1 MN864788 (1080p ->...
Page 180 fig.V08 AVR_X3600 VIDEO DIAGRAM TCA9517DGKR BUFFER TMDS HDMI ZONE2 DDC_CLK/DATA TMDS TMDS FRONT IN_3 TMDS HDMI OUT1 OUT_1 HDMI 27MHz TMDS HDMI OUT2 OUT_0 MN864787 HDMI (TX / RX / OSD / Scaler ) TMDS TMDS HDMI1 IN_3 OUT_0 IN_1 MN864788 (1080p ->...
Page 181: Jig For Servicing
JIG FOR SERVICING Use the following jigs (extension cable kit) when repairing the PCBs. Order with your dealer for the jigs your dealer if necessary. CN5000 CAUTION : Incorrect connections may cause malfunction. Connection of Jig for DIGITAL PCB ---Items to Be Prepared--- 8U-110084S : EXTENSION UNIT KIT 1 Set 8U-110136S : EXTENSION UNIT KIT...
Page 182 (4) Connect the expansion cables. Board-to-Board Connections Ref. No. Ref. No. N1024 DIGITAL 11pin CP1023 SIDE CNT FRONT CNT 23pin CP1017 SIDE CNT N1026 DIGITAL 21pin CP1018 SIDE CNT N1018 DIGITAL 15pin CP1040 FRONT CNT N1044 DIGITAL 17pin CP1039 FRONT CNT N1043 DIGITAL 9pin...
Page 183: Adjustment Procedure
ADJUSTMENT Adjusting Idling Current NOTE： Adjusting the idling current when "ECO Mode" is set may damage the Power AMP. AMP UNIT 1. Preparation (1) Prepare a DC voltmeter. (2) Place the unit under normal usage conditions, away from highly ventilated areas such as next to an air conditioning machine or electric fan.
Page 184 UPDATING PROCEDURE AFTER REPLACING THE PCB. PROCEDURE AFTER REPLACING THE U-COM, ETC. FIRMWARE UPDATE PROCEDURE 1. Items necessary for update 2. Update preparation with a USB flash drive 3. Update method when the DIGITAL PCB or network module is replaced (Using a USB flash drive) 4.
Page 185 PROCEDURE AFTER REPLACING THE PCB. PROCEDURE AFTER REPLACING THE U-COM, ETC. The procedure after replacing the printed circuit boards is as follows. The procedure after replacing the MCU (microprocessor), flash ROM, etc. is as follows. (1) Change the resistor for setting the region. Implement the update method when the DIGITAL PCB or network module is replaced.
Page 186: Firmware Update Procedure
Update download file when the DIGITAL PCB or network module is replaced Model Name Model Area Download from SDI AVR-X3600H avr_40.prod.update.factory.xxxx.zip Table 2 Update download file when the firmware is updated (Two files, "HW component" and "LEGO component") Download from SDI...
Page 187 2. Update preparation with a USB flash drive You can update the firmware by downloading the latest version with USB flash drive. 2.1. Connecting to the USB flash drive (1) Preparation • Windows PC • USB flash drive format : Prepare a USB flash drive formatted in FAT16 or FAT32. b We recommend a USB flash drive that has an LED installed.
Page 188 3. Update method when the DIGITAL PCB or network module is replaced (Using a USB flash drive) 3.1. File structure on USB flash drive (5) USB Update starts automatically. The Standby LED lights red. DIGITAL PCB or network module is replaced onto the USB flash drive in the following structure. Display during USB update After unzipping the files, store them in the root of the same USB flash drive.
Page 189 (4) Insert the USB flash drive into the USB port. NOTE : Enter the file name in double quotation marks. (The file extension is not required.) Service Region File name North America "denon-config-locale-set-1" Download ﬁrmware in USB ﬂash drive. Europe "denon-config-locale-set-2"...
Page 190 5. Normal Firmware Update Method from USB Flash Drive 5.1. File structure on USB flash drive (1) Press the power button to turn on the power. (2) Wait for this unit to start up. Copy the normal update files onto the USB flash drive in the following structure. (3) Set the input source to HEOS Music.
Page 191: Network Connection
6. Normal Firmware Update Method from OTA 6.2. Check and update the firmware Download the latest firmware from our website and update the firmware. Check if there is a firmware update available. It is also possible to check approximately how long the ---Cautions on Firmware Update--- update will take.
Page 192 7. About the error codes See the table below for details on error codes and solutions when updating the firmware. Device ID table Error codes are displayed in 4 digits, : DeviceID, : ErrorCode). YYXX Device ID ( YY ) Device Name Display General...

This manual is also suitable for:

Avrx3600hbke3 Avrx3600hbke2 Avrx3600hbke1c
