30" Sigle Wall Oven-Mechanical Control
MODEL NUMBER SERIES
FBOEL1370-30
INSTRUCTION MANUAL
Read these instructions carefully before using your appliance, and keep it carefully.
If you follow the instructions, your appliance will provide you with many years of good service.
08/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FBOEL1370-30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Forno FBOEL1370-30

  • Page 1 ® 30" Sigle Wall Oven-Mechanical Control MODEL NUMBER SERIES FBOEL1370-30 INSTRUCTION MANUAL Read these instructions carefully before using your appliance, and keep it carefully. If you follow the instructions, your appliance will provide you with many years of good service.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Customer Care Warning Important Safety PARTS AND FEATURES The Handle Installation Operating Instructions OVEN USE...
  • Page 3 30" Sigle Wall Oven-Mechanical Control FBOEL1370-30...
  • Page 4: Customer Care

    Customer Care Thank you for purchasing a Forno product. Please read the entire instruction manual before operating your new appliance practices, features, operation and care recommendations of your appliance. Both the model and serial number are listed inside the product. For warranty purposes, you will also need the date of purchase .
  • Page 5: Warning

    WARNING FOR YOUR SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. and others. Al l safety messages will follow the safety alert symbol and either the word “DANGER,” “WARNING”...
  • Page 6: Warnings For Electric Installation

    WARNINGS FOR ELECTRIC INSTALLATION WARNING Electrical Shock Hazard Installation and service must be performed by a quali ed installer or service agency. The models may be powered at 240V or 208V. Always disconnect the power before servicing this unit. This appliance must be properly grounded. Failure to do so could result in death or serious injury.
  • Page 7: Important Safety

    IMPORTANT SAFETY INSTRUCTIONS • • Do not cover or block any Be sure the blower fan runs openings on this appliance. whenever the oven is in operation. If the fan does not • Use this appliance only for operate, do not use the oven. its intended use as described Call an authorized service in this manual.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS • • Always place oven racks in During and after use, do not desired location while oven is touch or let clothing or other cool. If a rack must be moved while oven is hot, do not let the heating elements or the potholder contact the hot interior surfaces of the oven...
  • Page 9: Parts And Features

    PARTS AND FEATURES A Oven Vent B Broil Element C Control Panel D Halogen Light E Bottom Element (not visible) F Model and Serial # Plate G Door Gasket...
  • Page 10: The Handle Installation

    The Handle Installation Install Oven Door Handle Be very careful not to scratch the surface of the unit. The appearance of the handle may vary from what is shown in the manual. Tool Needed • Hex screwdriver(provided) Assembling Handle 1. Partially loosen the set screws installed in both ends of the handle with the Hex screwdriver. Set screw (pre-installed) 2.
  • Page 11: Operating Instructions

    Operating Instructions CONTROL PANEL: Indicator light Cooking Mode: • Light: Turns the oven light on when turn to Light. (When select other cooking modes, the light will keep on during working). • Bake: Top heating element and bottom heating element work. •...
  • Page 12: Oven Use

    OVEN USE BEFORE USING THE OVEN 1. Turn the Cooking Mode Selection control knob to Roast mode. 2. Turn the Temperature Control knob to the highest setting. 3. Allow the oven to operate for 30 minutes with the door closed and no food in the cavity. NOTE: Any odor that may be detected during this initial use is due to the evaporation of substances used to protect the oven during storage.
  • Page 13: Oven Settings

    Oven (continued) OVEN SETTINGS Bake Baking is cooking with heated air. Both upper and lower elements in the oven are used, but the fan is used only during preheating. Follow the recipe or convenience food directions for baking temperature, time, and rack position. Baking time will vary with the temperature of ingredients and the size, shape, and finish of the baking utensil..
  • Page 14 Oven (continued) Broil and poultry may cook better at lower broiling temperatures. Tips: The oven door remains closed during broil. When inspecting the food, open the oven door no more than two inches. NOTES: Before broiling, position the rack to your needs •...
  • Page 15 Oven (continued) CONVECTION SETTINGS During convection cooking, the fan provides hot air circulation throughout the oven. The movement of heated air around the food can help to speed up cooking by penetrating the cooler outer surfaces. The food cooks more evenly, browning and crisping outer surfaces while sealing moisture inside.
  • Page 16 Oven (continued) Convection Broil Convection Broil adds the use of convection fan(s) to circulate heated air. Bring the rack to the middle of the cavity to provide evening cooking. Turn the cooking functions knob to the convection BROIL. Rotate the dial to the temperature you wish to use. The oven will begin preheating.
  • Page 17 Oven (continued) Guidelines: • Do not preheat for Convection Roast. • Roast in a low-sided, uncovered pan. • When roasting whole chickens or turkey, tuck wings behind back and loosely tie legs with kitchen string. • Use the 2-piece broil pan for roasting uncovered. •...
  • Page 18: Bake Chart

    BAKE TIPS • For best results, bake food on a single rack with at least 1" - 1½" (2.5 - 3 cm) space between utensils and oven walls. • Use one rack when selecting the bake mode. • Check for doneness at the minimum time. •...
  • Page 19: Convection Bake Tips

    CONVECTION BAKE TIPS Reduce recipe baking temperatures by 25°F (15°C). • For best results, foods should be cooked uncovered, in low-sided pans to take advantage of the forced air circulation. Use shiny aluminum pans for best results • Heatproof glass or ceramic can be used. Reduce temperature by another 25°F (15°C) when using heatproof glass dishes for a total reduction of 50°F (30°C).
  • Page 20: Convection Bake Chart

    CONVECTION BAKE CHART Reduce standard recipe temperature by 25 ºF (15 °C) for Convection Bake. Temperatures have been reduced in this chart. RACK TEMP. °F (°C) FOOD ITEM TIME (MIN) POSITION (PREHEATED OVEN) Cake Cupcakes 325 (160) 20-22 Bundt Cake 325 (160) 43-50 325 (160)
  • Page 21: Convection Roast Tips

    CONVECTION ROAST TIPS • Do not preheat for Convection Roast. • Roast in a low-sided, uncovered pan. • When roasting whole chickens or turkey, tuck wings behind back and loosely tie legs with kitchen string. • Use the 2-piece broil pan for roasting uncovered. WARNING Burn Hazard Use an oven mitt to remove temperature probe.
  • Page 22: Convection Roast Chart

    CONVECTION ROAST CHART TIME WEIGHT OVEN TEMP. RACK INTERNAL MEATS (min. per (lb) °F (°C) POSITION TEMP. °F (°C) Beef Rib Roast 325 (160) 16-20 145 (63) medium rare 18-22 160 (71) medium Rib Eye Roast, 325 (160) 16-20 145 (63) (boneless) medium rare 18-22...
  • Page 23: Convection Broil Tips

    CONVECTION BROIL TIPS • Place rack in the required position needed before turning on the oven. • Use Convection Broil mode with the oven door closed. • Do not preheat oven. • Use the 2-piece broil pan. • Turn meats once halfway through the cooking time (see convection broil chart). CONVECTION BROIL CHART BROIL INTERNAL...
  • Page 24: Dehydrate Tips

    DEHYDRATE TIPS The circulating heated air at a lower temperature slowly removes the moisture for food preservation. • Oven temperature for dehydrating is between 120ºF (50ºC) to 160ºF (70ºC). • Multiple racks can be used simultaneously. • Some foods require as much as 14-15 hours of time to fully dehydrate. •...
  • Page 25: Broil Tips

    APPROXIMATE FOOD PREPARATION DRYING TIME* TEST FOR DONENESS (hrs) Mushrooms Wash and towel dry. 7-12 Tough and leathery, Cut of stem end. Cut Tomatoes Wash and towel dry. 16-23 Dry, brick red color dry well Herbs Oregano, sage Rinse and dry with Dry at 120°F Crisp and brittle parsley and...
  • Page 26 BROIL TIME TIME RACK INTERNAL TEMP. FOOD AND THICKNESS SETTING SIDE 1 SIDE 2 POSITION °F (°C) °F (°C) (MIN.)* (MIN.)* Sausage - fresh 160 (71) Ham Slice (½") 160 (71) Seafood Fish Filets, 1" Cook until 10-14 Do not turn Buttered easily with fork...
  • Page 27: Oven Racks

    OVEN RACKS IMPORTANT: To avoid permanent damage to the porcelain finish, place food or bakeware on an oven rack. Do not place food or bakeware directly onto the oven door or oven bottom. • The oven racks can be placed in any of the six height positions with the oven. •...
  • Page 28: Oven Door Removal

    OVEN DOOR REMOVAL For normal oven use, there is no need to remove the oven door. However, should it become necessary to remove the door, follow the instructions in this section. IMPORTANT: • Make sure oven is cool and that power to the oven has been turned off before removing the door.
  • Page 29: Replacing An Oven Light

    To Replace the Oven Door: 1. Holding the door firmly, insert the upper arms of both hinges into the slots. The recesses must hook on the lips. Upper Arm Slots Recess 2. Open the oven door. NOTE: You should hear a “click” sound when the door is correctly in place. 3.
  • Page 30 1. Disconnect power at the main power supply (fuse or breaker box). 2. Using a Phillips-head screwdriver, remove the screw, and then remove the cover. Light Cover 3. Remove the burned out bulb from the socket. Light Bulb Light Cover NOTE: To avoid damage or decreasing the life of the new bulb, do not touch bulb with bare fingers.
  • Page 31: Troubleshooting

    • BAKING AND ROASTING PROBLEMS Before contacting Forno customer service, please check the chart below for cases that may apply to you. It can be simple misuse of material, shapes, and sizes of bakeware that causes poor results. Baking Issues...
  • Page 32 ® Customer Support: Call 1-866-231-8893 or email: info@forno.ca...
