SERVICE MANUAL
HOME CINEMA DVD/CD CONTROL CENTER
REMOTE CONTROL RM-SRXDV3R
STANDBY/ON
STB
VCR
TV
AUDIO
TV
TAPE
CDR
FM/AM
TV DIRECT
STB
VCR
DVD
TV/VIDEO
REW/
TUNING
/FF
REPEAT
SLEEP
FM MODE
STROBE
TV/STB CH
SOUND
EFFECT
CENTER
1
2
3
ANALOG
/DIGITAL
TEST
REARáL
INPUT
4
5
6
AUDIO
SURR ON/OFF
REARáR
7
8
9
STANDBY
STANDBY/ON
SUBTITLE
SURR MODE
Ð SUBWOOFER +
10/0
+10
VFP
100+
TV RETURN
PROGRESSIVE
DIMMER
ANGLE
+
+
MUTING
TV VOL
VOLUME
ZOOM
Ð
Ð
TA/NEWS/INFO
DIGEST
TOP MENU
MENU
PTY
PTY SEARCH
PTY
CHOICE
ENTER
ON SCREEN
RETURN
DISPLAY
HOME CINEMA
DVD/CD CONTROL CENTER
Contents
Safety precautions --------------------------------------------------------
Preventing static electricity ----------------------------------------------
Disassembly method ------------------------------------------------------
Adjustment method -------------------------------------------------------
Description of major ICs -------------------------------------------------
RX-DV3RSL
R X - D V 3 R H O M E C I N E M A D V D / C D C O N T R O L C E N T E R
DVD
STB
VCR
INPUT
SURROUND
ON/OFF
MODE
ANALOG/DIGITAL
INPUT ATT.
REC MODE
COPYRIGHT
2002 VICTOR COMPANY OF JAPAN, LTD.
B ----------------------- U.K.
E --- Continental Europe
EN----- Northern Europe
TV
TAPE/CDR
FM/AM
TV DIRECT
MASTER VOLUME
SOURCE NAME
SETTING
ADJUST
MEMORY
CONTROL
DVD/SUPER VCD/VCD/CD
RX-DV3RSL
Area suffix
COMPACT
SUPER VIDEO
1-2
1-4
1-5
1-14
1-16~46
No.21154
Oct. 2002
